Sennheiser MKH 8060 User manual

ACTION.

MKH 8060 Short Gun Microphone

MKH_8060.indd 1 25.03.11 13:43

MKH RF Microphones

Sennheiser‘s MKH Line has constantly set

new standards in broadcast and recording.

The microphones operate on the RF principle

which Sennheiser has used for more than

50 years and brought to the highest level of

perfection.

Among the many advantages of this

principle are an extremely low inherent self-

noise, the capability to handle high sound

pressure levels without distortion and a high

resistance to adverse climatic conditions.

Sennheiser has recently updated its classic

MKH Line with the new MKH 8060 short

gun microphone which incorporates the

advantages of the renowned MKH 416

and suits all the needs of a modern ﬁlm

production

MKH 8060

Whether it‘s a feature ﬁlm, documentary

or ENG, the new MKH 8060 will give you

the quality sound to match your exciting

pictures.

It’s very small dimensions are especially

surprising when it shows its strengths as

a professional gun microphone.

Its excellent directivity and improved off-

axis linearity ensure a clear and natural

sound recording, whether you are in the

studio or outdoors.

Its special design ensures attenuation of

off-axis sound without coloration.

Part of the ﬂexible MKH 8000 series, just

add the MZD 8000 and it is a digital mic.

Features

Super-cardioid/lobar pick-up pattern

Very natural sound

Uncolored off-axis sound

Exceptionally low inherent self-noise

Extremely low distortion

Transformerless and fully ﬂoating

balanced output

High output signal

Rugged metal housing

non-reﬂective Nextel coating

Extremely weather-proof due to RF circuit

Ideal for camera mounting due to

compact design

incl. MZD 8000 fully AES 42 digital

microphone

Capturing the Moment

By Adding Perfect Sound to Your Exciting Pictures.

MKH 8060 Gun Microphone.

MKH_8060.indd 2 25.03.11 13:43

Short

MKH RF Microphones

Sennheiser‘s MKH Line has constantly set

new standards in broadcast and recording.

The microphones operate on the RF principle

which Sennheiser has used for more than

50 years and brought to the highest level of

perfection.

Among the many advantages of this

principle are an extremely low inherent self-

noise, the capability to handle high sound

pressure levels without distortion and a high

resistance to adverse climatic conditions.

Sennheiser has recently updated its classic

MKH Line with the new MKH 8060 short

gun microphone which incorporates the

advantages of the renowned MKH 416

and suits all the needs of a modern ﬁlm

production

MKH 8060

Whether it‘s a feature ﬁlm, documentary

or ENG, the new MKH 8060 will give you

the quality sound to match your exciting

pictures.

It’s very small dimensions are especially

surprising when it shows its strengths as

a professional gun microphone.

Its excellent directivity and improved off-

axis linearity ensure a clear and natural

sound recording, whether you are in the

studio or outdoors.

Its special design ensures attenuation of

off-axis sound without coloration.

Part of the ﬂexible MKH 8000 series, just

add the MZD 8000 and it is a digital mic.

Features

Super-cardioid/lobar pick-up pattern

Very natural sound

Uncolored off-axis sound

Exceptionally low inherent self-noise

Extremely low distortion

Transformerless and fully ﬂoating

balanced output

High output signal

Rugged metal housing

non-reﬂective Nextel coating

Extremely weather-proof due to RF circuit

Ideal for camera mounting due to

compact design

incl. MZD 8000 fully AES 42 digital

microphone

Capturing the Moment

By Adding Perfect Sound to Your Exciting Pictures.

MKH 8060 Gun Microphone.

MKH_8060.indd 2 25.03.11 13:43

Short

Delivery includes

The MKH 8060 comes with a threaded transport tube,

MZQ 8060 microphone clamp and a MZW 8060 foam windshield.

The microphone system consists of the microphone head and the

MZX 8000 XLR module.

Recommended Accessories

MZS 20-1 pistol grip suspension for use with basket windshields

MZW 20-1 basket windshield

MZH 20-1 hairy cover providing protection from wind noise

Technical data

MKH 8060

Transducer principle RF condenser microphone

Pick-up pattern super-cardioid/lobar

Frequency response 50–25,000 Hz

Sensitivity -24 dBV/Pa (63mV/Pa)

Max. sound pressure level 129 dB SPL

Equivalent noise level 11 dB (A) (DIN-IEC 651)

23 dB (CCIR 268-3)

Phantom powering 48 ± 4 V Phantom (P48, IEC 61938)

Current consumption 3.3 mA

Nominal impedance 25 ƻ

Min. terminating impedance 2 Kƻ

Weight 80 g (112 g with XLR module MZX 8000)

Dimensions Length: 145 mm (178 mm with XLR module MZX 8000)

Diameter: 19 mm

Operating temperatur -10 °C to 60 °C

Microphone frequency response curve Polar diagram

low frequencies

125 Hz

250 Hz

500 Hz

1 kHz

high frequencies

2 kHz

4 kHz

8 kHz

16 kHz

30°

60°

90°

150°

120°

0°

30°

60°

90°

120°

150°

180°

MKH 8060 0302

MKH_8060.indd 3 25.03.11 13:43

542558 03/11 Printed in Germany Sennheiser is a registered trademark of Sennheiser electronic GmbH & Co. KG

Sennheiser electronic GmbH & Co. KG

Am Labor 1, 30900 Wedemark, Germany

www.sennheiser.com

MKH_8060.indd 4 25.03.11 13:43
