Samsung SC45 Series User manual
Vacuum Cleaner
user manual
English
SC45** Series
✻ Before operating this unit, please read the instructions carefully.
✻ For indoor use only.
Thank you for purchasing a Samsung product.
DJ68-00586J-02.indb 1 2017. 7. 13. �� 11:20
2_ safety information
safety information _3
safety information
SAFETY INFORMATION
WARNING
• Before operating the appliance, please read this manual thoroughly
and retain it for your reference.
WARNING
• Because these following operating instructions cover various models,
the characteristics of your vacuum cleaner may differ slightly from
those described in this manual.
CAUTION/WARNING SYMBOLS USED
WARNING Indicates that a danger of death or serious injury exists.
CAUTION Indicates that a risk of personal injury or material damage exists.
OTHER SYMBOLS USED
Represents something you must NOT do.
Represents something you must follow.
Indicates that you must disconnect the power plug from the socket.
DJ68-00586J-02.indb 2 2017. 7. 13. �� 11:20
2_ safety information
safety information _3
safety information
IMPORTANT SAFEGUARDS
1.
Read all instructions carefully. Before switching
on, make sure that the voltage of your electricity
supply is the same as that indicated on the
rating plate on the bottom of the cleaner.
2. WARNING: Do not use the vacuum cleaner
when rug or floor is wet.
Do not use to suck up water.
3. Close supervision is necessary when any
appliance is used by or near children. Do
not allow the vacuum cleaner to be used as
a toy. Do not allow the vacuum cleaner to
run unattended at any time. Use the vacuum
cleaner only for its intended use as described
in these instructions.
4. Do not use the vacuum cleaner without a
dust bin.
Empty the dust bin before it is full in order to
maintain the best efficiency.
5. Slide to the Stop(or Min)position before
inserting a plug into the electrical outlet.
6. Do not use the vacuum cleaner to pick up
matches, live ashes or cigarette butts.
Keep the vacuum cleaner away from stoves
DJ68-00586J-02.indb 3 2017. 7. 13. �� 11:20
4_ safety information
safety information _5
and other heat sources. Heat can deform
and discolour the plastic parts of the unit.
7. Avoid picking up hard, sharp objects with
the vacuum cleaner as they may damage
the cleaner parts. Do not stand on the hose
assembly. Do not put weight on the hose.
Do not block the suction or the exhaust port.
8. Switch the vacuum cleaner off on the body
of the machine before unplugging from the
electrical outlet. Disconnect the plug from the
electrical outlet before changing the dust bag
or dust container. To avoid damage, please
remove the plug by grasping the plug itself,
not by pulling on the cord.
9. This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
10. Children should be supervised to ensure
that they do not play with the appliance.
DJ68-00586J-02.indb 4 2017. 7. 13. �� 11:20
4_ safety information
safety information _5
11. The plug must be removed from the socket
outlet before cleaning or maintaining the
appliance.
12. The use of an extension cord is not
recommended.
13. If your vacuum cleaner is not operating
correctly, switch off the power supply and
consult an authorized service agent.
14. If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similarly qualified person in order
to avoid a hazard.
15. Don’t carry the vacuum cleaner by holding
the hose.
Use the handle on the vacuum cleaner set.
16. Unplug the cleaner when not in use. Turn
off the power switch before unplugging.
17. Do not use to suck up water.
18. Do not immerse in water for cleaning.
19. The hose should be checked regularly and
must not be used if damaged.
20. The vacuum cleaner handle contains
electrical connections the handle is not a
serviceable part.
21. The current carrying hose handle contains
DJ68-00586J-02.indb 5 2017. 7. 13. �� 11:20
contents _7
6_ safety information
electrical connections is not a serviceable
part by user.
22. Please contact the manufacturer or service
center for a replacement.
23. For information on Samsung’s
environmental commitments and product
specific regulatory obligations e.g. REACH
visit: samsung.com/uk/aboutsamsung/
samsungelectronics/corporatecitizenship/
data_corner.html
DJ68-00586J-02.indb 6 2017. 7. 13. �� 11:20
contents _7
contents
6_ safety information
ASSEMBLING THE CLEANER
08
08 Assembling the Cleaner
OPERATING THE CLEANER
09
09 On/Off Switch
09 Power cord
10 Power control
MAINTAIN TOOLS AND FILTER
11
11 Using accessory
12 Maintain floor tools
13 Emptying the dust bin
14 When to clean the dust pack
15 Cleaning the dust pack
16 Cleaning the outlet filter
TROUBLESHOOTING
17
DJ68-00586J-02.indb 7 2017. 7. 13. �� 11:20
operating the cleaner _9
8_ assembling the cleaner
assembling the cleaner
• Please do not press the button
of dust bin handle when carrying
machine.
OPTION
OPTION
• For storage, park the floor nozzle.
DJ68-00586J-02.indb 8 2017. 7. 13. �� 11:20
operating the cleaner _9
02 OPERATING THE CLEANER
operating the cleaner
8_ assembling the cleaner
ON/OFF SWITCH
CAUTION
• When removing the plug from the electrical outlet, grasp
the plug, not the cord.
1) BODY CONTROL TYPE 2) ON/OFF TYPE
POWER CORD
DJ68-00586J-02.indb 9 2017. 7. 13. �� 11:20
maintain tools and filter _11
10_ operating the cleaner
POWER-CONTROL
1) SLIDE CONTROL TYPE ONLY (OPTION)
• SLIDE TO THE STOP POSITION
Vacuum-cleaner switches off (stand by mode)
• SLIDE FORWARD TO MAX
Suction capacity increases smoothly up to
maximum.
- BODY (BODY-CONTROL TYPE ONLY)
MIN = For delicate surface e.g. net curtains.
MAX = For hard floors and heavily soiled carpets.
2) BODY-CONTROL TYPE / ON/OFF TYPE
- HOSE
To reduce suction for cleaning draperies, small rugs,
and other light fabrics, pull the tap air until the hole
is open.
DJ68-00586J-02.indb 10 2017. 7. 13. �� 11:20
