Senco PC2015 User manual
1
PP
PP
Parar
arar
arts Refts Ref
ts Refts Ref
ts Reference Guideerence Guide
erence Guideerence Guide
erence Guide
PC2015 8.0 H.PPC2015 8.0 H.P
PC2015 8.0 H.PPC2015 8.0 H.P
PC2015 8.0 H.P..
..
.GASOLINE AIR COMPRESSORGASOLINE AIR COMPRESSOR
GASOLINE AIR COMPRESSORGASOLINE AIR COMPRESSOR
GASOLINE AIR COMPRESSOR
MTM009 Issue Date: 04/30/00MTM009 Issue Date: 04/30/00
MTM009 Issue Date: 04/30/00MTM009 Issue Date: 04/30/00
MTM009 Issue Date: 04/30/00 20002000
20002000
2000
bb
bb
by SENCO Pry SENCO Pr
y SENCO Pry SENCO Pr
y SENCO Products,oducts,
oducts,oducts,
oducts,
Inc.Inc.
Inc.Inc.
Inc. Cincinnati,OH 45244- USACincinnati,OH 45244- USA
Cincinnati,OH 45244- USACincinnati,OH 45244- USA
Cincinnati,OH 45244- USA
©
PDAC040-041700-DUBS
Questions? Comments? call SENCO’s toll-free Action-line: 1-800-543-4596 or e-mail: Toolprof@senco.com
OMAC0073-041400-DUBS
2
PC2015PC2015
PC2015PC2015
PC2015
GASOLINE AIRGASOLINE AIR
GASOLINE AIRGASOLINE AIR
GASOLINE AIR COMPRESSORCOMPRESSOR
COMPRESSORCOMPRESSOR
COMPRESSOR PP
PP
Parar
arar
artsts
tsts
ts RefRef
RefRef
Reference Guideerence Guide
erence Guideerence Guide
erence Guide
3
PDAC039-041500-DUBS
SENCO PC2015 8.0 HP GASOLINE AIR COMPRESSORSENCO PC2015 8.0 HP GASOLINE AIR COMPRESSOR
SENCO PC2015 8.0 HP GASOLINE AIR COMPRESSORSENCO PC2015 8.0 HP GASOLINE AIR COMPRESSOR
SENCO PC2015 8.0 HP GASOLINE AIR COMPRESSOR
REPLAREPLA
REPLAREPLA
REPLACEMENT PCEMENT P
CEMENT PCEMENT P
CEMENT PARAR
ARAR
ARTS LISTTS LIST
TS LISTTS LIST
TS LIST
PP
PP
Parar
arar
art No.t No.
t No.t No.
t No. DescriptionDescription
DescriptionDescription
Description
4
030174 PUMP
070151 GRIP
090069 BUSHING
100095 FLYWHEEL
100097 DRIVE PULLEY
110044 BELT DRIVE
140068 WHEEL
140069 ISOLATOR
150007 HOSE
150188 HOSE
190086 FILTER ASSEMBLY
190087 FILTER ELEMENT
200314 AXLE SPACER
200420 AXLE
200421 REGULATOR MOUNTING BRACKET
200457 BELTGUARD BRACKET
200468 BELT TENSIONER PLATE
220228 SAFETY RELIEF VALVE
220231 ADJUSTABLE REGULATOR
220257 PRESSURE GAUGE
220260 PILOT VALVE
220283 PLATE
230050 ELBOW
230053 ELBOW
230111 BUSHING
230127 STREET TEE
230312 DRAIN VALVE
240010 NIPPLE
240160 ADAPTER
250439 O-RING
250440 O-RING
260208 SEAL
270015 BOLT
270066 BOLT
270067 BOLT
270121 BOLT
270122 BOLT
270576 BOLT
278002 BOLT
278032 BOLT
278033 BOLT
278433 BOLT
278803 BOLT
278908 BOLT
278921 BOLT
278934 BOLT
280002 WASHER
280023 WASHER
281032 WASHER
289001 WASHER
300155 LOCKNUT
300157 LOCKNUT
300159 LOCKNUT
303030 FLANGE NUT
330020 EDGING
330197 FASTENER
330294 THROTTLE CONTROL
340130 LABEL
340575 LABEL
340588 LABEL
340815 LABEL
340817 LABEL
340819 LABEL
340821 LABEL
340823 LABEL
340842 LABEL
390106 PLUG
420011 HOSE CLAMP
430078 KEY
430092 COTTER PIN
430102 KEY
460814 AIR OUTLET
460815 INNER COOLER
460816 COVER
460817 CYLINDER
460818 PLUG
460819 CAP
460820 SIGHT GLASS
460821 ISOLATOR
460822 CAP
460823 HEAD
480024 BEARING
480060 BEARING
700238 RING SET
700239 RING SET
700240 GASKET
854043 BELTGUARD
854044 BELTGUARD
854045 ENGINE
854046 AIR TANK
