Sennheiser MKE 2 elements User manual

GEBRAUCHSANLEITUNG

INSTRUCTIONS FOR USE

NOTICES D‘EMPLOI

ISTRUZIONI PER L‘USO

INSTRUCCIONES PARA EL USO

GEBRUIKSAANWIJZING

MKE 2

MZS 2

MKE 2

Condensorclip-onmicrophonewithomni-directionalcharacteristicfortopsound-

quality and robustness requirements. Suitable for vocal transmission and miking

up instruments in all fields of live sound transmission.

Characteristics

앫Extremely small size

앫Insensitive to structure-borne noise

앫Linear frequency response

앫Robust

Note

If the microphone is fastened as shown or in a similar manner, it is essential to

ensure that

왘it is not in direct contact with the skin

왘it is covered up whilst make-up is applied in order

to prevent contamination of the sound inlet.

Attachment to articles of clothing

MZQ 2: this clip serves to attach the mic to the collar, lapel or button hole etc.

The pin MZS 2 can be used for rough clothing. The ZH 2 pin provides high

stability.Thispinisalsosuitableforarticlesofclothingwhichdonothaveacollar

or lapel to attach the mic with the MZQ 2 clip.

MZM 10+MZM 2: this magnetic clip is quite unobtrusive. Often the frictional force

between the mic and the clothing is sufficient to guarantee that the microphone is

notdislocated.Inaddition,theneckstrap(included)ensuresthatthemiccannotbe

displaced from its proper position, especially with regard to smooth clothes.

Storing the microphone

왘The microphone should be stored in a dry room.

왘Iftheoperatingconditionsdeviatesubstantiallyfromtheclimatic conditions

in the storage room, the microphone, should be exposed to the new climatic

conditions for roughly 15 minutes prior to operation.

MKE 2 - Technical dat in comparison

MKE 2-2R MKE 2-2R bd MKE 2-2R rd MKE 2-60 MKE 2-4 MKE 2-5 MKE 2-P

Directional characteristic omnidirectional omnidirectional omnidirectional omnidirectional omnidirectional omnidirectional omnidirectional

Transmission range 20-20000 Hz 20-20000 Hz 20-20000 Hz 20-20000 Hz 20-20000 Hz 20-20000 Hz 20-20000 Hz

±3 dB ±3 dB ±3 dB ±3 dB ±3 dB ±3 dB ±3 dB

Free-field open-circuit 31 mV / Pa 0.35 mV / Pa 6.3 mV / Pa 6.3 mV / Pa 6.3 mV / Pa 31 mV / Pa 10 mV / Pa

sensitivity (1kHz) ±2.5 dB ±2.5 dB ±2.5 dB ±2.5 dB ±2.5 dB ±2.5 dB ±2.5 dB

Rated impedance 2700 Ω600 Ω1000 Ω200 Ω1000 Ω2700 Ω50 Ω

Min. terminating impedance 15 KΩ3.3 KΩ4.7 KΩ1000 Ω4.7 KΩ15 KΩ1 KΩ

Equivalent noise level

A-weighted (DIN IEC 651) 27 dB 27 dB 27 dB 27 dB 27 dB 27 dB 27 dB

CCIR-weighted (CCIR 468-1) 38 dB 38 dB 38 dB 38 dB 38 dB 38 dB 38 dB

Sound pressure level limit 120 dB 150 dB 140 dB 140 dB 140 dB 120 dB 130 dB

Feed from transmitter from transmitter from transmitter from K6/K6P from transmitter open phantom feed

SK 2012 SK 2012 SK 2012 feed modul SK 50/SK 250 cable end 12-48 V

Plug Mikrodot Mikrodot Mikrodot special plug Lemo-plug - XLR-3-plug with

system K6 4-polig integrated phantom

feed adapter

Cable length 1.5 m 1.5 m 1.5 m 3 m 1.5 m 4 m 3 m

Diameter of the microphone 6 mm 6 mm 6 mm 6 mm 6 mm 6 mm 6 mm

Weight (without plug+cable) 1g1g1g1g1g1g1g

Delivery includes:

Wind-shield MZW 2 2-222-2

Clip MZQ 2 2 - 2 2 2 - 2

Pin MZS 2 1 - 1 1 1 - 1

Magnetic holder set MZM2/MZM10 1-1-1-1





Frequency response

Cleaning the sound inlet

Pull the sound inlet off of the microphone as shown. Release the inlet either with

your fingers or using a tool with a blunt edge. If several microphones with short

cleaning intervals (e.g. once a week) are used, it is advisable to order a special tool

(Order No. 37 990) from your Sennheiser dealer.

Thecleaningintervalsaredependentonthedegreeofcontamination.Anultrasonic

bath and Kaltron or similar should be used for cleaning. In the event of severe

contaminationormechanicaldamage thesoundinletmustbereplaced withanew

inlet (Order No. 26317: black; 19037: beige).

Before attaching the windscreen, please remove the gauze cap.

Sennheiser electronic KG

Telefon: 05130/600-0

Telefax: 05130/6312

D-30900 Wedemark

Printed in Germany Publ. 8/95 18273 / A11

Änderungen vorbehalten

Subject to alterations

Sous réserve de modifications

Con riserva di modifiche

Reservado el derecho a introducir modificaciones

Wijzigingen voorbehouden
