Sennheiser SKM 2020-D Dimensions

Modulation 2-FSK

RF frequency range 926 -928 MHz

Number of channels 6

Frequency response 100 – 7,000 Hz

RF output power 1 mW

Signal-to-noise ratio > 65 dB(A)

Total harmonic distortion ≤1%

Pick-up pattern Cardioid

Transducer principle Dynamic

Operating time (rech. batt. pack) 8 hours

Power supply BA 2015 (2.4 V); 2 AA (1.5 V)

Operating temperature 0 - 50°C

Weight incl. rechargeable batt. pack 14.82 oz.

Range 80 ft. indoors, 160 ft. outdoors

Digital RF wireless transmission

6 channels in the license-free ISM frequency

band (926-928 MHz)

Rugged housing for everyday use

Ideal for use in noisy environments

Backlit display indicates selected channel

and battery status

Rotatable end cap for on/off, mute, and

menu settings

Up to 8 hours of use with the BA2015G2

rechargeable battery

KEY FEATURES TECHNICAL DATA

Digital Handheld Transmitter

SKM2020-D-US

The SKM 2020-D-US handheld transmitter may be the easiest way to address your audience. Should a participant have

a question, simply hand the microphone to them and all participants will hear clearly! The transmitter is easy to operate

and offers a rugged design for everyday use. The microphone effectively attenuates unwanted background noise to

ensure clear, reliable communication to all of your listeners. A convenient backlit display allows the user to view the

active channel, as well as battery status. The included BA2015 G2 rechargeable battery offers up to 8 hours of use and

charges in about 3.5 hours with the EZL2020-20L charger.

About the Tourguide 2020 Series

The Tourguide 2020 series is the first digital RF wireless tour guide system in the ISM band, offering excellent audio

quality and extremely reliable, interference-free communication. Designed for easy set-up and operation, this system

offers a high degree of flexibility with six available audio channels, making it an ideal choice for almost any guided

tour application! Other system components include a small bodypack transmitter, SK 2020-D-US, with your choice of

microphone (ordered separately); lightweight stethoset receivers, HDE 2020-D-US; and a portable, convenient carrying

case with charger, EZL2020-20L.

Digital Handheld Transmitter

SKM2020-D-US

Sennheiser Electronic Corporation

1 Enterprise Dr • Old Lyme, CT 06371

(860) 434-9190

ARCHITECT SPECS

The transmitter must utilize the ISM band frequencies of 926 – 928 MHz for transmission of up to six audio channels,

with an AF frequency response of 100–7,000 Hz. It must accept a rechargeable battery or 2 AA batteries. It must

feature a rotatable end cap for access to on/off, mute, menu up/down, and set buttons. It must have a backlit display

indicating signal source, source level, selected channel, battery status and lock mode. It must be easily configured via

set and menu up/down buttons.

The SKM2020-D-US offers a high degree of flexibility with six available audio channels, making it an ideal choice for

almost any guided tour, assistive listening, language transmission and more!

APPLICATIONS:
