Samsung SC52 Series User manual

Vacuum Cleaner

user manual

imagine the possibilities

Thank you for purchasing a Samsung product.

✻Before operating this unit, please read the instructions carefully.

✻For indoor use only. English

SC52** SERIES

DJ68-00542X-00.indb 1 2016. 9. 20. �� 11:52

02_ safety information

safety information

SAFETY INFORMATION

• Before operating the appliance, please read this manual thoroughly and

retain it for your reference.

• Because these following operating instructions cover various models,

the characteristics of your vacuum cleaner may differ slightly from those

described in this manual.

CAUTION/WARNING SYMBOLS USED

WARNING

Indicates that a danger of death or serious injury exists.

CAUTION

Indicates that a risk of personal injury or material damage exists.

OTHER SYMBOLS USED

Represents something you must NOT do.

Represents something you must follow.

Indicates that you must disconnect the power plug from the socket.

This vacuum cleaner is designed for household use only.

Do not use this vacuum cleaner to clean building waste and debris, toner

of laser printer. Regularly keep the filters in clean conditions to prevent of

collecting fine dust in them. Dry carpet cleaners or fresheners, powders and

fine dust such as flour should be only vacuumed in very small amounts.

Always clean the dust bin & filters after vacuuming them.

Do not use this vacuum cleaner with any of the filters or dust bin removed.

Do not use worn, deformed or damaged filters.

Always install the filters in the correct position as shown in this manual.

Failure to meet these requirements could cause damage to the internal parts

and void your warranty. Never twist micro filter after washing. It can be a

reason of deformation or damage filter.

If filter deformed or damaged please replace the filter (it can be a reason of

penetration of dust and debris into motor).

Please insert filter properly without gap between filter and cover filter (it can

be a reason of penetration of dust and debris into motor).

WARNING

DJ68-00542X-00.indb 2 2016. 9. 20. �� 11:52

safety information _03

safety information

IMPORTANT SAFEGUARDS

1. Read all instructions carefully. Before switching on,

make sure that the voltage of your electricity supply is

the same as that indicated on the rating plate on the

bottom of the cleaner.

2. WARNING : Do not use the vacuum cleaner when rug

or floor is wet.

Do not use to suck up water.

3. Do not use the vacuum cleaner without a dust bag.

Change the dust bag before it is full in order to

maintain the best efficiency.

4. Slide to the Stop(or Min)position before inserting a plug

into the electrical outlet.

5. Do not use the vacuum cleaner to pick up matches,

live ashes or cigarette butts.

Keep the vacuum cleaner away from stoves and other

heat sources. Heat can deform and discolour the

plastic parts of the unit.

6. Avoid picking up hard, sharp objects with the vacuum

cleaner as they may damage the cleaner parts. Do not

stand on the hose assembly. Do not put weight on the

hose.

Do not block the suction or the exhaust port.

7. Switch the vacuum cleaner off on the body of the

machine before unplugging from the electrical outlet.

Disconnect the plug from the electrical outlet before

changing the dust bag or dust container. To avoid

damage, please remove the plug by grasping the plug

DJ68-00542X-00.indb 3 2016. 9. 20. �� 11:52

04_ safety information

itself, not by pulling on the cord.

8. This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

9. Children shall not play with the appliance. Cleaning

and user maintenance shall not be made by children

withoutsupervision.

10. The plug must be removed from the socket outlet

before cleaning or maintaining the appliance.

11. The use of an extension cord is not recommended.

12. If your vacuum cleaner is not operating correctly,

switch off the power supply and consult an authorized

service agent.

13. If the supply cord is damaged, it must be replaced

by the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard.

14. Don’t carry the vacuum cleaner by holding the hose.

Use the handle on the vacuum cleaner set.

15. Unplug the cleaner when not in use. Turn off the power

switch before unplugging.

For information on Samsung’s environmental commitments

and product specific regulatory obligations e.g. REACH

visit: samsung.com/uk/aboutsamsung/samsungelectronics/

corporatecitizenship/data_corner.html

DJ68-00542X-00.indb 4 2016. 9. 20. �� 11:52

contents _05

contents

ASSEMBLING THE CLEANER

OPERATING THE CLEANER

07 ON/OFF Switch

07 Power Cord

08 Power-Control

08 Using & assembling the strap

(Optional)

MAINTAIN TOOLS AND FILTER

09 Using accessory

10 Maintain floor tools

11 Cleaning the cyclone filter (Optional)

11 Dust full indicator

12 Changing the dust bag

12 Cleaning inlet filter

13 Cleaning the outlet filter

TROUBLESHOOTING

DJ68-00542X-00.indb 5 2016. 9. 20. �� 11:52

06_ assembling

assembling the cleaner

For storage, park the floor nozzle.

OPTION

Features may vary according to model.

DJ68-00542X-00.indb 6 2016. 9. 20. �� 11:52

operating _07

02 OPERATING

operating the cleaner

ON/OFF SWITCH

1) BODY CONTROL TYPE 2) ON/OFF TYPE

• When removing the plug from the electrical outlet, grasp the plug, not the

cord.

POWER CORD

CAUTION

DJ68-00542X-00.indb 7 2016. 9. 20. �� 11:52

08_ operating

operating the cleaner

POWER-CONTROL

BODY-CONTROL TYPE / ON/OFF TYPE

• HOSE

To reduce suction for cleaning draperies,

small rugs, and other light fabrics, pull

the tap air until the hole is open.

• BODY (BODY-CONTROL TYPE ONLY)

MIN = For delicate surface e.g. net

curtains.

MAX = For hard floors and heavily soiled

carpets.

USING & ASSEMBLING THE STRAP (OPTIONAL)

This appliance is designed to be

conveniently carriedon your waist

using the belt-strap accessory.When

cleaning steps, curtains, shelves, etc,

you cancarry the unit with the strap over

your shoulder.

Insert the lockers into the hanger.

Detach the lockers by pushing them

down.

DJ68-00542X-00.indb 8 2016. 9. 20. �� 11:52

maintain _09

03 MAINTAIN

maintain tools and filter

USING ACCESSORY

Pipe (Option)

• Adjust the length of the telescopic pipe by

sliding the length control button located in the

center of the telescopic pipe back and forth.

• To check for blockages, separate the

telescopic pipe and adjust to shorten.

This allows for easier removal of waste

clogging the tube.

Accessory

• Dusting brush for furniture. shelves, books,

etc.

• Crevice tool for radiators, crevices, corners,

between cushions.

DJ68-00542X-00.indb 9 2016. 9. 20. �� 11:52

10_ maintain

maintain tools and filter

MAINTAIN FLOOR TOOLS

2-Step Brush (Option)

• Adjust the inlet lever according to the floor

surface.

• Remove waste matter

completely if the inlet is

blocked.

Carpet Cleaning Floor Cleaning

Pet Brush (Option)

For improved pick-up of pet hair and fibre on carpets.

Frequent vacuuming of hair or pet fur may cause a falling-off of the rotation due to

matters tangled around the drum. In this case, clean the drum with care.

Blanket brush (Option)

Clogs on turbine keep brush from turning, thus need to be unclogged as

follows. For picking up pet hair and fibre on upholstery and bed linen.

Remove waste matter completely when inlet is blocked.

Turn the lock button to ‘UNLOCK’, and remove waste

matter.

To reassemble, align the cover to the front of the main

body and close. After closing the cover, ensure that the

lock button is turned to the ‘LOCK’ position.

Use for bedclothes only. Be cautious not to

damage brush during unclogging.

Turbine

Brosse

WARNING

DJ68-00542X-00.indb 10 2016. 9. 20. �� 11:52
