Sanyo MBR-1404G User manual

MBR-1404G

MBR-1404GR

Blood Bank Refrigerator

INSTRUCTION MANUAL

MBR-1404GR

Note:

1. No part of this manual may be reproduced in any form without the expressed written

permission of SANYO.

2. The contents of this manual are subject to change without notice.

3. Please contact SANYO if any point in this manual is unclear or if there are any

inaccuracies.

CONTENTS

PRECAUTIONS FOR SAFE OPERATION P. 2

CAUTIONS FOR USAGE P. 7

ENVIRONMENTAL CONDITIONS P. 8

REFRIGERATOR COMPONENTS P. 9

INSTALLATION P. 13

BEFORE COMMENCING OPERATION P. 15

REMOTE ALARM TERMINAL P. 15

START-UP OF UNIT P. 16

OPERATING INSTRUCTIONS P. 17

ROUTINE MAINTENANCE P. 19

TROUBLESHOOTING P. 22

DISPOSAL OF UNIT P. 22

SPECIFICATIONS P. 23

PERFORMANCE P. 23

SAFETY CHECK SHEET P. 24

PRECAUTIONS FOR SAFE OPERATION

It is imperative that the user complies with this manual as it contains

important safety advice.

Items and procedures are described so that you can use this unit correctly and safely.

If the precautions advised are followed, this will prevent possible injury to the user and

any other person.

Precautions are illustrated in the following way:

WARNING

Failure to observe WARNING signs could result in a hazard to personnel

possibly resulting in serious injury or death.

CAUTION

Failure to observe CAUTION signs could result in injury to personnel and

damage to the unit and associated property.

Symbol shows;

this symbol means caution.

this symbol means an action is prohibited.

this symbol means an instruction must be followed.

Be sure to keep this manual in a place accessible to users of this unit.

< Label on the unit >

This mark is labeled on the cover in which the electrical components of high voltage are

enclosed to prevent the electric shock.

The cover should be removed by a qualified engineer or a service personnel only.

PRECAUTIONS FOR SAFE OPERATION

Do not use the unit outdoors. Current leakage or electric shock may result if the unit is exposed to

rain water.

Only qualified engineers or service personnel should install the unit. The installation by

unqualified personnel may cause electric shock or fire.

Install the unit on a sturdy floor. If the floor is not strong enough or the installation site is not

adequate, this may result in injury from the unit falling or tipping over.

Never install the unit in a humid place or a place where it is likely to be splashed by water.

Deterioration of the insulation may result which could cause current leakage or electric shock.

Never install the unit in a flammable or volatile location. This may cause explosion or fire.

Never install the unit where acid or corrosive gases are present as current leakage or electric

shock may result due to corrosion.

Use a dedicated power source as indicated on the rating label attached to the unit. Ensure that a

suitable fuse of adequate amperage is used to allow for compressor start up.

Remove dust from the power supply plug before inserting in a power source. A dusty plug or

improper insertion may pose a hazard.

Use a power supply outlet with ground (earth) to prevent electric shock. If the power supply

outlet is not grounded, it will be necessary to install a ground by qualified engineers.

Never ground the unit through a gas pipe, water main, telephone line or lightning rod. Such

grounding may cause electric shock in the case of an incomplete circuit.

Do not insert metal objects such as a pin or a wire into any vent, gap or any outlet for inner air

circulation. This may cause electric shock or injury by accidental contact with moving parts.

Never store volatile or flammable substances in this unit. This may cause explosion or fire.

Never store corrosive substances in this unit. This may lead to damage to the inner components

or electric parts.

Do not pull out more than 2 drawers (for MBR-1404GR) at the same time when storing or taking

out of the stocked material. This may cause injury by falling or tipping of the unit if something heavy

items are stored.

WARNING

PRECAUTIONS FOR SAFE OPERATION

If this unit is to be used for storing poisons, radioactive material or other harmful products,

ensure that it is in a safe area. Failure to do so may lead to an adverse effect on the health of

personnel in the area and the local environment. In this case, a request for repair or maintenance

will necessitate a safety check sheet for maintenance personnel.

Disconnect the power supply to the unit prior to any repair or maintenance of the unit in order to

prevent electric shock or injury.

Ensure you do not inhale or consume medication or aerosols from around the unit at the time of

maintenance. These may be harmful to your health.

