Samsung NX58K9500WG User manual

Slide-In Gas Range

User manual

NX58H9950W*/NX58H9500W*/NX58K9500W*

2 English

Regulatory Notice

ANTITIP DEVICE

WARNING

To reduce the risk of tipping the range, the range must be

secured by a properly installed Anti-Tip device. AFTER THE

RANGE HAS BEEN INSTALLED, CONFIRM THAT THE ANTI-TIP

DEVICE HAS BEEN PROPERLY INSTALLED AND VERIFY THAT

THE ANTI-TIP DEVICE IS PROPERLY ENGAGED. Refer to the

installation manual for instructions.

a) If the anti-tip device is not installed, a child or adult can tip the

range and be killed.

b) Verify the anti-tip device has been properly installed and

engaged at rear right (or rear left) of the range bottom.

c) If you move the range and then move it back into place, ensure

the anti-tip device is re-engaged at the right or left rear of the

range bottom.

d) Do not operate the range without the anti-tip device in place and

engaged.

e) Failure to do so can result in death or serious burns to children

or adults.

WARNING

If the information in this manual is not followed exactly,

a re or explosion may result causing property damage,

personal injury, or death.

• DO NOT store or use gasoline or other ammable vapors

and liquids in the vicinity of this or any other appliance.

• WHAT TO DO IF YOU SMELL GAS:

- DO NOT try to light any appliance.

- DO NOT touch any electrical switch.

- DO NOT use any phone in your building.

- Immediately call your gas supplier from a neighbor’s

phone. Follow the gas supplier’s instructions.

- If you cannot reach your gas supplier, call the re

department.

• Installation and service must be performed by a qualied

installer, service agency, or the gas supplier.

English 3

Regulatory Notice

KEY FEATURES

Bigger is better

With a capacity of 5.8 cubic feet, this Samsung gas oven range

offers more space than many other leading brands in the

United States and Canadian markets. The enhanced capacity

means a better cooking experience.

A cooktop with 5 burners

Power burners, simmer burners, as well as a center oval burner

provide exible cooktop heat for a variety of cookware. The

center oval burner delivers heat evenly over a large area, and

provides the optimum temperatures for griddle cooking.

Enhanced convenience with easy

maintenance

The Samsung gas oven range combines all the benets of 3

separate home appliances - gas range, gas oven, and warming

drawer - to maximize customer convenience with its careful,

stylish design.

WARNING

Do not step, lean, or sit on the oven door of the range. You can

cause the range to tip, resulting in burns or serious injuries.

Conrm that the Anti-Tip device is installed properly. Then, to

verify that the Anti-Tip device is engaged, grasp the top rear

edge of the range and carefully attempt to tilt it forward. The

Anti-Tip device should prevent the range from tilting forward

more than a few inches.

If you pull the range out from the wall for any reason, make

sure the antitip device is properly engaged when you push the

range back against the wall. If it is not, there is a risk of the

range tipping over and causing injury if you or a child stand, sit

or lean on an open door.

Never completely remove the leveling legs. If you remove

the leveling legs, the range will not be secured to the anti-tip

device properly.

4 English

Contents

Important safety information 5

Symbols used in this manual 5

California proposition 65 warning 5

Commonwealth of massachusetts 5

General safety 6

Fire safety 7

Gas safety 8

Electrical and grounding safety 9

Installation safety 10

Location safety 12

Cooktop safety 13

Oven safety 15

Warming drawer/lower drawer safety 16

Self-cleaning oven safety 17

Overview 18

Layout 18

What’s included 18

Control panel 19

Before you start 20

Display mode 20

Clock 20

Kitchen timer 21

Oven vent/cooling vent 21

Gas range 21

Cookware 22

Wok grate 23

Griddle 23

Gas burners 24

Ignition 25

Gas oven 26

Cooking mode 26

Recipe guide 30

Racks 32

Cooking options 33

Special features 34

Changing option settings 37

Others 41

Warming drawer 42

Maintenance 43

Cleaning 43

Replacement 49

Reinstallation 49

Troubleshooting 51

Checkpoints 51

Information codes 56

Warranty (U.S.A) 57

Warranty (CANADA) 59

English 5

Important safety information

SAVE THESE INSTRUCTIONS

CALIFORNIA PROPOSITION 65 WARNING

WARNING

Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

COMMONWEALTH OF MASSACHUSETTS

• This product must be installed by a licensed plumber or gas

tter qualied or licensed by the State of Massachusetts.

When using ball-type gas shut-off valves, you must use

the T-handle type. Multiple exible gas lines must not be

connected in series.

Important safety information

READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE

• All electrical and gas equipment with moving parts can be

dangerous. Please read the important safety instructions

for this appliance in this manual. The instructions must be

followed to minimize the risk of injury, death, or property

damage.

• Save this manual. Please Do Not Discard.

SYMBOLS USED IN THIS MANUAL

WARNING

Hazards or unsafe practices that may result in severe personal

injury or death.

