Samsung Level Over EO-AG900 User manual
GH68-00000A Rev.1.0
2013/11
www.samsung.com
User manual
EO-AG900
Refer to page 12 for safety information.
4
Images may differ in appearance
from the actual product. Content
is subject to change without prior
notice.
Package contents
Check the product box for the following
items. The items supplied with the device
and any available accessories may vary
depending on the region or service
provider.
• Device
• Hard case
• Soft case (Acc. kit)
• USB cable
• 3.5 mm audio cable
• 6.3 mm stereo plug
• Flight adaptor
• User manual
Getting started
Device layout
TBD
TBD
5
Getting started
TBD
After fully charging, disconnect the
device from the charger. First unplug the
charger from the device, and then unplug
it from the electric socket.
• To save energy, unplug the
charger when not in use. The
charger does not have a power
switch, so you must unplug the
charger from the electric socket
when not in use to avoid wasting
power. The charger should
remain close to the electric
socket and easily accessible while
charging.
• The socket-outlet shall be
installed near the equipment and
shall be easily accessible.
Charging the battery
This device has a built-in battery. Before
using the device for the first time or
when the battery has been unused for
extended periods, you must charge the
battery.
Use only Samsung-approved
chargers and cables. Unapproved
chargers or cables can cause the
battery to explode or damage the
device.
Charge the device by connecting it to the
computer or the USB power adaptor via
the USB cable.
• The notification light turns red while
the device is being charged. The
notification light turns green when
charging is complete.
6
Getting started
Turning the device on or off
Slide the power switch up to turn on the
device. When the device is turned on, the
notification light flashes blue.
TBD
Slide the power switch down to turn off
the device. When the device is turned off,
the notification light turns blue and then
flashes red before turning off.
Charging time and standard run
times (800 mAh)
Charging
time Approx. 2.5 hrs
Standard
run times
Call time Approx.
15 hrs
Play time Approx.
15 hrs
Standby
time
Approx.
2,000 hrs
• Charging time is measured
after charging with a Samsung-
approved charger.
• Battery run time is results of tests
performed in the manufacturer's
laboratory. Standby time was
measured at the time of first
shipment.
• The battery charging time and
run time may vary depending
on the environment the device
is used in.
7
Getting started
Connecting via the NFC feature
1
Activate the NFC feature on the other
device.
2
Turn on the device and place the other
device’s NFC antenna near the NFC
antenna area on the left earpiece of
your device.
If you are connecting to other
devices, ensure that the screen on
the connected device is unlocked.
The NFC feature does not work
when the connected device's
screen is locked.
TBD
Connecting to other devices
You can connect the device to other
Bluetooth-enabled devices, such as
smartphones or computers.
You can connect to an other
Bluetooth-enabled device only
after disconnecting a previously
connected device.
Connecting via the Bluetooth
feature
1
Turn on the device. Press and hold the
Bluetooth button for about 3 seconds.
The device enters the Bluetooth
pairing mode and the notification light
flashes red, green, and then blue.
2
On the Bluetooth-enabled device,
access the Bluetooth setup mode and
search for Bluetooth devices.
3
From the search results, select the
device name.
When pairing is complete, the device's
name appears in the device list.
8
Using the device
Use one of the following methods to
disconnect a device:
• Turn off the device.
• Disconnect the Bluetooth feature
between your device and the
connected device.
• Place another device's NFC antenna
near the NFC antenna area on the left
earpiece of your device.
Using the device
Enjoying multimedia files with
the device
You can enjoy multimedia files on other
devices with your device.
Play multimedia files on a connected
device and use the touch panel on the
right earpiece of your device to control
functions.
You can control connected devices
with the touch panel when they
are connected via Bluetooth.
• When two devices are
connected, place your device
near to the connected device.
Otherwise, the device may not
work properly or be affected by
noise interference.
• The connection methods or
NFC antenna area may differ
depending on the connected
devices. For more information,
refer to the user manual of the
connected device.
Disconnecting from other
devices
You can connect to another device
only after disconnecting a previously
connected device.
9
Using the device
• Tap and hold on the touch panel and
draw a circle anticlockwise to decrease
the volume.
TBD
When the device is adjusted to
full volume an alert will sound to
notify you. Adjust the volume on
the connected device when you
cannot hear sounds on your device
at full volume.
• Tap the touch panel to play or pause
playback.
• On the touch panel, drag your finger to
the left to play the previous file or drag
it to the right to play the next file.
TBD
• Tap and hold on the touch panel and
draw a circle clockwise to increase the
volume.
TBD
10
Using the device
Receiving a call
If a smartphone is connected to the
device, you can answer a call.
Use the touch panel on the right earpiece
of your device and use one of the
following methods to control calls:
• Tap the touch panel to answer a call.
• Tap and hold the touch panel to reject
a call.
• Tap and hold on the touch panel and
draw a circle clockwise to increase the
volume.
• Tap and hold on the touch panel and
draw a circle anticlockwise to decrease
the volume.
Connecting via an audio cable
You can connect a smartphone or media
player to the device with an audio cable.
TBD
• Before connecting a device via
the audio cable, disconnect any
other connected devices.
• When the device is turned off,
you can adjust the volume when
playing multimedia files with the
connected device only.
11
Appendix
Specifications and features
Dimensions(mm) 164.3 X 62.3 X 69.2
Weight(±1 g) 350 g
Transmission
power 1 mW
Bluetooth
frequency 2402 ~ 2480 MHz
Bluetooth
version 3.0
Supported
Bluetooth profile
A2DP, HSP, HFP,
AVRCP
Identification
code
MSIP-CMM-SEC-
EO-AG900
Wireless
connection
range
10 m
NFC frequency 13.56 MHz
Operating
temperature 5 °C ~ 35 °C
The wireless connection range
may vary depending on the
environment the device is used in.
