SANUS VuePoint F180d User manual

F180d INSTRUCTION MANUAL

Scan for easy install video

san.us/964

We’ll Make It Stress-Free

If you have any questions along the way, just give us a call.

1-888-333-9952. We’re ready to help!

Drywall with

wood studs? Perfect!

Does your TV weigh more than 100 lbs. (45.4 kg) including accessories?

—

Perfect!

Yes

—

This mount is NOT compatible. Visit vuepoint.sanus.com or call 1-888-333-9952 to ﬁnd a compatible mount.

100 lbs.

(45.4 kg)

IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE

1/2 in.

(13 mm)

Ready to begin?

Please read through these instructions completely to be sure you’re comfortable with this easy install process. Also check your TV

owner’s manual to see if there are any special requirements for mounting your TV.

If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact

Customer Service at 1-888-333-9952.

Do you have all of the tools needed?

Before getting started, let’s make sure this mount is perfect for you!

CAUTION: Avoid potential personal injuries and property damage!

●This product is designed for use in wood studs - DO NOT install into drywall alone

●The wall must be capable of supporting ﬁve times the weight of the TV and mount combined

●Do not use this product for any purpose not explicitly speciﬁed by manufacturer

●Manufacturer is not responsible for damage or injury caused by incorrect assembly or use

7/32 in.

(5.5 mm)

Wood

What is your wall made of?

Unsure? Call 1-888-333-9952

Stud Finder Awl Pencil Level Phillips

Screwdriver Tape

Measure Wood

Drill Bit

Drill ScissorsSocket

15.75

40.00

2.95

7.50

3.94

10.00

23.62

60.00

7.87

20.00

2.95

7.50

3.94

10.00

7.87

20.00

15.75

40.00

11.81

30.00

11.81

30.00

12.00

30.49

12°

11°

2.85

7.24

15.00

38.10

0.38

0.97

OFFSET

3.00

7.61

OFFSET

Dimensions

in.

[cm]

NOTE: TV shifts 3 in. (7.61 cm)

to the right or left when in the home

position. Consider this when select-

ing the location of your wall mount.

M5 x 12mm

M6 x 12mm M6 x 35mm

M5 x 35mm

M6 x 20mm

M8 x 16mm

M8 x 12mm M8 x 35mm

M8 x 20mm

NOTE: Not all hardware included will be used.

WARNING: This product contains small items that could be a choking hazard if swallowed.

Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to

your dealer; contact Customer Service. Never use damaged parts!

Supplied Parts and Hardware

STEP 1 Parts and Hardware

TV Bracket

TV Screws

Washers Spacers

M6/M8M5

TV Bracket

Extenders

TV Bracket Interface Screws

04 x4 05 x4

07 x4

08 x4

06 x4

12 x4

10 x4 13 x4

09 x4 11 x4 14 x4

03 x8

x1 02 x4

1/4-20 x 3/4 in.

10-24 x 1 in.

5⁄16 in. x 2 3⁄4 in.

STEP 2 Parts and Hardware STEP 3 Parts and Hardware

.695 x .350 x.075 in.

16 x1

15 x1

19 x1

Wall Plate

Wall Plate Template

Lag Bolts

Lag Bolt Washers

18 x4

20 x2

21 x1

Locking Screw

Wall plate Screw

Arm Assembly

17 x4

Cable Ties

18 in.

(457.2 mm)

2.5 in.

(63.4 mm)

Cable Tunnel Kit

Additional Hardware

STEP 1 Attach TV Bracket to TV

1-1 Measure Your TV Hole Pattern

inches

inch dimensions are approximate

Measure the width and height of your TV hole pattern in cm.

Record your measurements:

Width__________cm x Height ________ cm

75 mm = 7.5 cm ≈ 3 in.

100 mm = 10 cm ≈ 4 in.

200 mm = 20 cm ≈ 7 7/8 in.

300 mm = 30 cm ≈ 11 3/4 in.

400 mm = 40 cm ≈ 15 3/4 in.

1-2 Assemble Your TV Bracket

Determine which TV bracket configuration to use, A, B, C, or D

based on your TV hole pattern measurements.

A7.87

[20.0]

7.87

[20.0]

3.94

[10.0]

3.94

[10.0]

15.75

[40.0]

15.75

[40.0]

3.0

[7.5]

3.0

[7.5]

in.

[cm]

in.

[cm]

Assemble TV bracket extenders 02 onto TV bracket 01 as illustrated.

Secure using eight screws 03 in the corner holes shown.

30.0 x 30.0

40.0 x 40.0

11.81

[30.0]

11.81

[30.0]

11.81

[30.0]

15.75

[40.0]

40.0 x 30.0

These smaller hole patterns only use TV bracket 01 .

Do not use the four TV bracket extenders 02 and eight screws 03 .

7.5 x 7.5

10.0 x 10.0

20.0 X 20.0

Assemble TV bracket extenders 02 onto TV bracket 01 as illustrated.

Secure using eight screws 03 in the corner holes shown.

60.0 x 40.0

C40.0 x 20.0

20.0 x 40.0

in.

[cm] in.

[cm]

Assemble TV bracket extenders 02 onto TV bracket 01 as illustrated.

Secure using eight screws 03 in the corner holes shown.

15.75

[40.0]

15.75

[40.0]

15.75

[40.0]

7.87

[20.0]

7.87

[20.0]

23.62

[60.0]

M5 M6 M8

1-3 Select TV Screw Diameter 1-4 Select TV Screw Length

Hand thread screws into the threaded inserts

on the back of your TV to determine which

screw diameter (M5, M6, or M8) to use.

FLAT BACK ROUND BACK CABLESINSET HOLES

If your TV has a flat back AND you want your TV closer to the

wall, use the shorter screws.

Spacers and longer screws are supplied to accommodate:

●Round/irregular back TVs

●TVs with inset mounting holes

●Extra space needed for cables

Too Long

CAUTION:

Verify adequate thread

engagment with the screw or

screw/spacer combination.

-Too short will not hold the TV.

-Too long will damage the TV.

Too Short

Correct

Standard configurations

are shown. For special

applications, or if you

are uncertain about your

hardware selection, contact

Customer Service at 1-888-

333-9952.
