Samsung S27E591C User manual
User manual
S27E591C
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.
BN46-00473A-03
Table Of Contents 2
Table Of Contents
BEFORE USING THE
PRODUCT
6 Copyright
6 Icons used in this manual
7 Cleaning
8 Securing the Installation Space
8 Precautions for storage
9 Safety Precautions
9Symbols
10 Electricity and Safety
11 Installation and Safety
13 Operation and Safety
17 Correct posture to use the product
PREPARATIONS 18 Checking the Contents
18 Checking the Components
19 Parts
19 Control Panel
20 Function Key Guide
22 Reverse Side
23 Installation
23 Attaching the Stand
24 Removing the Stand
25 Adjusting the Product Tilt
25 Anti-theft Lock
26 Installing the Wall Mount
CONNECTING AND USING
A SOURCE DEVICE
28 Before Connecting
28 Pre-connection Checkpoints
28 Connecting and Using a PC
28 Connecting to a PC
31 Connecting the Power
33 Driver Installation
34 Setting Optimum Resolution
Table Of Contents
Table Of Contents 3
SCREEN SETUP 35 SAMSUNG MAGIC Bright
35 Configuring SAMSUNG MAGIC Bright
37 Brightness
37 Configuring Brightness
38 Contrast
38 Configuring Contrast
39 Sharpness
39 Configuring Sharpness
40 Color
40 Configuring Red
41 Configuring Green
42 Configuring Blue
43 Configuring the Color Tone Settings
44 Configuring Gamma
45 SAMSUNG MAGIC Upscale
45 Configuring SAMSUNG MAGIC Upscale
46 HDMI Black Level
46 Configuring the HDMI Black Level Settings
47 Eye Saver Mode
47 Configuring Eye Saver Mode
48 Game Mode
48 Configuring Game Mode
49 Response Time
49 Configuring the Response Time
50 Picture Size
50 Changing the Picture Size
52 Screen Adjustment
52 Configuring H-Position & V-Position
53 Adjusting Coarse
54 Adjusting Fine
Table Of Contents
Table Of Contents 4
COORDINATING OSD 55 Transparency
55 Changing Transparency
56 Position
56 Configuring H-Position & V-Position
57 Language
57 Configuring Language
58 Display Time
58 Configuring Display Time
SETUP AND RESET 59 Sound
59 Configuring Volume
60 Configuring Sound Mode
61 Configuring Select Sound
65 Eco Saving Plus
65 Configuring Eco Saving Plus
66 Off Timer
66 Configuring Off Timer
67 Configuring Turn Off After
68 PC/AV Mode
68 Configuring PC/AV Mode
69 Source Detection
69 Configuring Source Detection
70 Key Repeat Time
70 Configuring Key Repeat Time
71 Power LED On
71 Configuring Power LED On
72 Reset All
72 Initializing Settings (Reset All)
INFORMATION MENU AND
OTHERS
73 Information
73 Displaying Information
Table Of Contents
Table Of Contents 5
74 Configuring Brightness, Contrast and
Sharpness from the Initial Screen
75 Configuring Volume in the Initial Screen
75 Volume
INSTALLING THE
SOFTWARE
76 Easy Setting Box
76 Installing the Software
77 Removing the Software
TROUBLESHOOTING
GUIDE
78 Requirements Before Contacting
Samsung Customer Service Center
78 Testing the Product
78 Checking the Resolution and Frequency
78 Check the following.
81 Q & A
SPECIFICATIONS 83 General
85 PowerSaver
86 Standard Signal Mode Table
APPENDIX 88 Contact SAMSUNG WORLD WIDE
96 Responsibility for the Pay Service (Cost
to Customers)
96 Not a product defect
96 A Product damage caused by customer's fault
96 Others
97 Correct Disposal
97 Correct Disposal of This Product (Waste
Electrical & Electronic Equipment)
98 Terminology
INDEX
6
Before Using the Product
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
© 2015 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is
prohibited.
Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Icons used in this manual
An administration fee may be charged if either
(a) an engineer is called out at your request and there is no defect in the product
(i.e. where you have failed to read this user manual).
(b) you bring the unit to a repair center and there is no defect in the product
(i.e. where you have failed to read this user manual).
The amount of such administration charge will be advised to you before any work or home visit is
carried out.
The following images are for reference only. Real-life situations may
differ from what is shown in the images.
7
Before Using the Product
Before Using the Product
Cleaning
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
1. Power off the monitor and computer.
2. Disconnect the power cord from the monitor.
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
3. Wipe the monitor screen using a clean, soft and dry cloth.
Do not apply a cleaning agent that contains alcohol,
solvent, or surfactant to the monitor.
Do not spray water or detergent directly on the product.
4. Wet a soft and dry cloth in water and wring thoroughly to clean the
exterior of the monitor.
5. Connect the power cord to the product after cleaning the product.
6. Power on the monitor and computer.
!
!
8
Before Using the Product
Before Using the Product
Securing the Installation Space
Ensure some space around the product for ventilation. An internal temperature rise may cause fire
and damage the product. Be sure to allow the amount of space as shown below or greater when
installing the product.
The exterior may differ depending on the product.
Precautions for storage
Be sure to contact Samsung Customer Service Center (page 88) if the inside of the monitor needs
cleaning. (A service fee will be charged.)
3.93
inches
(10 cm)
3.93
inches
(10 cm)
3.93 inches (10 cm)
3.93 inches (10 cm)
3.93 inches
(10 cm)
9
Before Using the Product
Before Using the Product
Safety Precautions
Symbols
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING
TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside. It is dangerous to
make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and
maintenance has been included with this product.
Warning A serious or fatal injury may result if instructions are not followed.
Caution Personal injury or damage to properties may result if instructions are
not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.
10
Before Using the Product
Before Using the Product
Electricity and Safety
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
An electric shock or fire may result.
Do not plug many products into the same power socket.
Otherwise, the socket may overheat and cause a fire.
Do not touch the power plug with wet hands.
Otherwise, an electric shock may result.
Insert the power plug all the way in so it is not loose.
An unstable connection may cause a fire.
Ensure you connect the power plug to a grounded power socket. (type 1
insulated devices only).
An electric shock or injury may result.
Do not bend or pull the power cord with force. Do not weigh the power cord
down with a heavy object.
A damaged power cord may cause an electric shock or fire.
Do not place the power cord or product near heat sources.
An electric shock or fire may result.
Remove foreign substances such as dust around the plug pins and power socket
with a dry cloth.
Otherwise, a fire may result.
!
!
!
