Samsung WMN4270S User manual

Adjustable Wall Mount User Guide

WMN4270S

Finished wall mount

Components

 Pleasemakesuretousethecomponentsandpartssuppliedwiththeproduct.

Safety precautions

Makesurethataninstallationengineerspecifiedbyyourdealerinstallstheproduct.

1. Donotletchildrenplayunderneaththeproductwhenitisinstalled.Childrenmayhittheirheadsagainsttheedgeoftheproduct.

2. Takecarewhenyouadjusttheangleorrotatetheproductbecausethebackoftheproductmaymakecontactwiththewall.

 (Youcanpreventdamagetotheproductandthewallbyattachingspongestothe4edgesoftheproduct.)

3. Donotinstalltheproductinahot,humidlocationoronaweakwallthatisunabletosustaintheweightoftheproduct.

4. DonotinsertyourhandintothegrooveatthebottomoftheTVwhileinstallingtheTVontothewallmountasthismayresultinanelectricshock.

5. MakesuretocoverthegrooveatthebottomoftheTVthatbecomesvisibleafterremovingthestandusingtheseparatecoversuppliedwiththeTV.

Makesurethataninstallationengineerspecifiedbyyour

dealermovesorreplacestheproductaftertheinstallation.

Donothangontotheinstalledproductandavoid

impactstotheproduct.

Adjustable mount Bracket

1EA Left:1EA Right:1EA

Parts

Plastichangers

:4EA

Screwsⓐ:8EA Anchors:8EA

Cabletie:1EA

Screwsⓑ:8EA

Screwsⓒ:4EA Washers

M8X35 M8X40 M8X47

Wall Mount Guide-WMN4270S-03.indb 1 2012-12-18 �� 11:11:16

Installing the wall mount

1Fixtheadjustablemountontothewallasshownbythefigure.

Fixtheadjustablemountontothewallwithanchorsand

screwsⓐfrom①to⑦inthisorder.

Ifyoucannotfastentheanchorsandscrewsatthespecified

positions,fastenthematthenearestpossiblepositions.

2Afterfirmlyfixingtheadjustablemountontothewallasshown

bythefigure,pulltheadjustablepartforward,assemblethe

bracketswiththeadjustablemountasshownbythefigureand

fixthembyfasteningthe8screwsⓑsuppliedwiththeproduct.

(Thesameforleftandright)

Checkthestrengthofthewall,andifthewallisinsufficientlystrong,reinforcethewallbeforeinstallingtheproductonthewall.

Thescrewsandanchorssuppliedwiththeproductaretofixtheproductontowoodorconcrete.

Checkthematerialofthewallanduseappropriatefixingscrewsdependingonthetypeofmaterialsuchasplasterboard,

marbleorironplate.

Fixing the anchors and screws ⓐ

Whenyoudrillaholeinthewall,makesuretouseadrill

bitwiththespecifieddiameter.failingtodosomayresult

inasafetyissue.

Drillaholeusinga6X50drillbit.

Cleantheinsideofthehole.

Inserttheenclosedanchorintothehole.

Aligntheadjustablemountwiththehole

andfastenthescrewⓐ.

4screwsⓑ

Wall Mount Guide-WMN4270S-03.indb 2 2012-12-18 �� 11:11:17

3RemovethescrewsfromthemainbodyoftheTV,assemblethe4enclosed

plastichangersandscrewsⓒasshownbythefigureandfirmlyfastenthemto

thebackofthemainbodyoftheTV.

 

HangtheTVontothewallmountandmakesuretocheckiftheTVhasbeeninstalledproperlyontothewallmountby

observingtheassembledTVasyoumovethewallmountfromlefttoright.

TakecarenottohurtyourfingerswhenyouinstalltheTVoradjustthewallmount.

Makesuretofixthewallmountontothewallfirmly.IftheTVfalls,itmayresultininjuryordamagetotheproduct.

4PullthewallmountbracketsasfarforwardaspossibleandhangtheTVontothewallmountatthespecifiedpositionsasshown

bythefigurewhile2personsareholdingtheTV.

5Tiethepowercordandtheothercableswiththeenclosedcabletieasshownby

thefigureandmakesurethatthecablesdonotcomeloosewhenthewallmount

isadjusted.

Afterconnectingthecablesandpullingtheadjustablemountasfarforward

aspossible,arrangethecablesusingthecabletiethathasbeenpassed

throughthespecifiedholeintheadjustablemountasshownbythefigure.

Thecablewillthennotinterferewiththewallmount.

Checktheoperation2or3timesandifthereisnoproblem,fixthewall

molding.

FixtheTVontothewallmount

firmlyandturnthe2safetycatches

atthetopofthewallmountbrackets

tothelockpositionasshownbythe

figure,sothattheTVandthewall

mountdonotbecomeseparated.

[Modelsbefore2013] [2013F-seriesmodels]

UseM8X35andM8X40screwsⓒ

Refertotheseparatesheet

[Fornormalmodels] [Forslimmodels]

Wall Mount Guide-WMN4270S-03.indb 3 2012-12-18 �� 11:11:18

Adjusting the wall mount angle

 ThisproducthasadoptedaSmoothMovingMechanismsothatitalwaysmovesverysmoothly.

Adjusttheangleoftheproductcarefully.Usingexcessiveforce

mayresultintheproducthittingthewallandbecomingdamaged.

Adjustthehorizontalanglebyholdingbothsidesoftheproduct.

Whenyouadjusttheverticalangle,holdthetopcenterofthe

product.Thenyoucansmoothlyadjusttheangle.

Youcanadjusttheangleupto-20°~20°horizontallyandup

to10°~15°vertically.Theallowedadjustableanglemaydiffer

dependingonthemodel.

Product specifications

Specifications

Theproductappearanceandspecificationsaresubjecttochangeforproductimprovementpurposeswithout

priornotice.

Width(mm) 465

Height(mm) 460

Depth(mm) 24.5

Weight(Kg) 5.5

WallmountVESAspecifications 400X400

465

240.5 24.5 50

400

346

247

394

135

172

212

400

460

Wall Mount Guide-WMN4270S-03.indb 4 2012-12-18 �� 11:11:19
