Samsung UA48J5000AK User manual

▶

❑Using the INFO button (Now & Next guide)

The display identifies the current channel and the status of certain audio-video

settings.

The Now & Next guide shows daily TV programme information for each channel

according to the broadcasting time.

NWhen you press the INFO button, a channel information banner will appear

on the top of the screen. And then press the ENTEREbutton, you can see

the details of the programme.

●Scroll ◄, ►to view information for a desired programme while watching

the current channel.

●Scroll ▲, ▼to view information for other channels.

Channel Setting

English

◀ ▶

❑Memorizing channels

■Aerial

(Depending on the country and model)

OMENUm→Broadcasting → Aerial → ENTERE

Before your television can begin memorising the available channels, you must

specify the type of signal source that is connected to the TV.

English

◀ ▶

■Auto Tuning

(Depending on the country and model)

OMENUm→Broadcasting → Auto Tuning → ENTERE

NAutomatically allocated programme numbers may not correspond to actual

or desired programme numbers. If a channel is locked, the PIN input window

appears.

●Auto Tuning

Aerial (Terrestrial / Cable / Satellite) (Depending on the country and model)

: Select the aerial source to memorise.

NWhen selecting Terrestrial, scans for a channel automatically and stores

in the TV.

Channel Type (Digital & Analogue / Digital / Analogue): Select the channel

source to memorise.

Channel Ordering (Depending on the country and model): Select the channel

order type.

English

◀ ▶

When selecting Cable →Digital & Analogue, Digital or Analogue

–Operator Selection (Depending on the country and model): Selects a

provider of cable services.

–Search Mode: Scans for all channels with active broadcast stations and

stores them in the TV.

NIf you select Quick, you can set up the Network, Network ID,

Frequency, Modulation and Symbol Rate manually by pressing the

button on the remote control.

–Network: Selects the Network ID setting mode among Auto or Manual.

●Network ID: When Network is Manual, you can set up Network ID

using the numeric buttons.

English

◀ ▶

●Frequency: Displays the frequency for the channel (differs in each

country).

●Modulation: Displays available modulation values.

●Symbol Rate: Displays available symbol rates.

●Cable Search Option

(Depending on the country and model & cable channels only)

Sets additional search options such as the frequency and symbol rate for a

cable network search.

Start Frequency / Stop Frequency: Set the start or stop frequency (differs in

each country).

Symbol Rate: Displays available symbol rates.

Modulation: Displays available modulation values.

English

◀ ▶

●Satellite

(Depending on the country and model & satellite only)

When selecting Satellite, scans for a channel automatically and stores in the

T V.

Channel Type (All / TV / Radio): Select the channel type to memorise.

Satellite: Select the satellite to scan.

Scan Mode (All Channels / Free Channels Only): Select a scan mode for

the selected satellite.

Re-initialise: Selects the scanning mode of the selected satellite.

Search Mode: Sets Search Mode using ▲ / ▼buttons.

English

◀ ▶

❑Using the Channel menu

■Channel List

OMENUm→Broadcasting →Channel List →ENTERE

The Channel List contains the channels your TV displays when you press the

channel button. You can view channel information, All, TV, Radio, Data/Other,

Analogue or Favourites 1-5.

Press ► (Mode) button to change the channel mode, or press ◄(Sorting)

button to change the channel order according to channel number or name on the

list.

NWhen you press the CH LIST button on the remote control, Channel List

screen will be displayed at once.

English

◀ ▶

Channel Sorting

●Number / Name: Arranges the channel order according to channel number or

name on the list.

Channel Mode

●Aerial: Switches to Terrestrial, Cable or Satellite.(Depending on the country

and model)

●Edit Favourites: Set channels you watch frequently as favourites.

NFor detailed information about using Edit Favourites, refer to “Edit

Favourites”.

●Favourites 1-5: Shows all favourite channels, arranged in up to five groups.

Each group has a separate screen.

NThe TV displays Favourites 1-5 only if you have added favourites using

Edit Favourites.

English

◀ ▶

●All: Shows all currently available channels.

●TV: Shows all currently available TV channels.

●Radio: Shows all currently radio channels.

●Data/Other: Shows all currently available MHP (Multimedia Home Platform) or

other channels.

●Analogue: Shows all currently available analogue channels.

English

◀ ▶

■Guide

OMENUm→Broadcasting →Guide →ENTERE

The EPG (Electronic Programme Guide) information is provided by broadcasters.

Using programme schedules provided by broadcasters, you can specify

programmes you want to watch in advance so that the channel automatically

changes to the selected programme channel at the specified time. Programme

entries may appear blank or out of date depending on a channel status.

●aRed (Quick Nav): Viewing the TV programmes on the list quickly using

▲/▼/◄/► buttons.

●bGreen (Channel Category): Select the type of channels you want to

display.

●{Yellow (Schedule Manager): Moves to the reserved programmes in

Schedule Manager.

English
