Sanyo XACTI VPC-SH1EX User manual

Dual Camera

VPC-SH1EX

VPC-SH1

VPC-SH1GX

VPC-SH1PX

VPC-SH1TA

QUICK GUIDE

Printed in Vietnam

1AG6P1P5616-- SG412EX, U, GX, PX, TA (1209AB-SD)

STEP 1

RECORD A VIDEO CLIP

If the image is not captured...

Is there enough power left in the battery? Recharge

the battery pack.

(See “Insert the battery pack” on the reverse side.)

Turn on the camera.

Press the [O]

button.

You can capture a still

image while recording

a video clip.

During video clip

recording, press the

[O] button to capture

a still image of the

scene at that instant.

STEP 2

CAPTURE A STILL IMAGE

Press the REC/PLAY

button.

The last recorded

image is displayed.

Select the image to

play back.

Toggle the SET button

left, right, up or down

to move the orange

frame to the ﬁle you

wish to play back.

Press the SET button.

The image you

selected in step

displayed fullscreen.

If a video clip was

selected, playback

begins.

STEP 3

VIEWING IMAGES

Turn on the camera.

Press the ON/OFF

button for at least

1 second.

If the screen to set

the date and time

appears, press the

MENU button 2

times to cancel it.

Press the [R]

button to begin

recording a video

clip.

To stop recording,

press the [R]

button again.

STEP 4

DELETING IMAGES

Did your photos turn out the way you hoped?

Even if you make a mistake, it’s easy to delete the pictures you aren’t

satisﬁed with. Unlike ﬁlm cameras, with a dual camera you can take

all the photos you want, keep the ones you like and delete the rest.

Display the ﬁle that

you want to delete.

Toggle the SET

button up.

The Conﬁrm

Delete Screen

appears.

Select “DELETE”,

and press the SET

button.

The current image

is deleted.

To return to the

Playback Screen,

select “EXIT”, and

press the SET

button.

COPYING FILES TO A COMPUTER

(WINDOWS XP)

Start your computer, and use the supplied USB

interface cable to connect your camera to the

computer.

Connect the camera’s USB/AV terminal to the

computer’s USB connector.

The USB Connection Screen appears on the

camera’s monitor.

Select “COMPUTER”, and press the SET button.

The screen to select the connection mode

appears.

Select “CARD READER”, and press the SET

button.

Select an action.

Select the desired procedure.

Copy the desired camera ﬁle(s) to the computer.

CAUTION

To access the data in the camera’s internal memory...

Remove the card from the camera.

A card is not included with your camera. Please

purchase a commercially sold card.

Monitor unit

1Open

Card

3Insert.

Card slot cover

2Pull and rotate.

4Insert the card until it

clicks into place

After inserting the

card, colse the card slot

cover.

INSTALL THE BATTERY PACK AND CARD

After installing the battery pack, connect the AC

adaptor (supplied) to the camera's DC IN

terminal and charge the battery.

Insert the battery pack

Battery pack

Card slot

Insert the card
