CONTENTS
GENERAL DESCRIPTION
1 Introduction .................................................................................... 2
2 Specifications.......................................................................................... 3
GENERAL INSTRUCTIONS
1 Selection of the Range ..................................................................... 4
2 Test Lead Connections ..................................................................... 4
3 Replacement of atteries ........................................................ 5
4 Reading the Scale................................................................................. 5
5 Meter Movement Protection............................................................. 5
6 Other Precautions................................................................................. 7
OPERATION
1 DC Voltage Measurements ............................................................. 8
2 AC Voltage Measurements
.............................................................
11
3 Internal Resistance of the Voltage Range .................................14
4 DC Current Measurements
.............................................................
16
5 Resistance Measurements
.................................................................
19
6 Volume Level Measurements .........................................................23
7 Capacity and High Resistance Measurements
............................
28
SUPPLEMENTARY DATA
1 Schematic Diagram ..............................................................................31
2 Arrangement of Parts (Rear View).................................................32
3 List of Main Parts ..............................................................................33
1