Never splash water directly onto the unit as this may cause electric shock or short circuit.

Never disassemble, repair, or modify the unit yourself. Any such work carried out by an

unauthorized person may result in fire or injury due to a malfunction.

Disconnect the power supply plug before replacement of the florescent light to prevent electric

shock.

Disconnect the power supply plug if there is something wrong with the unit. Continued

abnormal operation may cause electric shock or fire.

If the unit is to be stored unused in an unsupervised area for an extended period, ensure that

children do not have access and that doors cannot be closed completely.

The disposal of the unit should be undertaken by appropriate personnel. Remove doors to

prevent accidents such as suffocation.

Prepare a safety check sheet when you request any repair or maintenance for the safety of service

personnel.

WARNING

PRECAUTIONS FOR SAFE OPERATION

Select a level and sturdy floor for installation. This precaution will prevent the unit from tipping.

Improper installation may result in water spillage or injury from the unit tipping over.

Do not install the unit at a place with the possibility of something falling on it. The electric

parts are located in the upper part of this unit.

Connect the unit to a power source as indicated on the rating label attached to the unit. Use

of any other voltage or frequency other than that on the rating label may cause fire or electric shock.

Fix the shelves securely. Incomplete installation may cause injury or damage.

When removing the plug from the power supply outlet, grip the power supply plug, not the cord.

Pulling the cord may result in electric shock or fire by short circuit.

Never damage or break the power supply plug or cord. Do not use the supply plug if its cord

is loose. This may cause fire or electric shock.

Do not touch any electrical parts such as the power supply plug or any switches with a wet hand.

This may cause electric shock.

Do not put a container with water or heavy articles on the unit. Injury may be caused if the

articles fall. Current leakage or electric shock may result from the introduction of spilled water into

electrical components.

Do not climb onto the unit. This may cause damage to the unit and cause it to tip over.

Hold the handle when closing the door. This will reduce the likelihood of a trapped finger.

Do not lean on the door. This may cause injury if the unit tips over.

Never lean or press on the glass. Excessive force may cause injury of the glass breaks.

Check the filter mentioned in this manual and clean it as necessary. A dusty filter may cause

temperature rise or failure.

Do not touch the condenser directly when the filter is removed for cleaning. This may cause injury

due to hot surface.

Disconnect the power supply plug before moving the unit. Take care not to damage the power

cord. A damaged cord may cause electric shock or fire.

CAUTION

PRECAUTIONS FOR SAFE OPERATION

Dispose of any water in the evaporation tray completely before moving the unit. Spilled or

splashed water may cause current leakage or electric shock.

Be careful not to tip the unit over during movement to prevent damage or injury.

Disconnect the power plug when the unit is not used for long periods.

Do not put the packing plastic bag used in the packaging within reach of children as suffocation

may result

CAUTION

CAUTIONS FOR USAGE

1. Adequate space should be provided between the items inside the unit to allow air circulation.

2. Never store corrosive materials such as acid or alkali unless the container is completely sealed up.

Corrosion may lead to failure of the unit in time.

3. In case condensation forms on the front glass or frame due to a high humidity environment, wipe if off

with a soft and dry cloth.

4. Do not clean the unit with scrubbing brushes, acid, thinner, solvents powdered soap, cleanser or hot

water. These agents can scratch the paint or cause it to peel. Plastic and rubber parts can be easily

damaged by these materials, especially solvents. When a neutral detergent is used to clean the unit,

rinse thoroughly with a cloth soaked in clean water.

ENVIRONMENTAL CONDITIONS

This equipment is designed to be safe at least under the following conditions (based on the IEC 1010-1):

1. Indoor use;

2. Altitude up to 2000 m;

3. Ambient temperature 5oC to 40oC

4. Maximum relative humidity 80% for temperature up to 31oCdecreasing linearly to 50% relative

humidity at 40oC;

5. Mains supply voltage fluctuations not to exceed ±10% of the nominal voltage;

6. Other supply voltage fluctuations as stated by the manufacturer.

7. Transient overvoltages according to Installation Categories (Overvoltage Categories) II; For mains

supply the minimum and normal category is II;

8. Pollution degree 2 in accordance with IEC 664.

REFRIGERATOR COMPONENTS

MBR-1404GR

91011

12 13 1415
