Samsung HT-BD2 Technical manual

System Upgrade by CD Method for HT-BD2

Introduction

This manual describes System Upgrade procedure for HT-BD2. If you have any problems during

System Upgrade, please contact Samsung Customer Service Center.

How to make a firmware update CD

Please follow the below procedures.

1 Download the new ‘firmware’ file from www.samsung.com

2 If the firmware file is compressed (*.zip/rar), the file should be uncompressed to CD image

file (*.iso).

3 Please burn the CD image file on a blank CD-R/RW disc

1) Recommended CD Burning Program is Nero Burning ROM.

2) Burning Options (in case of using Nero Burning ROM)

A. ‘Recorder’ menu  ‘Burn Image…’  Select an uncompressed image file(*.iso)

B. Please check ‘Finalize CD (No further writhing possible!)’

C. Please refer to your own CD burning Program Manual if you want to use any other

CD burning program for burning ISO image file.

D. Make sure if the downloaded software is eligible for your HT-BD2.

E. The system upgrade may not be executed if the update CD was made without

following the upper procedure

Warning

The following events may interrupt the upgrade process and MAY RESULT IN PERMANENT

DAMAGE TO THE UNIT WHILE UPGRADING.

1. Unplugging the power plug

2. Power Outage

3. Dirt or Scratches on the burned CD-R/RW disc

4. Closing or opening the disc tray during the update process

How to upgrade the HT-BD2

1. Press OPEN/CLOSE button to open the disc tray.

2. Insert the upgrade CD.

3. Press OPEN/CLOSE button to close the disc tray.

4. Please wait about 6 minutes while verifying.

Verifying Firmware Version.

5. When below message box comes up, please check the date of the Firmware version.

Do you want to update Firmware?

>Current Version : 070730.02_XAA

>New Version : 070903.01_XAA

Yes No

6. Press ‘Enter’ button to choose ‘Yes’ for upgrade and please remove the disc on the tray.

If you select ‘No’, HT-BD2 will be automatically powered off.

If you don’t see above message box, try another disc. Generally, this is caused by disc

quality or disc creation problem.

7. Please wait for about 7 minutes.

Firmware Update.

Now, Processing…

Please, do not turn off the power.

8. When finished, the screen and the power will turn off automatically.

9. Turn on the unit again. The tray will close automatically. Below screen will show up. Please

select the language you want with a corresponding number button.

MENU LANGUAGE SELECTION

Press 1 for English

Pulsar 2 para Español

Touche 3 pour Français

Macrovision : BSS01

10. If you want to do System Upgrade through the network, please refer to ‘System Upgrade’

Article on the User’s Manual.