CAUTION

Hazards or unsafe practices that may result in electric shock,

personal injury, or property damage.

NOTE

Useful tips and instructions

These warning icons and symbols are here to prevent injury to

you and others. Please follow them explicitly. After reading this

section, keep it in a safe place for future reference.

6 English

Important safety information

SAVE THESE INSTRUCTIONS

• Remove all packaging materials from the range before

operating to prevent ignition of these materials. Keep

all packaging materials out of children’s reach. Properly

dispose the packaging materials after the range is

unpacked.

• Do not store any object of interest to children on the

cooktop or backguard of the range. Children climbing on the

range to reach items could be killed or seriously injured.

• Do not operate the range if the range or any part of the

range is damaged, malfunctioning, or missing parts.

• Do not use the range as a space heater. Use the range for

cooking only.

• Do not use oven cleaners or oven liners in or around any

part of the oven.

• Use only dry pot holders. Pot holders with moisture in them

can release steam and cause burns if they come in contact

with hot surfaces. Keep pot holders away from open ames

when lifting cookware. Never use a towel or bulky cloth in

place of a pot holder.

• Do not use the range to heat unopened food containers.

• Do not strike the oven glass.

• When disposing of the range, cut off the power cord and

remove the door to prevent children and animals from

getting trapped.

GENERAL SAFETY

WARNING

To reduce the risk of re, electric shock, personal injuries, and/

or death, obey the following precautions.

• Do not touch any part

of the range, including

but not limited to, oven

burners, surface burners, or

interior surfaces during or

immediately after cooking.

• Know the location of the gas shut-off valve and how to shut

it off.

• Make sure the anti-tip device is properly installed on the

range. See the installation instructions for more information.

• Do not let children near the range. Do not let children go

into the range or onto the range. Do not let children play

with the range or any part(s) of the range. Do not leave

children unattended in an area where the range is in use.

For children’s safety, we recommend utilizing the control/

door lockout feature.

English 7

Important safety information

SAVE THESE INSTRUCTIONS

FIRE SAFETY

WARNING

To reduce the risk of re, electric shock, personal injuries, and/

or death, obey the following precautions.

• Do not store, place or use

ammable or combustible

materials such as charcoal,

paper, plastic, pot holders,

linens, curtains, gasoline or

other ammable vapors or

liquids near or inside the range.

• Do not wear loose tting or hanging garments while using

the range.

• To avoid grease buildup, regularly clean the vents.

• Do not let pot holders or other ammable materials touch a

heating element. Do not use a towel or other bulky cloths in

place of a pot holder.

• Unplug or disconnect power before servicing.

• Make sure all meat and poultry is cooked thoroughly. Meat

should always be cooked to an internal temperature of

160 °F (71 °C). Poultry should always be cooked to an

internal temperature of 180 °F (82 °C).

• Teach children not to touch or play with the controls or any

part of the range. We recommend you utilize the control/

door lockout feature to reduce the risk of mis-use by

children.

• Do not lean on the range as you may turn the control knobs

inattentively.

• Do not stand on top of the appliance or place objects

(such as laundry, an oven cover, lighted candles, lighted

cigarettes, dishes, chemicals, metal objects, etc.) on the

appliance.

- Items, such as a cloth, may get caught in the door.

- This may result in electric shock, re, problems with the

product, or injury.

• Take care not to hurt yourself when cleaning the appliance

(externally or internally). You may hurt yourself on the

sharp edges of the appliance.

8 English

Important safety information

SAVE THESE INSTRUCTIONS

GAS SAFETY

WARNING

To reduce the risk of re, electric shock, personal injuries, and/

or death, obey the following precautions.

If you smell gas:

• Close the valve and do not

use the range.

• Do not light a match, candle,

or cigarette.

• Do not turn on any gas or

electric appliances.

• Do not touch any electrical switches or plug a power cord

into an outlet.

• Do not use any phone in your building.

• Evacuate the room, building, or area of all occupants.

• Immediately call your gas supplier from a neighbor’s phone.

Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the re

department.

• Do not use water on a grease re. To put out a grease re,

turn off the heat source and smother the re with a tight-

tting lid or use a multipurpose dry chemical or foam-type

re extinguisher.

• If a grease re should occur in the oven, turn off the oven

by pressing the OFF/CLEAR button. Keep the oven door

closed until the re goes out.

If necessary, use a multipurpose dry chemical or foam-type

re extinguisher.

• Do not heat unopened food containers - buildup of pressure

may cause container to burst and result in injury.

• Do not put any combustible material or items around the

range.

English 9

Important safety information

SAVE THESE INSTRUCTIONS

• Do not use a damaged power plug, power cord, or loose

power outlet.

• Do not modify the power plug, power cord, or power outlet

in any way.

• Do not put a fuse in a neutral or ground circuit.

