Sanus accents AMF112 User manual

Milestone AV Technologies

6436 City West Parkway

Eden Prairie, MN 55344 USA

Customer Service

Americas: 800-359-5520 • 651-484-7988 • [email protected]om

Europe, Middle East, and Africa: +31 (0) 495 580 852 • europe[email protected]om

Asia Paciﬁc: 86 755 8996 9226 • sanus.ap@milestone.com

accents.sanus.com

All other brand names or marks are used for identiﬁcation purposes and are trademarks of their respective owners.

(6904-002010<01>)

Scan here to view

product demo and install

videos or visit san.us/103

AMF112 Instruction Manual

6904-002010 <01>

16.54

420.0

8.25

209.6

15.77

400.6

100mm to 420mm

18.70

475.0

5.00

127.0

in.

[mm]

12.02

305.4

3.02

76.8

15° 15°

Technical Specications

Specications

ÙWeight capacity-DO NOT EXCEED: 27 kg (60lb) includes TV and any accessories

ÙTilt: ± 15°

CAUTION: Avoid potential personal injuries and property damage!

ÙDo not use thisproduct for any purpose not explicitly specied by manufacturer.

ÙThewall must becapableof supporting vetimes theweight of themonitor and mount combined.

ÙThisproduct isnot designed for use in metal stud walls!

ÙIf you do not understand these instructions, or havedoubtsabout thesafety of theinstallation, assembly or use of this

product, contact manufacturer Customer Serviceor call a qualied contractor.

ÙManufacturer isnot responsiblefor damageor injury caused by incorrect assembly or use.

IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE

Required Tools

10mm

(3/8 in.)

5.5mm

(7/32 in.)

13mm

(1/2 in.)

6904-002010 <01> 3

5/32 in. 3/16 in.

[01] x 1

[02] x 1 [03] x 1

[04] x 1

[05] x 1

[20] x 1 [21] x 1

[23] x 1 [24] x 1

[22] x 4

[06] x 3 [07] x 3 [08] x 3

[09] x 4 [10] x 4

[11] x 4 [12] x 4 [13] x 4

[14] x 4 [15] x 4

[16] x 4 [17] x 4

[19] x 4[18] x 8

M4 M6/M8

M8 x 16mm M8 x 35mm

M6 x 12mm M6 x 20mm M6 x 35mm

M4 x 12mm M4 x 30mm

5/16 x 2¾ in.

8-32 x 3/8 in. 8-32 x 9/16 in.

WARNING: This product contains small items that could be a choking hazard if swallowed.

Beforestarting assembly, verify all partsareincluded and undamaged.If any partsaremissing or damaged, do not return the

damaged item to your dealer; contact Customer Service. Never use damaged parts!

NOTE: M4, M6, or M8 describes thediameter, mm describes thelength of screwsthat arelabeled M# X ##mm.Not all

hardwareincluded will beused.

Supplied Parts and Hardware

6904-002010 <01>

Beforeyou begin, hand thread screwsinto thethreaded insertson theback of your TV to determinethecorrect screw

diameter (M4, M6, or M8).Verify that thereareadequatethreadsto securethebracketsto themonitor.If you encounter

resistance, stopimmediately and contact customer service.

CAUTION: Avoid potential personal injuries and property damage! Use theshortest screw and spacer combination to

accommodateyour needs. Using hardwarethat istoo long may damageyour monitor’sinternal components.

1Install TV Brackets

6904-002010 <01> 5

Ensurethat thebracket islevel on theback of theTV.If you need extra spaceto accommodatecables, recesses, or protrusions,

see theinstallation option that uses spacers.

M4 M6

[02]

[03]

[03][02]

[02]

[18] [19]

[19]

[09]

[14]

[11]/[12]

[02]

1-1 For TVs with a at/unobstructed back

6904-002010 <01>

M4 M6

Ensurethat thebracketsarelevel on theback of theTV.Standard congurationsareshown.For special applications, or if you

areuncertain about your hardwareselection, contact Customer Service.

[02]

[03]

[03][02]

[02] [02]

[02]

[18] [19]

[19]

[10]

[13]

[15]

[18]

[16]

[17]

1-1 For TVs with an irregular/obstructed back

6904-002010 <01> 7

1.Slidethehorizontal brackets[04] and [05] onto thevertical brackets[02] and [03].Makesurethat they areevenly spaced

left to right.

2. Install screws[22] to lock horizontal brackets[04] and [05] in position.

[02]

[03]

[04]

[05]

[22]

1-2 Attach horizontal brackets

6904-002010 <01>

1< 16 mm

(5/8 in.)

[01]

75 mm

(3 in.)

[07]

[08]

1.Locatestud.Verify thecenter of thestud with an awl or

thin nail or use an edgeto edgestud nder.

CAUTION:

To avoid potential injuries or property

damage:

ÙAny material covering thewall must not exceed 16

mm (5/8 in.).

ÙMinimum wood stud size: common 2x 4 in.

(nominal 1.5 x 3.5 in.)

2. Level thewall plate[01] and mark theholelocations.

3.Drill pilot holes asillustrated.

CAUTION:

To avoid potential injuries or property

damage: Pilot holes MUST bedrilled to a depth of 75

mm (3 in.), using a 5.5 mm (7/32in.) diameter drill bit.

2Mount the Wall Plate

Wood Stud 5.5 mm

(7/32 in.)

13 mm

(1/2 in.)

4.Tighten thelag bolts[08] only until thewashers[07] are

pulled rmly against thewall plate[01].

CAUTION:

Improper use could reducetheholding

power of thelag bolt.To avoid potential injuries or

property damage: DO NOT over-tighten thelag bolts

[08].

6904-002010 <01> 9

2Mount the Wall Plate

Solid Concrete and Concrete Block 10mm

(3/8 in.)

13mm

(1/2 in.)

1.Level wall plateand mark theholelocations.

CAUTION:

To avoid potential injuries or property

damage:

ÙMount wall platedirectly onto theconcretesurface.

ÙMinimum solid concretethickness: 8 in.

ÙMinimum concreteblock size: 8 x 8 x 16 in.

2. Drill pilot holes asillustrated.

CAUTION:

To avoid potential injuries or property

damage:

ÙPilot holes MUST bedrilled to a depth of 75 mm (3

in.), using a 10mm (3/8 in.) diameter drill bit.

ÙNever drill into themortar between blocks.

[01]

[01] [06]

[06]

[07]

[08]

75 mm

3 in.

3.Insert lag bolt anchors[06].Besuretheanchors[06]

areseated ush with theconcretesurface.

4.Tighten thelag bolts[08] only until thewashers[07] are

pulled rmly against thewall plate[01].

CAUTION:

Improper use could reducetheholding

power of thelag bolt.To avoid potential injuries or

property damage: DO NOT over-tighten thelag bolts

[08].

6904-002010 <01>

[21]

[20]

[05]

[04]

[01]

3 Hang the TV/Bracket Assembly onto

the Swing Arm

HEAVY! You will need assistancewith thisstep.

Level theTV/bracket assembly and install thewasher[20] and retaining screw [21].

CAUTION: Avoid potential injuries or property damage! Besureto install thewasher[20] and retaining screw [21]

securely.Thiswill prevent theTV from separating away from themount.
