Sennheiser E 609 silver Dimensions

Microphones | Dynamic Microphone

General Description

The e 609 has an excellent transient response. Its laterally mounted

capsule has been specially developed for miking guitar cabs face on and

extremely close to the signal source. The e 609 is also suitable for drum

miking, particularly toms, where the microphone’s profile allows the cap-

sule to be positioned close to the drum skin.

Features

j

Exceptional full-size sound quality

j

Very high sound pressure handling capability

j

Super-cardioid pick-up pattern provides isolation from

other on-stage signals

j

Hum compensating coil

j

Delivery includes: 1 e 609

1 microphone clip

1 pouch

Technical Data

Pick-up pattern ...........................................................super-cardioid

Frequency response .................................................40 – 18,000 Hz

Sensitivity (free field, no load, 1 kHz)...........................1.5 mV/Pa

Nominal impedance ................................................................. 350 Ω

Min. terminating impedance..................................................... 1 kΩ

Dimensions ...........................................................55 x 34 x 134 mm

Weight ........................................................................................ 180 g

Profile

Super-cardioid instrument microphone, hum compensating

coil, frequency response 40 – 18,000 Hz, sensitivity (free field,

no load) 1.5 mV/Pa at 1 kHz, nominal impedance 350 Ω, min.

terminating impedance 1 kΩ, dimensions 55 x 34 x 134 mm,

weight 180 g.

Cat. No. 004522
