Features—Benets

• Metal construction—rugged and reliable

• Hum compensating coil—reduces electrical interference

• Silent on/off switch (e 865-S only)

• Neodynum ferrous magnet with boron—keeps mic stable regardless of climate

• Falcon ring—consistent sound over time

Technical Data

resnednoc tertcelE recudsnarT

zH 000,02–04 esnopser ycneuqerF

dioidrac-repuSnrettappu-kciP

Bd051LPSmumixaM

Sensitivity (free eld, no load) 3 mV/Pa at 1 kHz. nominal

Nominal impedance at 1 kHz 200 Ω

Min. terminating impedance 1 k W

gnirewopmotnahpV84–V21ylppusrewoP

.zo11.xorppa)elbactuohtiw(thgieW

27.7x9.1sehcninisnoisnemiD

e 865 Professional Condenser Vocal Microphone

The E 865 represents the rst condenser microphone in the acclaimed Evolution Series. A live

performance, lead vocal microphone, the E 865 easily cuts through high on-stage levels by

virtue of its detailed and natural 40 Hz–20 kHz reproduction and superb transient response. Its

smooth super-cardioid polar pattern rejects feedback with low, off-axis coloration. The E 865

withstands sound pressure levels of up to 150 dB, and deftly suppresses pop noise. While it

picks up the nest sonic nuances, the E 865 is at the same time rugged, beneting from high-

quality workmanship and a robust all-metal housing. The microphone ships with a pouch and

mic clip.

Architect’s Specications

The microphone shall be an eletret condenser microphone operating in the frequency range

of 40–20,000 Hz. It shall have a super-cardioid pick up pattern with 3 mV/Pa at 1 kHz. nominal

sensitivity. The maximum SPL shall be 150 db, and the nominal impedance at 1 kHz shall be

200 Ω. The unit shall be powered by a 12–48V phantom power unit. The unit shall be

1.9 x 7.72 inches and weight approx. 11 oz. The unit shall be a Sennheiser e865 microphone.

Supplied Accessories

1 protective pouch

1 MZQ 800 microphone clip

Optional Accessories

21' XLR microphone cable MC21N

2304WZMneercsdniwmaofyerG

Floor stand with boom arm SEMS 3000

e 865

e 865

CBinder - MIcrophones.indd 47 11/11/08 2:25:05 PM
