Samsung 225BW - SyncMaster - 22" LCD Monitor User manual

Install drivers Install programs

SyncMaster 225BW

Downloaded from ManualMonitor.com Manuals

Notational

Failure to follow directions noted by this symbol could result in bodily harm or damage to

equipment.

Prohibited Important to read and understand at all times

Do not disassemble Disconnect the plug from the outlet

Do not touch Ground to prevent an electric shock

Power

When not used for an extended period of time, set your computer to DPMS.

If using a screen saver, set it to the active screen mode.

Downloaded from ManualMonitor.com Manuals

Do not use a damaged or loose plug.

zThis may cause an electric shock or fire.

Do not pull the plug out by the wire nor touch the plug with wet hands.

zThis may cause an electric shock or fire.

Use only a properly grounded plug and receptacle.

zAn improper ground may cause electric shock or equipment damage.

Insert the power plug firmly so that it does not come loose.

zA bad connection may cause fire.

Do not excessively bend the plug and wire nor place heavy objects upon

them, which could cause damage.

zThis may cause an electric shock or fire.

Do not connect too many extension cords or plugs to an outlet.

zThis may cause fire.

Do not disconnect the power cord while using the monitor.

zA surge may be caused by the separation and may damage the monitor.

Do not use the power cord when the connector or plug is dusty.

zIf the connector or plug of the power cord is dusty, clean it with a dry

cloth.

zUsing the power cord with a dusty plug or connector may cause an

electric shock or fire.

Installation

Downloaded from ManualMonitor.com Manuals

Be sure to contact an authorized Service Center, when installing your monitor in

a location with the heavy dust, high or low temperatures, high humidity, chemical

substance and where it operates for 24 hours such as the airport, the train

station or etc.

Failure to do so may cause a serious damage to your monitor.

Put your monitor in a location with low humidity and a minimum of dust.

zFailure to do so may cause an electric shock or fire inside the monitor.

Do not drop the monitor when moving it.

zThis may cause damage to the product or human body.

Install the monitor base in a showcase or shelf so that the end of the

base does not protrude from the showcase or shelf.

zDropping the product may cause damage to the product or personal

injury.

Do not place the product on an unstable or small surface area.

zPlace the product on an even, stable surface, as the product may fall

and cause harm to someone walking by, specifically children.

Do not place the product on the floor.

zSomeone, specifically children could trip over it.

Keep any flammable objects such as candles, insecticides or cigarettes

away from the product.

zOtherwise, this may cause a fire.

Keep any heating devices away from the power cable.

zA melted coating may lead to electric shock or fire.

Do not install the product in places with poor ventilation, for instance, a

bookshelf, closet, etc.

zAny increase in internal temperature may cause fire.

Downloaded from ManualMonitor.com Manuals

Set down the monitor carefully.

zThe monitor could be damaged or broken.

Do not place the monitor face down.

zThe TFT-LCD surface may be damaged.

Installing a wall bracket must be done by a qualified professional.

zInstallation by unqualified personnel may result in injury.

zAlways use the mounting device specified in the owner's manual.

When installing the product, make sure to keep it away from the wall

(more than 10 cm/4 inches ) for ventilation purposes.

zPoor ventilation may cause an increase in the internal temperature of the

product, resulting in a shortened component life and degraded

performance.

Keep the plastic packaging (bag) out of children’s reach.

zThe plastic packaging (bag) may cause suffocation if children play with

it.

Clean

When cleaning the monitor case or the surface of the TFT-LCD screen, wipe with

a slightly moistened, soft fabric.

Do not spray water or detergent directly on the monitor.

zThis may cause damage, electric shock or fire.

Downloaded from ManualMonitor.com Manuals

Use the recommended detergent with a smooth cloth.

If the connector between the plug and the pin is dusty or dirty, clean it

properly with a dry cloth.

zA dirty connector may cause an electric shock or fire.

Make sure to unplug the power cord before cleaning the product.

zOtherwise, this may cause electric shock or fire.

Unplug the power cord from the power outlet and wipe the product using

a soft, dry cloth.

zDo not use any chemicals such as wax, benzene, alcohol, thinners,

insecticide, air freshener, lubricant or detergent.

Contact the Service Center or Customer Center for interior cleaning

once a year.

zKeep the product's interior clean. Dust which has accumulated in the

interior over an extended period of time may cause malfunction or fire.

Others

Do not remove cover (or back).

zThis may cause an electric shock or fire.

zRefer servicing to qualified service personnel.

If your monitor does not operate normally - in particular, if there are any

unusual sounds or smells coming from it - unplug it immediately and

contact an authorized dealer or the service center.

zThis may cause an electric shock or fire.

Keep the product away from places exposed to oil, smoke or moisture;

do not install inside a vehicle.

zThis may cause malfunction, an electric shock or fire.

zEspecially avoid operating the monitor near water or outdoors where it

Downloaded from ManualMonitor.com Manuals

could be exposed to snow or rain.

If the monitor is dropped or the casing is damaged, turn the monitor off

and unplug the power cord. Then contact the Service Center .

zThe monitor may malfunction, causing an electric shock or fire.

Disconnect the plug from the outlet during storms or lightening or if it is

not used for a long period of time.

zFailure to do so may cause an electric shock or fire.

Do not try to move the monitor by pulling only the wire or the signal

cable.

zThis may cause a breakdown, electric shock or fire due to damage to

the cable.

Do not move the monitor right or left by pulling only the wire or the

signal cable.

zThis may cause a breakdown, electric shock or fire due to damage to

the cable.

Do not cover the vents on the monitor cabinet.

zBad ventilation may cause a breakdown or fire.

