IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS - PLEASE READ ENTIRE MANUAL BEFORE USING THIS PRODUCT

Thank you for choosing a Sanus Foundations Component Series Rack Accessory.

ÙThe CFR518RR is designed to work with the CFR518 Component Series Rack.

ÙThe CFR524RR is designed to work with the CFR524 Component Series Rack.

ÙThe CFR535RR is designed to work with the CFR535 Component Series Rack.

CAUTION:

CAUTION: Avoid potential personal injuries and property damage!

ÙAll doors and accessories must be grounded.

ÙDo not use this product for any purpose not explicitly specied by Sanus Systems.

ÙIf you do not understand these instructions, or have doubts about the safety of the installation, assembly or use of this product, contact Sanus Systems

Customer Service or call a qualied contractor.

ÙSanus Systems is not responsible for damage or injury caused by incorrect assembly or use.

6901-002033 <00> 3



Choose an Option Do Not Loosen/Tighten Note This End Up.

LEGEND

WARNING This product

contains small items that

could be a choking hazard

Tools Required Caution/Warning Repeat Step Heavy! Assistance Required.

OPT

Electrical Warning Troubleshooting and

Maintenance Tip Hazard Optional

6901-002033 <00>

Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Sanus

Systems Customer Service. Never use damaged parts!

Supplied Parts and Hardware

[03] x 8 [04] x 8[01] x 1 [02] x 1

6901-002033 <00> 5

Install Rear Rack Rails

Install the rails into any of the slots provided.

For the CFR518 and CFR524, be sure to install the rails to the top (T), bottom (B), right (R), and left (L) support bars evenly.

For the CFR535, be sure to install the rails to the top (T), bottom (B), middle (M), right (R), and left (L) support bars evenly.

Step 1

(B)

(R)

(L)

(T)

CFR518 & CFR524

6901-002033 <00>

Milestone AV Technologies and its aliated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete. However, Milestone makes no claim that the information

contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in connection with the installation or use of this product. The information contained in this

document is subject to change without notice or obligation of any kind. Milestone makes no representation of warranty, expressed or implied, regarding the information contained herein. Milestone assumes no

responsibility for accuracy, completeness or suciency of the information contained in this document.

(B)

(R)

(L)

(T)

(M)

CFR535