• Use a dedicated 120-volt, 60-Hz, 20-amp, AC, fused

electrical circuit for this range. A time-delay fuse or circuit

breaker is recommended. Do not plug more than one

appliance into this circuit.

• Do not connect the ground wire to plastic plumbing lines,

gas lines, or hot water pipes.

• This range must be Earth grounded. In the event of a

malfunction or breakdown, grounding will reduce the risk of

electrical shock by providing a path for the electric current.

This range is equipped with a cord having a grounding

plug. The plug must be rmly plugged into an outlet that

is properly installed and grounded in accordance with the

local codes and ordinances. If you are unsure whether your

electrical outlet is properly grounded, have it checked by a

licensed electrician.

Checking for gas leaks

• Leak testing of the appliance shall be conducted according

to the manufacturer’s instructions.

Do not use a ame to check for gas leaks. Use a brush to

spread a soapy water mixture around the area you are

checking. If there is a gas leak, you will see small bubbles in

the soapy water mixture at the leak point.

ELECTRICAL AND GROUNDING SAFETY

WARNING

To reduce the risk of re, electric

shock, personal injuries, and/

or death, obey the following

precautions.

• Plug into a grounded 3-prong

outlet.

• Do not remove the ground prong.

• Do not use an adapter or an extension cord.

10 English

Important safety information

SAVE THESE INSTRUCTIONS

INSTALLATION SAFETY

WARNING

To reduce the risk of re, electric shock, personal injuries, and/

or death, obey the following precautions.

• Have your range installed

and properly grounded

by a qualied installer,

in accordance with the

installation instructions. Any

adjustment and service should

be performed only by qualied gas range installers or

service technicians.

• Do not attempt to service, modify, or replace your range or

any part of your range unless it is specically recommended

in this manual. All other service should be referred to a

qualied technician.

• Always use new exible connectors when installing a gas

appliance. Do not use old exible connectors.

• Make sure the anti-tip device is properly installed on the

range. See the installation instructions for more information.

• The range is supplied with a 3-pronged grounded plug. This

cord must be plugged into a mating, grounded 3-prong

outlet that meets all local codes and ordinances. If codes

permit the use of a separate ground wire, we recommend

that a qualied electrician determine the proper path for

this ground wire.

• Electrical service to the range must conform to local codes.

Barring local codes, it should meet the latest ANSI/NFPA No.

70 – Latest Revision (for the U.S.) or the Canadian Electrical

Code CSA C22.1 – Latest Revisions.

• It is the personal responsibility of the range owner to

provide the correct electrical service for this range.

This manual suits for next models

Table of contents

Languages:

Other Samsung Range manuals

Samsung

Samsung NE58H9970WS User manual

Samsung

Samsung NX58H9500WS User manual

Samsung

Samsung NX58K3310S series User manual

Samsung

Samsung NE63 831 Series User manual

Samsung

Samsung NE63*671 Series User manual

Samsung

Samsung NE63 6511S Series User manual

Samsung

Samsung NX58M9420SS Series User manual

Samsung

Samsung NE58F9710WS User manual

Samsung

Samsung NX58M9960P series User manual

Samsung

Samsung NX58M5600S Series User manual

Samsung

Samsung NX58F5700WS User manual

Samsung

Samsung NX58M6650WS User manual

Samsung

Samsung NX58H9500W Series User manual

Samsung

Samsung NX58H9500WS/AA User manual

Samsung

Samsung NX60 67 S Series User manual

Samsung

Samsung FTQ386 Series User manual

Samsung

Samsung FCQ321HTUB User manual

Samsung

Samsung NE63 6511S Series User manual

Samsung

Samsung NX58 565 Series User manual

Samsung

Samsung NE59 785 Series User manual

Samsung

Samsung NX58K3310S series User manual

Samsung

Samsung NX58M9960P series User manual

Samsung

Samsung NE63T8911SG User manual

Samsung

Samsung NE58N9430SG User manual

Popular Range manuals by other brands

Kenmore

Kenmore 790.45712 Use & care guide

Wolf

Wolf CHR CHSSR owner's manual

Smeg

Smeg Built-in Microwave Oven Instructions for the user

Zanussi

Zanussi ZCG054G user manual

Whirlpool

Whirlpool 8575985-W Warranty

Frigidaire

Frigidaire 316000635 owner's guide

GE JCSS630 quick start guide

Hotpoint

Hotpoint RB524R Use and care & installation instructions

Whirlpool

Whirlpool Roper FGP305KW3 Use & care guide

Amana

Amana ART6610 SERIES owner's manual

Maytag

Maytag MERH770WB Use & care guide

Fulgor Milano

Fulgor Milano SOFIA Use & care manual

Premier

Premier EF-4358GH instruction manual

Kenmore

Kenmore 790.9010 Series Use & care guide

KitchenAid

KitchenAid KESC300 Use and care guide

Frigidaire

Frigidaire FFEF3012LS Service data sheet

Diamond

Diamond G65/2F4T manual

LG LRE3091 Product information
