Samsung NP-RV518E User manual

User Guide

SAMSUNG

RV413/RV418/RV513/

RV518/RV709/RV718

Contents

Chapter 1. Getting Started

Cautions Regarding OS Support 6

Before You Start 7

Safety Precautions 9

Proper Posture During Computer Use 22

Important Safety Information 25

Replacement Parts and Accessories 27

Regulatory Compliance Statements 29

WEEE SYMBOL INFORMATION 43

Basic Items 44

Overview 45

Front View 45

Status Indicators 46

Right View 47

Left View 48

Bottom View 49

Turn on the computer 50

Attaching the Battery 50

Connect the AC adapter 50

Turn on the computer 51

Using Sleep Mode 52

Chapter 2. Using the computer

Keyboard 54

Touchpad 58

CD Drive (ODD, Optional) 59

Inserting and Ejecting a CD 59

Multi Card Slot (Optional) 61

Adjusting the Volume 63

Chapter 3. Settings and

Upgrade

LCD Brightness Control 66

BIOS Setup 67

Entering the BIOS Setup 67

The BIOS Setup Screen 68

Setting a Boot Password 70

Changing the Boot Priority 72

Upgrading Memory 73

Battery 75

Installing/Removing the Battery 75

Charging the Battery 76

Measuring the Remaining

Battery Charge 77

Extending the Battery Usage Time 77

Using the Security Lock Port 79

Chapter 4. Appendix

Product Specications 82

Chapter 1.

Getting Started

Cautions Regarding OS Support 6

Before You Start 7

Safety Precautions 9

Proper Posture During Computer Use 22

Important Safety Information 25

Replacement Parts and Accessories 27

Regulatory Compliance Statements 29

WEEE SYMBOL INFORMATION 43

Basic Items 44

Overview 45

Front View 45

Status Indicators 46

Right View 47

Left View 48

Bottom View 49

Turn on the computer 50

Attaching the Battery 50

Connect the AC adapter 50

Turn on the computer 51

Using Sleep Mode 52

Cautions Regarding OS Support

zWindows is neither installed nor supplied with this computer.

xTherefore, customers should purchase a Windows XP/Windows Vista/Windows 7 software

license and install the software. Do not install an illegal copy or a copy that has already

been installed on another PC.

cFor the installation procedures and any issues with the operating systems or applications

not supplied by Samsung Computer, contact the corresponding software company.

vThe company will not provide a replacement or refund due to the reason x, c and if our

service engineer visits you due to this problem, a service charge will be applied.

Charge the battery fully when using the computer for the rst time.

Before You Start

Before reading the User Guide, rst check the following information.

Safety Precaution Notations

Icon Notation Description

Warning

Failing to follow instructions marked with this symbol, may

cause personal injury and or fatality.

Caution

Failing to follow instructions marked with this symbol, may

cause slight injury to yourself or damage your property.

Text Notations

Icon Notation Description

Before You Start

Content included in this section includes information

required before using a function.

Caution

Content included in this section includes information

required about the function.

Note

Content included in this section includes helpful information

to use the function.

Samsung Electronics Co., Ltd. 2011

Samsung Electronics Co., Ltd. owns the copyright of this manual.

No part of this manual may be reproduced or transmitted in any form or by any means,

electronic or mechanical, without the consent of Samsung Electronics Co., Ltd.

The information in this document is subject to change without notice due to improving the

performance of the product.

Samsung Electronics shall not be liable for any data loss. Please take care to avoid losing any

important data and backup your data to prevent any such data loss.

About the Product Capacity Representation Standard

About HDD Capacity Representation

The capacity of the storage device (HDD, SSD) of the manufacturer is calculated assuming that

1KB=1,000 Bytes.

However, the operating system (Windows) calculates the storage device capacity assuming

that 1KB=1,024 Bytes, and therefore the capacity representation of the HDD in Windows is

smaller than the actual capacity due to the difference in capacity calculation.

(E.g. For a 80GB HDD, Windows represents the capacity as 74.5GB, 80x1,000x1,000x1,000

byte/(1,024x1,024x1,024)byte = 74.505GB)

In addition, the capacity representation in Windows may be even smaller because some

programs such as Recovery Solution may reside in a hidden area of the HDD.

About Memory Capacity Representation

The memory capacity reported in Windows is less than the actual capacity of memory.

This is because BIOS or a video adapter uses a portion of memory or claims it for further use.

(E.g. For 1GB(=1,024MB) memory installed, Windows may report the capacity as 1,022MB or

less)

Installation Related

Do not install the product in

places exposed to humidity

such as a bathrooms.

There is a danger of electric

shock. Use the product within

the operating conditions

specied in the Manufacturers

User Guide.

Keep the plastic bags out of

the reach of children.

There is a danger of

suffocation.

Keep a distance of 15cm or

more between the computer

and the wall and do not place

any objects between them.

This may increase the internal

temperature of the computer

and may cause an injury.

Do not install the computer

on a slant or a place prone to

vibrations, or avoid using the

computer in that location for

a long time.

This increases the risk that a

malfunction or damage to the

product will occur.

Avoid exposing any part of

your body to the heat from

the computer vent or AC

adapter for a long time when

the computer is on.

Exposing a part of your body

close to the heat from the vent

or AC adapter for long periods

of time may cause a burn.

Avoid blocking the vent at

the bottom or side of the

computer when using it on a

bed or cushion.

If the vent is blocked, there

is a danger of damaging the

computer or overheating the

inside of the computer.

Safety Precautions

For your security and to prevent damage, please read the following safety instructions

carefully.

Since this is commonly applied to Samsung Computers, some pictures may differ from

actual products.

Warning

Failing to follow instructions marked with this symbol may cause personal injury and even fatality.

NP Ver 2.8

Power Related

The power plug and wall outlet gures may differ depending on the country specications and

the product model.

Do not touch the main plug or

power cord with wet hands.

There is a danger of electric

shock.

Do not exceed the standard

capacity (voltage/current) of

a multiplug or power outlet

extension when using it for

the product.

There is a danger of electric

shock or re hazard.

If the power cord or power

outlet makes a noise,

disconnect the power cord

from the wall outlet and

contact a service center.

There is a danger of electric

shock or re hazard.

Do not use a damaged or

loose main plug or power

cord or power outlet.

There is a danger of electric

shock or re hazard.

Plug the power cord rmly

into the power outlet and AC

adapter.

Failing to do so may cause re

hazard.

Do not unplug the power cord

out by pulling the cable only.

If the cord is damaged, it may

cause electric shock.

Do not bend the power cord

excessively or do not place

a heavy object over the

power cord. It is especially

important to keep the power

cord out of reach of infants

and pets.

If the cord is damaged, it may

cause electric shock or re.

Connect the power cord to

an outlet or multiple power

plug (extended cable) with a

ground terminal.

Failing to do so may result in

electric shock.

Warning

Failing to follow instructions marked with this symbol may cause personal injury and even fatality.
