Samsung SC45 Series User manual
imagine the possibilities
Thank you for purchasing a Samsung product.
Vacuum Cleaner
user manual
English
✻ Before operating this unit, please read the instructions carefully.
✻ For indoor use only.
SC45** Series
DJ68-00586B-06.indb 1 2017. 9. 4. �� 2:50
2_ safety information
safety information _3
safety information
SAFETY INFORMATION
• Before operating the appliance, please read this manual thoroughly and
retain it for your reference.
• Because these following operating instructions cover various models,
the characteristics of your vacuum cleaner may differ slightly from those
described in this manual.
CAUTION/WARNING SYMBOLS USED
WARNING Indicates that a danger of death or serious injury exists.
CAUTION Indicates that a risk of personal injury or material damage exists.
OTHER SYMBOLS USED
Represents something you must NOT do.
Represents something you must follow.
Indicates that you must disconnect the power plug from the socket.
WARNING
WARNING
DJ68-00586B-06.indb 2 2017. 9. 4. �� 2:50
2_ safety information
safety information _3
safety information
IMPORTANT SAFEGUARDS
1. Read all instructions carefully.
Before switching on, make sure that the voltage
of your electricity supply is the same as that
indicated on the rating plate on the bottom of the
cleaner.
2. WARNING: Do not use the vacuum cleaner when
rug or floor is wet. Do not use to suck up water.
3. Close supervision is necessary when any
appliance is used by or near children.
Do not allow the vacuum cleaner to be used as
a toy. Do not allow the vacuum cleaner to run
unattended at any time. Use the vacuum cleaner
only for its intended use as described in these
instructions.
4. Do not use the vacuum cleaner without a dust
bin. Empty the dust bin before it is full in order to
maintain the best efficiency.
5. Slide to the Stop (or Min) position before inserting
a plug into the electrical outlet.
6. Do not use the vacuum cleaner to pick up
matches, live ashes or cigarette butts.
Keep the vacuum cleaner away from stoves
and other heat sources. Heat can deform and
discolour the plastic parts of the unit.
DJ68-00586B-06.indb 3 2017. 9. 4. �� 2:50
4_ safety information
safety information _5
7. Avoid picking up hard, sharp objects with the
vacuum cleaner as they may damage the cleaner
parts. Do not stand on the hose assembly.
Do not put weight on the hose.
Do not block the suction or the exhaust port.
8. Switch the vacuum cleaner off on the body of the
machine before unplugging from the electrical
outlet. Disconnect the plug from the electrical
outlet before changing the dust bag or dust
container. To avoid damage, please remove the
plug by grasping the plug itself, not by pulling on
the cord.
9. This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
10. Children should be supervised to ensure that
they do not play with the appliance.
11. The plug must be removed from the socket
outlet before cleaning or maintaining the
appliance.
DJ68-00586B-06.indb 4 2017. 9. 4. �� 2:50
safety information _5
12. The use of an extension cord is not
recommended.
13. If your vacuum cleaner is not operating
correctly, switch off the power supply and
consult an authorized service agent.
14. If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similarly qualified person in order to
avoid a hazard.
15. Don’t carry the vacuum cleaner by holding the
hose.
Use the handle on the vacuum cleaner set.
16. Unplug the cleaner when not in use.
Turn off the power switch before unplugging.
17. For information on Samsung’s environmental
commitments and product specific regulatory
obligations e.g. REACH (WEEE, Batteries)
visit: samsung.com/uk/aboutsamsung/
samsungelectronics/corporatecitizenship/
data_corner.html
DJ68-00586B-06.indb 5 2017. 9. 4. �� 2:50
assembling the cleaner _7
6_ contents
ASSEMBLING THE CLEANER
07
07 Assembling the Cleaner
OPERATING THE CLEANER
08
08 On/Off Switch
08 Power cord
09 Power control
MAINTAIN TOOLS AND FILTER
10
10 Using accessory
11 Maintain floor tools
12 Emptying the dust bin
13 When to clean the dust pack
14 Cleaning the dust pack
15 Cleaning the outlet filter
TROUBLESHOOTING
16
contents
DJ68-00586B-06.indb 6 2017. 9. 4. �� 2:50
assembling the cleaner _7
01 ASSEMBLING THE CLEANER
assembling the cleaner
6_ contents
• Please do not press the button
of dust bin handle when carrying
machine.
OPTION
OPTION
• For storage, park the floor nozzle.
DJ68-00586B-06.indb 7 2017. 9. 4. �� 2:50
8_ operating the cleaner
operating the cleaner _9
operating the cleaner
ON/OFF SWITCH
CAUTION
• When removing the plug from the electrical outlet, grasp
the plug, not the cord.
1) BODY CONTROL TYPE 2) ON/OFF TYPE
POWER CORD
DJ68-00586B-06.indb 8 2017. 9. 4. �� 2:50
8_ operating the cleaner
operating the cleaner _9
02 OPERATING THE CLEANER
POWER-CONTROL
1) SLIDE CONTROL TYPE ONLY (OPTION)
• SLIDE TO THE STOP POSITION
Vacuum-cleaner switches off (stand by mode)
• SLIDE FORWARD TO MAX
Suction capacity increases smoothly up to
maximum.
- BODY (BODY-CONTROL TYPE ONLY)
MIN = For delicate surface e.g. net curtains.
MAX = For hard floors and heavily soiled carpets.
2) BODY-CONTROL TYPE / ON/OFF TYPE
- HOSE
To reduce suction for cleaning draperies, small rugs,
and other light fabrics, pull the tap air until the hole
is open.
DJ68-00586B-06.indb 9 2017. 9. 4. �� 2:50
10_ maintain tools and filter
maintain tools and filter _11
maintain tools and filter
PIPE (OPTION)
• Adjust the length of the telescopic pipe by sliding
the length control button located in the center of
the telescopic pipe back and forth.
USING ACCESSORY
• To check for blockages, separate the telescopic
pipe and adjust to shorten. This allows for easier
removal of waste clogging the tube.
ACCESSORY (OPTION)
• Dusting brush for furniture. shelves, books, etc.
• Crevice tool for radiators, crevices, corners, between
cushions.
DJ68-00586B-06.indb 10 2017. 9. 4. �� 2:50
