Fastening Solutions™

FinishPro®

32

ProSeries 16 Gauge Finish Nailer

11

/413/411

/22 21

/2

Driving 16ga Fasteners from 1 1/4" to 2 1/2" the FinishPro32 provides all

the versitility a professioanl contractor will ever need, combined with

features such as a thumbwheel adjustable depth of drive and a reversed

safety foot, the FinishPro32 will be the only 16ga nailer needed

Applications:

Baseboards, cabinets, case goods, chair rail, crown molding, decorative

trim, door & window casing-sash & millwork, bookshelves, exterior

triminterior trim,

FinishPro®32 Features and Benefits:

• Thumb wheel adjustable depth-of-drive

• 360º adjustable exhaust – keeps oil and dust away from the work surface

• Belt hook – for convenience

• Stretch comfort grip – for comfort and control

• EZ-Clear® removes jams fast and easy

• No-mar pad – to protect work materials

• Rear bumper – to protect the work surface

• Available in dual action or restrictive fire

• One-year warranty

• Includes case, fitting, oil, wrench and manual

www.senco.com ©2006 by Senco Products, Inc.

Fastener Specifications:

Gauge: 16

Fastener Range: 1-1/4” – 2-1/2”

Finish: Galvanized

Specifications:

Item#: 1X0201N Sequential Actuation w/case

Tool Weight: 4.3 lbs (1.8 kg)

Height: 113/8” (349 mm)

Length: 12” (304 mm)

Nail Capacity: 110

Reg. Operating Pressure: 70-120 psig

Mode of Operation: Tool is available with either contact actuation or

sequential trigger mechanism.

Fastening Solutions™

360º Adjustable Exhaust

Quiet design

Stretch Comfort Grip

www.senco.com ©2006 by Senco Products, Inc.

No-Mar Pad

Protects woodwork

Easy-Open Latch

For more comfortable

loading

Rear Bumper

Protects work surface

Belt Hook

Lets the tool go

where you go

Thumb Wheel Adjustable

Depth-of-Drive

Drives staples to a consistent

and controllable depth

Easy-Clear Guide Body

To clear jams fast

FinishPro®

32

ProSeries 16 Gauge Finish Nailer

Always read the Operators Manual and Safety Instructions with all tools to ensure

proper use and safety precautions or contact SENCO for more information on our

trigger systems. Choose the right trigger system for your specific needs!

For additional information on how SENCO Fastening Solutions will save you time,

reduce costs, and increase quality, call our toll-free Action Line: 1-800-543-4596 to

find your nearest Authorized Senco Dealer or Distributor.

Visit our web site at: www.senco.com

Sequential Actuation Trigger (also known as restrictive trigger or trigger fire) operates

in the following a sequence - depress the safety element at the nose of tool against the

work surface then pull the trigger. After each fastener is driven, release the trigger and

lift the tool off the work surface before starting the sequence again. This trigger is

recommended and acceptable for most applications.

Contact Actuation Trigger (also known as dual action, bounce or bottom fire)

operates in the following sequence- pull the trigger first and keep the trigger pulled

while moving the tool along the work surface with a bouncing motion, depressing the

safety element at the nose of the tool against the work surface where the fastener is to

be driven. This trigger is recommended for use by trained professionals only in high

production or volume applications.
