Sennheiser MZD 8000 User manual
MZD 8000
Instruction manual
MZD 8000
Digitalmodul
MZD 8000_524157_0408_Sp6.book Seite 1 Dienstag, 21. Oktober 2008 7:58 19
1
Contents
Important safety information ........................................................ 2
The MZD 8000 ................................................................................... 3
Delivery includes ............................................................................... 4
Product overview .............................................................................. 4
Putting the digital module into operation .................................... 5
Connecting the microphone head and the cable ................... 5
Connecting the digital module to other devices .................... 6
Remote controlling the MZD 8000 ................................................. 7
If a problem occurs... ........................................................................ 8
Cleaning the MZD 8000 .................................................................... 9
Accessories ......................................................................................10
Specifications ..................................................................................11
Manufacturer Declarations ............................................................12
Thank you for choosing Sennheiser!
We have designed this product to give you reliable operation
over many years.
Over 60 years of accumulated expertise in the design and
manufacture of high-quality electro-acoustic equipment have
made Sennheiser a world-leading company in this field.
Please take a few moments to read these instructions care-
fully, as we want you to enjoy your new Sennheiser products
quickly and to the fullest.
MZD 8000_US.fm Seite 1 Freitag, 31. Oktober 2008 11:16 11
2
Important safety information
• Please read this instruction manual carefully and completely
before using the device.
• Make this instruction manual easily accessible to all users at all
times.
• Always include this instruction manual when passing the
device on to third parties.
• Never open the device. If devices are opened by customers in
breach of this instruction, the warranty becomes null and void.
• Water entering the housing of the device can cause a short-
circuit and damage the electronics. Protect the device from
wetness. Use only a slightly damp cloth to clean the device.
• Do not expose the device to extreme temperatures.
• Use the device with care and store it in a clean, dust-free
environment.
Intended use of the device
Intended use includes:
• having read this instruction manual, especially the chapter
“Important safety information” on page 2,
• using the device within the operating conditions and limita-
tions described in this instruction manual.
“Improper use” means using the device other than as described in
these instructions, or under operating conditions which differ
from those described herein.
MZD 8000_US.fm Seite 2 Freitag, 31. Oktober 2008 11:16 11
3
The MZD 8000
The MZD 8000 digital module is an AES 42 A/D converter for all
microphone heads of the MKH 8000 series.
The MZD 8000 has the following features:
• Direct screw-on connection for the
microphone heads of the MKH 8000 series
• 2-channel 24 bit A/D converter,
dynamic range 115 dB
• Studio grade preamplifier and converter
• Sampling rate 44.1 kHz, 48 kHz, 88.2 kHz,
96 kHz, 176.4 kHz and 192 kHz
• Integrated, remote-controllable DSP functions such as
low-cut filter, attenuation and gain
• Digital output in AES 42 format
• External synchronization via AES 42, Mode 2
• Color: Nextel®black, non-reflecting,
matching to the MKH 8000 series
MZD 8000_US.fm Seite 3 Freitag, 31. Oktober 2008 11:16 11
4
Delivery includes
1 MZD 8000 digital module
1 instruction manual
Product overview
Connection for microphone head
MZD 8000 digital module
XLR-3M socket
쐋
MZD 8000_US.fm Seite 4 Freitag, 31. Oktober 2008 11:16 11
5
Putting the digital module into operation
Connecting the microphone head and
the cable
왘Screw an MKH 8000 series micro-
phone head to the connection of
the MZD 8000 as shown.
Note:
During operation, the MZD 8000’s connection for the micro-
phone head provides 48 V phantom power.
왘First screw on a microphone head before connecting an XLR
cable.
To connect the cable:
왘Connect an XLR cable to the XLR-3M
socket of the MZD 8000.
The XLR connection locks into place
with an audible click.
Long cables and multiple connectors in
the cable path lead to a drop in the
CAUTION! Danger of damage to the device!
An incorrect supply voltage can cause damage to the
power supply unit, the MZD 8000 and to subsequent
devices.
왘Only connect the digital module to microphone
inputs and power supply units which supply
phantom power according to the AES 42 standard.
쐋
MZD 8000_US.fm Seite 5 Freitag, 31. Oktober 2008 11:16 11
6
supply voltage and a deterioration in jitter characteristics, espe-
cially at high sampling rates.
왘If possible, use a continuous cable to connect the microphone
and the subsequent device.
왘For longer cable distances, only use AES/EBU cable.
Connecting the digital module to other devices
The MZD 8000 digital module receives and transmits electrical
signals according to the AES 42 standard (A).
If your mixing console does not support the AES 42 standard:
왘Use a format converter for conversion into other signals (B).
For additional information, visit the Internet at www.aes.org.
왘Synchronize all devices of the digital signal chain.
A
B
Control PC
Format converter
MZD 8000
Recording device/
mixing console
MZD 8000_US.fm Seite 6 Freitag, 31. Oktober 2008 11:16 11
7
To connect the microphone:
왘Use a suitable cable to connect the MZD 8000 to the micro-
phone input of a format converter or a mixing console.
왘When connecting the cables, make sure that the connectors
are properly locked.
Remote controlling the MZD 8000
Via the AES 42 interface, you can make the following settings to
the MZD 8000.
Depending on the software or the format converter used, some
settings are possibly not supported.
For information on software updates, visit the Internet at
www.sennheiser.com.
Parameter Settings
Sampling rate 44.1/48/88.2/96/176.4/192 kHz
Analog pre-attenuation 0, –6, –12, –18 dB
Digital high-pass filter Off/40/80/160 Hz
Digital signal gain from 0 to 63 dB (in steps of 1 dB)
Test signal Mono: 1 kHz sine
Stereo: 1 kHz sine left and right
(phase of right channel is advanced)
Steps:
Off/–6 dBFS/–48 dBFS/–60 dBFS
Phase (polarity) 0, 180°
Mute On/off
MZD 8000_US.fm Seite 7 Freitag, 31. Oktober 2008 11:16 11
8
If a problem occurs...
Problem Possible cause Solution
Microphone
does not work No supply
voltage available. Check the power supply
unit/the corresponding
software settings.
Microphone is
not connected to
an AES 42 input.
Check if the used
input complies with the
AES 42 standard.
Channel is muted. Deactivate “Mute” in the
AES 42 remote control.
Audio signal
is distorted Excessive sound
pressure of the
audio signal to
be recorded.
Increase the pick-up
distance or activate the
pre-attenuation in the
AES 42 remote control.
Overload due to
low-frequency
interference.
Use a suitable windshield
(accessory).
Activate the pre-
attenuation in the AES 42
remote control.
No
synchonization
between
MZD 8000
and
receiver
or no
digital
audio
signal
Connected cable
is incorrect. Check the cable.
Connected cable
is too long. Use an AES/EBU cable.
Use a shorter cable.
Reduce the sampling rate.
Cable path with
too many con-
nectors.
Use a continuous cable.
MZD 8000_US.fm Seite 8 Freitag, 31. Oktober 2008 11:16 11
9
Cleaning the MZD 8000
Use a slightly damp cloth to clean the device from time to time.
Note:
Do not use any cleansing agents or solvents.
MZD 8000_US.fm Seite 9 Freitag, 31. Oktober 2008 11:16 11
