Safety 1st WANDERER X User manual

17KG0m+

3 WHEEL STROLLER

WANDERER X

Suitable for newborn to 17kg

Illustration and designs may vary.

017002 - 017003 - Wanderer X Stroller - 01 - 16

CONTENTS

Warnings ......................................................................................................... 3

Components list ........................................................................................ 4 - 5

ASSEMBLING THE STROLLER

Opening Stroller ............................................................................................. 6

Wheel Assembly ......................................................................................... 7 - 8

Fitting Seat ...................................................................................................... 9

Bumper Bar ................................................................................................... 10

USING THE STROLLER

Canopy .......................................................................................................... 11

Front Swivel Wheel ....................................................................................... 12

Operating Brakes ......................................................................................... 13

Adjusting Handle / Backrest / Legrest .................................................. 14 - 15

Securing your Child ........................................................................................ 16

Adjusting Harness Height / Tether Strap ....................................................... 17

Folding / Unfolding / Carrying Stroller ................................................... 18 - 19

BASSINETTE AND INFANT CARRIER

Install and Use Bassinette .................................................................... 20 - 22

Install and Use Infant Carrier ................................................................ 23 - 24

CARE AND MAINTENANCE

Care and Maintenance ................................................................................. 25

Notes ..................................................................................................... 26 - 27

CONTACTS

Customer Service ....................................................................................... 28

017002 - 017003 - Wanderer X Stroller - 01 - 16

ALWAYS APPLY THE BRAKES WHENEVER THE STROLLER IS

STATIONARY.

• DO NOT LEAVE CHILDREN UNATTENDED.

• DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS

STROLLER.

• MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS

IF YOU ADJUST THE STROLLER, OTHERWISE THEY MAY BE

INJURED.

• SECURE THE CHILD IN THE HARNESS AT ALL TIMES AND

ENSURE THAT THE SAFETY HARNESS IS ADJUSTED FIRMLY

BUT COMFORTABLY TO THE CHILD’S BODY.

• A harness can form loops that may be a strangulation hazard, never

leave harness straps connected when not fitted to a child in the stroller.

• Use the tether strap to prevent the stroller rolling away.

• Do not allow children to stand on the seat or footrest.

• Do not attempt to lift the stroller by the bumper bar.

• Remove the child from the stroller before going up or down stairs

or escalators.

• Engage front wheel swivel locks when travelling on rough or uneven

surfaces.

• Regularly inspect the stroller for any parts that are loose, broken, torn

or missing. Attend to the problem as soon as it is noticed.

• Use only those accessories which are supplied by Dorel Australia and

approved for use with this stroller.

• Do not use the stroller near an open fire, barbecue or exposed flame.

• This product is not intended for commercial use.

• Do not run or jog with this stroller.

• This product is tested to AS/NZ 2088:2013

WARNING TO AVOID INJURY OR DEATH:

These instructions detail the safe use, assembly and maintenance of your

product. Please read these instructions carefully and ensure that they are

followed at all times. Failure to do so could result in serious injury or death.

017002 - 017003 - Wanderer X Stroller - 01 - 16

Maxi-Cosi Infant Carrier Wanderer Bassinette

Note:

• The weight of the child using this stroller should not be more than 17kg.

• Total weight for the shopping basket should not be more than 4kg.

• The weight of the child using the Infant Carrier should not be more

than 9kg.

• The weight of the child using the Bassinette should not be more

than 9kg.

• Please refer to instruction manuals of the Maxi-Cosi Infant Carrier

& Wanderer Bassinette for full weight and height specifications.

Components Sold Separately

Maxi-Cosi Infant

Carrier Adaptors x2

Safety 1st

Universal Raincover

017002 - 017003 - Wanderer X Stroller - 01 - 16

Component List

1. Handle Height Adjustment

2. Tether Strap

3. Folding Lock (both sides)

4. Storage Latch

5. Shopping Basket

6. Brake Lever (both sides)

7. Rear Wheels Assembly

8. Never Flat Tyres (x3)

9. Canopy

10. Marle Seat Pad

11. Bumper Bar

12. Harness Pads

13. Safety Harness

14. Adjustable Legrest

15. Swivel Wheel Lock

16. Front Wheel

017002 - 017003 - Wanderer X Stroller - 01 - 16

OPENING STROLLER

• If the stroller has a security tie, please remove it.

• Lift storage latch to release, as per Figure 1a.

• Unfold stroller by lifting handle as per Figure 1b until the locking

mechanism engages, as per Figure 1c.

Assembling: Wanderer Stroller

Lift

Storage Latch

Lift

Note:

• Folding strollers and accessories will always have the potential

to trap fingers or parts of the body between moving parts, causing

injuries. Care should be taken while folding or unfolding.

• This vehicle is designed for use on flat or gently sloping surfaces

and may be unstable on higher sloping and uneven surfaces.

You should always be aware of the possibility of the stroller

tipping on uneven or higher sloping surfaces.

017002 - 017003 - Wanderer X Stroller - 01 - 16

Assembling: Wanderer Stroller

TO FIT REAR WHEELS

• Slide rear wheel onto the wheel hub, as per Figure 2a.

• Repeat for other side.

TO REMOVE REAR WHEELS

• Push and hold metal tab, as per Figure 2b.

• Pull rear wheel from the hub, as per Figure 2c.

• Repeat on other side.

Push

Assembling: Wanderer Stroller

Note:

Never Flat tyres do not require air.

The tyres are maintenance free.

017002 - 017003 - Wanderer X Stroller - 01 - 16

TO FIT FRONT WHEEL

• Lift the front of the stroller and push the shaft into the front wheel hub, as per

Figure 3a.

• Listen for ‘CLICK’ to confirm locking position.

TO REMOVE FRONT WHEEL

• Slide the plastic button while pulling the front wheel off the front hub, as per

Figure 3b.

Assembling: Wanderer Stroller

Push

Pull

Click!

3a 3b

Slide

017002 - 017003 - Wanderer X Stroller - 01 - 16

TO FIT THE SEAT

• The seat can be positioned in either the forward facing Figure 4a or

rearward facing Figure 4c configuration. Insert the seat onto the frame by

lowering the seat into the frame, as per Figure 4b.

• Listen for ‘CLICK’.

TO REMOVE THE SEAT

• Slide and hold down button (A) with one hand and press button (B) with the

other hand, as per Figure 4d.

• Then press button (C) and lift out the seat, as per Figure 4e.

Assembling: Wanderer StrollerAssembling: Wanderer Stroller

Push

Press (B)

Slide (A)

Click!

Do not use this seat with any other models of stroller.

WARNING

Press (C)

Opposite side

Lift

017002 - 017003 - Wanderer X Stroller - 01 - 16

TO FIT BUMPER BAR

• Align bumper bar mounting slider with the mounting brackets, as per

Figure 5a and slide down until it locks into place.

• Repeat on other side.

TO REMOVE BUMPER BAR

• Remove bumper bar from frame.

• Press the plastic button and slide bumper bar upwards, as per Figure 5b

&Figure 5c.

Using: Wanderer Stroller

Slide

Push

Slide

5a 5b
