Senco FINISHPRO 18 User manual

FinishPro®18 – Model PC0947

18 Gauge Brad Nailer Compressor Combo Kit

NEW BRAD NAILER KIT!

Everything to get you started on the job is included

in this one package and at a price that creates an

excellent value.

The FinishPro® 18 brad nailer is a versatile nailer for

all your finish needs. FinishPro® 18 drives 18 gauge

nails from 5/8" – 2".

The SENCO PC1010 Compressor is a 1 hp. (peak)

.5 hp. (running), 1 gallon, oil-less portable air

compressor. Its' lightweight, rugged design will

satisfy the needs of the pro!

Applications:

Interior trim, cabinets, chair rail, crown molding,

baseboards, book shelves and exterior trim

Kit Contents:

• FinishPro® 18 Brad Nailer

• 1 gallon electric oil-less compressor

• 1/4” x 25’ coil hose

• Tool oil

• All necessary air fittings

• Safety glasses

• Manuals

• Variety pack of 18 ga. brad nails

PC1010 Compressor Features and Benefits:

• 1 hp. (peak) .5 hp.(running), oil-less motor

• 1 gallon capacity tank

• 4 amps @ 115V, 120 PSI Max Output

• 1/4" quick disconnect coupler and regulator

• Individual gauges for tank and regulated output

pressure

• Hand carry – cushioned grip handle, compact,

rugged and designed for the pro

• Lightweight - 20 lbs. (9.09 kg)

• One year warranty

FinishPro® 18 Features and Benefits:

• Item Code: PC0947

• Adjustable depth-of-drive control

• Adjustable exhaust

• Belt hook – for convenience

• Soft grip – for comfort and control

• No-mar pad – to protect work surface

• Rear bumper – to protect work finish

• Lightweight and powerful

• One year warranty

Fastener Specifications:

The FinishPro® 18 will drive 18 gauge brad nails from

5/8" – 2"

15/8"

18 gauge

11/4"13/4"

11/2"2"

5/8"

Fastening Solutions™

FinishPro®18 – Model PC0947

18 Gauge Brad Nailer Compressor Combo Kit

For additional information on how Senco Power Fastening Systems will save you time, reduce costs and increase quality, call our toll-free

Action Line: 1-800-543-4596 or visit our website @ www.senco.com to locate the dealer nearest you.

1 gal Tank

1/4" Quick

Disconnect

Coupler

Tank Pressure

Gauge

Regulator & Outlet

Pressure Gauge

120 PSI Max Output

Easy Grip Handle

Adjustable

Depth-of-Drive

No-Mar Pad

Adjustable

Exhaust

Full Comfort Grip

Belt Hook

Rear Bumper

FinishPro® 18 Brad Nailer

PC1010 1 hp (peak) .5 (running), 1 gal, Oil-Less

1 hp peak,

Oil-Less Motor

4 amps @ 115V

Specifications:

Tool Weight: 3 lbs (1.6 kg)

Height: 9.3" (238 mm)

Length: 9.75" (248 mm)

Nail Capacity: 110

Nail Range: 5/8" – 2"

Nail Gauge: 18

Reg. Operating Pressure: 70-95 psig

Warranty: 1 year

Specifications:

Power source: Electric

Max. amp: 4 amps @115V

Horsepower: 1 hp. (peak) .5 hp.(running)

Pump: Oil-less

SCFM @ 90 psi: 0.7

Pump-up time: 0 - 120 psi 128 seconds

Recovery time: 90 - 120 psi 35 seconds

Max pressure: 120 psi

Tank storage: 1 gallon

Weight: 20 lbs. (9.09 kg)

Dimensions: length 14", height 13", width 10"

Warranty: 1 year

Lightweight

3 lbs.

Lightweight

20 lbs.