Do not place water containers, chemical products or small metal objects

on the monitor.

zThis may cause malfunction, an electric shock or fire.

zIf a foreign substance enters the monitor, unplug the power cord and

contact the Service Center.

Keep the product away from combustible chemical sprays or

inflammable substances.

zThis may cause an explosion or fire.

Never insert anything metallic into the monitor openings.

zThis may cause an electric shock, fire or injury.

Downloaded from ManualMonitor.com Manuals

Do not insert metal objects such as chopsticks, wire and gimlet or

inflammable objects such as paper and match into the vent, headphone

port or AV ports or etc.

zIt may cause a fire or an electric shock. If an alien substances or water

flows into the product, turn the product off, unplug the power connector

from the wall outlet and contact the Service Center.

If you view a fixed screen for an extended period of time, residual image

or blurriness may appear.

zChange the mode to energy save or set a screensaver to moving picture

when you need to be away from the monitor for an extended period of

time.

Adjust the resolution and frequency to the levels appropriate for the

model.

zInappropriate resolution may cause undesirable picture quality.

22 inch (55,9 cm) - 1680 X 1050

Watching the monitor continuously at a too close angle may result in

eyesight damage.

To ease eye strain, take at least a five-minute break after every hour of

using the monitor.

Do not install the product on an unstable, uneven surface or a location

prone to vibrations.

zDropping the product may cause damage to the product or personal

injury. Using the product in a location prone to vibrations may shorten

the lifetime of the product or may catch fire.

When moving the monitor, turn off and unplug the power cord.

Make sure that all cables, including the antenna cable and cables

connecting to other devices, are disconnected before moving the

monitor.

zFailure to disconnect cables may damage it and lead to fire or an electric

shock.

Place the product out of children’s reach, as they could damage by

hanging onto it.

zA falling product could cause physical damage even death.

When not using the product for an extended time period, keep the

product unplugged.

Downloaded from ManualMonitor.com Manuals

zOtherwise, this may cause heat emission from the accumulated dirt or

degraded insulation, leading to electric shock or fire.

Do not place children’s favorite objects (or anything else that may be

tempting) on the product.

zChildren may try to climb on the product to retrieve an object. The

product could fall, causing physical damage or even death.

Proper Seating Posture During Monitor Use

zPeriodically take a 10 minute break every hour or so to relieve eye

strain.

zPosition the monitor so that your eyes are slightly higher than the

display panel.

zAdjust the LCD screen panel angle so that the panel faces

downwards.

zAdjust the LCD screen panel so that the reflection of the

illumination is minimized for your comfort.

zKeep your arms parallel to the floor and lightly place your hands

on the keyboard.

zPosition the monitor or chair so that your eyes are slightly higher

than the display panel.

Downloaded from ManualMonitor.com Manuals

Please make sure the following items are included with your monitor.

If any items are missing, contact your dealer.

Contact a local deale

to bu

tional items.

Unpacking

Monitor & Slidin

Stand

Manual

Quick Setup Guide

Warranty Card

(Not available in all

locations)

User's Guide,

Monitor Driver,

Natural Color software,

icTune™ software

Cable

Downloaded from ManualMonitor.com Manuals

Other manuals for 225BW - SyncMaster - 22" LCD Monitor

Table of contents

Other Samsung Monitor manuals

Samsung

Samsung S27B800PXM User manual

Samsung

Samsung 305T - SyncMaster - 30" LCD Monitor User manual

Samsung

Samsung HPM5027 User manual

Samsung

Samsung U24E590D User manual

Samsung

Samsung QM98T User manual

Samsung

Samsung SyncMaster 460DR User manual

Samsung

Samsung SyncMaster 570DXn User manual

Samsung

Samsung 400CX - SyncMaster - 40" LCD TV User manual

Samsung

Samsung TT17J Series User manual

Samsung

Samsung F2080 - SyncMaster - 20" LCD Monitor User manual

Samsung

Samsung DB32E User manual

Samsung

Samsung Samsung 900S User manual

Samsung

Samsung 2333HD - SyncMaster - 23" LCD Monitor User manual

Samsung

Samsung SyncMaster 710NT User manual

Samsung

Samsung SyncMaster 592V User manual

Samsung

Samsung SyncMaster 940BW Plus User manual

Samsung

Samsung SYNCMASTER P2050N User manual

Samsung

Samsung TP17LT User manual

Samsung

Samsung 151MP - SyncMaster 151 MP User manual

Samsung

Samsung SyncMaster 931BW User manual

Samsung

Samsung DC40E User manual

Samsung

Samsung QB43R User manual

Samsung

Samsung SyncMaster 2243FW User manual

Samsung

Samsung LTN173KT02-T01 User manual

Popular Monitor manuals by other brands

Linear Acoustic

Linear Acoustic LQ-1000 user guide

AOC

AOC I2579V user manual

Gateway

Gateway FPD1520 user guide

Furuno

Furuno Mu 120c Operator's manual

Asus

Asus VB171D - 17" LCD Monitor Service manual

Dell

Dell S2230MX Setting up

Philips

Philips 107C64 user manual

Dell

Dell S2409WFP user guide

EverFocus

EverFocus EN-7517E instruction manual

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Service manual

Dell

Dell Precision 7680 Connection guide

LG 50PM1M - - 50" Plasma Panel Service manual

Bosch

Bosch DDU 9 manual

Acer

Acer A231HL user manual

Philips

Philips 86BDL4152T user manual

NEC

NEC AccuSync LCD5V user manual

Emay

Emay SleepO2 user manual

IBM

IBM 6360 Product support manual
