Samsung GT-E2232 User manual
GSM TELEPHONE
GT-E2232
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1Repair
7. Level 2Repair
8. Level 3Repair
9. Reference data
Notice :
All functionality, features, specifications and other
product information provided in this document inclu
ding, but not limited to, the benefits, design, pricing,
components, performance, availability, and capabiliti
-es of the product are subject to change without
notice or obligation. Samsung reserves the right to
make changes to this document and the product
described herein, at anytime, without obligation on
Samsung to provide notification of such change.
GSM TELEPHONE CONTENTS
SAMSUNG Proprietary-Contents may change without notice
1. Safety Precautions
1-1
This Document can not be used without Samsung's authorization
1-1. Repair Precaution
―Repair in Shield Box, during detailed tuning. Take specially care of tuning or test, because
specipicty of cellular phone is sensitive for surrounding interference(RF noise).
―Be careful to use akind of magnetic object or tool, because performance of parts is damaged by
the influence of magnetic force.
―Surely use astandard screwdriver when you disassemble this product, otherwise screw will be
worn away.
―Use athicken twisted wire when you measure level.
Athicken twisted wire has low resistance, therefore error of measurement is few.
―Repair after separate Test Pack and Set because for short danger (for example an overcurrent
and furious flames of parts etc) when you repair board in condition of connecting Test Pack and
tuning on.
―Take specially care of soldering, because Land of PCB is small and weak in heat.
―Surely tune on/off while using AC power plug, because arepair of battery charger is dangerous
when tuning ON/OFF PBA and Connector after disassembling charger.
―Don't use as you pleases after change other material than replacement registered on SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.
SAMSUNG Proprietary-Contents may change without notice
Safety Precautions
1-2
This Document can not be used without Samsung's authorization
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
―Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity prevention
string on wrist.
―Use earthed soldering steel when you connect or disconnect ESD.
―Use soldering removing tool to break static electricity. ,otherwise ESD will be damaged by static
electricity.
―Don't unpack until you set up ESD on product. Because most of ESD are packed by box and
aluminum plate to have conductive power,they are prevented from static electricity.
―You must maintain electric contact between ESD and place due to be set up until ESD is
connected completely to the proper place or acircuit board.
2. Specification
2-1
2-1. GSM General Specification
GSM900
Phase 1
DCS1800
Phase 1
Freq.
Band[MHz]
Uplink/Downlink
890~889.8
935~934.8
1710~1785
1805~1880
ARFCN range 0~1023 512~885
Tx/Rx spacing 45MHz 95MHz
Mod. Bit rate/
Bit Period
270.833kbps
3.692us
270.833kbps
3.692us
Time Slot Period/Frame
Period
576.9us
4.615ms
576.9us
4.615ms
Modulation 0.3GMSK 0.3GMSK
MS Power 33dBm~5dBm 30dBm~0dBm
Power Class 5pcl ~ 19pcl 0pcl ~15
pcl
Sensitivity -102dBm -100dBm
TDMA Mux 8 8
Cell Radius 35Km 2Km
Speclflcation
2-2
TX Power
control level
GSM900
533±3
dBm
631±3
dBm
729±3
dBm
827±3
dBm
925±3
dBm
10 23±3 dBm
11 21±3 dBm
12 19±3 dBm
13 17±3 dBm
14 15±3 dBm
15 13±3 dBm
16 11±5 dBm
17 9±5 dBm
18 7±5 dBm
19 5±5 dBm
TX Power
control level DCS1800
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
2-2. GSM Tx Power Class
SAMSUNG Proprietary-Contents may change without notice
