Schaerer Coffee Art Plus Touch Configuration guide

DAILY CLEANING INSTRUCTIONS - Coffee Art Plus Touch

CONTINUE

2. ► 3. ►

4. ►

7. ►

5. ►

8. ►

6. ►

Read and follow the instructions carefully before you begin the daily cleaning procedure. This procedure

should be performed on a daily basis or when prompted by the machine display. Never reach into the

machine or under the coffee spout during the automatic cleaning cycle!

When the “Start cleaning” message appears on the screen, follow the machine prompts to initial the clean cycle.

Note: In some congurations, the machine will automatically initiate the cleaning cycle after two hours of the “Start cleaning” message

appears. During that time all product buttons will be locked until the procedure is completed.

1. ►

• Use only Schaerer cleaning supplies

for this procedure.

• Fill large steaming pitcher with

16oz of water and mix in (1oz/30ml)

Schaerer Steam Wand Cleaner.

• Submerge steam wand into steam-

ing pitcher and press the LATTE

STEAM icon to heat solution. After

steam wand shuts off automatically

then let it soak for 5 minutes.

• When the “Start cleaning” message

appears on the screen, press “OK”

and move to the next step.

Note: The message may or may not ap-

pear, depending on programming.

• Immediately remove grounds bin

within 6 seconds. Empty cof-

fee grounds into trash can. Wash,

rinse, sanitize bin and set aside.

• Press the icon to go into the

service menu.

• In some congurations, this icon

may be hidden. If hidden, press and

hold the same area (bottom left cor-

ner) for 3-5 seconds. Service menu

will appear.

• Remove metal shield above

grounds bin and set aside.

• Select “Cleaning”

Item #12-MAB-SU1DN-06 Item #65221

Item #67409

9. ►

• Use large cleaning brush to wipe cof-

fee grounds from brew unit and sur-

rounding areas into drip tray.

Schaerer USA Corporation

15501 Red Hill Ave. STE 200

Tustin, CA 92780

www.schaererusa.com | 888.989.3004

Coffee Art Plus Touch Daily Cleaning | 09.2018 | v01

TO ORDER CLEANING SUPPLIES PLEASE CALL 888.989.3004

10. ► 11. ► 12. ►

• Press “Continue” on the screen to

activate cleaning cycle.

Cleaning runs (4:33 min.)

• Put back metal shield and slide cof-

fee grounds bin back into place.

• Lift dome lid and drop in one Schae-

rer cleaning tablet. Close lid after

dropping tablet.

• Press “OK” on the screen.

13. ► 15. ►

• Rell beans if necessary.

• Press “Continue” to return to

normal operating mode.

• Submerge steam wand into cold

water once to rinse, then discard

water. Wipe steam wand with a

clean, damp cloth.

14. ■

16. ■

• When automated cleaning cycle is

complete, empty pitcher into drip

tray. Wipe steam wand with a thick,

clean, damp cloth. Be careful,

wand will be very hot!

• After wiping off wand, point it toward

drip tray and purge by pressing the

button.