3. Operation Instruction and Installation
3-1
This Document can not be used without Samsung's authorization
Main Function
•GSM Dual Band GSM900/1800
•1.77"
QQVGA TFT
•VGA Camera
•SMS /MMS /E-MAIL
•MP3 /iMelody
•3.5
mm Earjack
•Dual Sim
SAMSUNG Proprietary-Contents may change without notice
4. Exploded View and Parts List
4-2
This Document can not be used without Samsung's authorization
4-1. Cellular phone Exploded View
QFR01
QMW02
QLC01
QCA01
QMO01
QSP01
QAR01
QRE01
QMI01
QKP01
QCR101
QBA01
QBC00
QMP01
QME01
QCR72
QIF01
SAMSUNG Proprietary-Contents may change without notice
Exploded View and Parts List
4-2
This Document can not be used without Samsung's authorization
Design LOC Description SEC CODE
QSP01 SPEAKER 3001-002671
QAR01 AUDIO-RECEIVER 3009-001539
QCR101 SCREW-MACHINE 6001-002005
QCR72 SCREW-MACHINE 6001-002051
QMI01 MICROPHONE-ASSY-GT-E2230 GH30-00723A
QMO01 MOTOR DC-GT-E2152 GH31-00521A
QBA01 INNER BATTERY PACK-1000MAH,BLK,ENG,EU GH43-03184A
QCA01 CAMERA MODULE-GT-E2120 GH59-07682A
QME01 DOME SHEET-GT-E2230 GH59-10744A
QMW02 PCT WINDOW-PCT MAIN WINDOW(DUOS) GH72-63542A
QMP01 A/S ASSY-PBAMAIN(COMM)GT-E2232 GH82-05666A
QLC01 ASSY LCD-1.77 QQVGA SCH-B559 ASSY GH96-04327A
QFR01 ASSY CASE-FRONT GH98-19398A
QBC00 ASSY COVER-BATTERY GH98-19400A
QKP01 ASSY KEYPAD-MAIN(RUSS) GH98-19669A
QRE01 ASSY CASE-REAR GH98-19521A
QIF01 PMO COVER-IF GH72-62902A
4-2. Cellular phone Parts list
SAMSUNG Proprietary-Contents may change without notice
5. MAIN Electrical Parts List
5-1
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
0403-001688 D500 DIODE-ZENER
0404-001172 ZD408 DIODE-SCHOTTKY
0406-001267 ZD402 DIODE-TVS
0406-001267 ZD403 DIODE-TVS
0406-001267 ZD406 DIODE-TVS
0406-001267 ZD407 DIODE-TVS
0406-001286 ZD500 DIODE-TVS
0406-001286 ZD502 DIODE-TVS
0406-001286 ZD503 DIODE-TVS
0406-001293 D400 DIODE-TVS
0406-001361 ZD404 DIODE-TVS
0406-001375 ZD400 DIODE-TVS
0406-001375 ZD401 DIODE-TVS
0406-001375 ZD409 DIODE-TVS
0406-001390 ZD501 DIODE-TVS
0406-001446 ZD300 DIODE-TVS
0501-002606 Q300 TR-SMALL SIGNAL
0501-002663 Q302 TR-SMALL SIGNAL
0501-002680 Q100 TR-SMALL SIGNAL
0502-001322 Q301 TR-POWER
0504-001151 U300 TR-DIGITAL
0601-002846 LED500 LED
0601-002846 LED501 LED
0601-002846 LED502 LED
0601-002846 LED503 LED
0601-002846 LED504 LED
0601-002846 LED505 LED
1202-001068 U402 IC-VOLTAGE COMP
1203-005512 U303 LDO
1203-005848 U302 IC-MULTI REG.
1203-005851 U304 IC-MULTI REG.
1203-006203 U500 IC-DC/DC CONVERTER
1203-006340 U301 IC-VOL. DETECTOR
1205-003517 U100 IC-BLUETOOTH
1404-001224 TH200 THERMISTOR-NTC
1405-001298 V300 VARISTOR
1405-001298 V500 VARISTOR
SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-2
This Document can not be used without Samsung's authorization
SEC CODE Design LOC Discription
1405-001298 V501 VARISTOR
2007-000138 R100 R-CHIP
2007-000138 R101 R-CHIP
2007-000138 R102 R-CHIP
2007-000138 R420 R-CHIP
2007-000138 R501 R-CHIP
2007-000138 R506 R-CHIP
2007-000138 R510 R-CHIP
2007-000138 R511 R-CHIP
2007-000138 R512 R-CHIP
2007-000138 R545 R-CHIP
2007-000140 R103 R-CHIP
2007-000140 R305 R-CHIP
2007-000140 R503 R-CHIP
2007-000140 R504 R-CHIP
2007-000140 R507 R-CHIP
2007-000140 R529 R-CHIP
2007-000140 R534 R-CHIP
2007-000141 R409 R-CHIP
2007-000143 R210 R-CHIP
2007-000143 R211 R-CHIP
2007-000143 R311 R-CHIP
2007-000143 R312 R-CHIP
2007-000143 R544 R-CHIP
2007-000148 R201 R-CHIP
2007-000148 R204 R-CHIP
2007-000148 R208 R-CHIP
2007-000148 R302 R-CHIP
2007-000148 R523 R-CHIP
2007-000148 R524 R-CHIP
2007-000148 R525 R-CHIP
2007-000148 R526 R-CHIP
2007-000148 R527 R-CHIP
2007-000153 R407 R-CHIP
2007-000154 R303 R-CHIP
2007-000155 R106 R-CHIP
2007-000157 R309 R-CHIP
