Royal Sovereign RMF-113SS User manual
Royal Sovereign International, Inc.
RMF-113SS / RMF-113B
COMPACT REFRIGERATOR
Owner's Manual
Please read and retain these instructions.
To register your product, please go to www.royalsovereign.com
www.royalsovereign.com
Page en Français 15
COMPACT REFRIGERATOR
Model RMF-113SS / RMF-113B
INTRODUCTION
Thank you for choosing Royal Sovereign Compact Refrigerator, RMF-113SS / RMF-113B. This Compact
Refrigerator can be set-up in just minutes and easily operated to keep food fresh and beverages cool. This manual
will provide you information for operation, use, and maintenance. Please take a few moments to read the
instructions thoroughly and always follow the precautions.
RMF-113SS / RMF-113B
3
SAFETY PRECAUTIONS
Read all of the instructions before using this appliance. When using this appliance, always exercise basic safety precautions, including the
following:
NOTE: If the refrigerator has been placed in a horizontal or tilted position for any period of time wait 24 hours before plugging the unit in.
1) Use this appliance only for its intended purpose as described in this use and care guide.
2) This refrigerator must be properly installed in accordance with the installation instructions before it is used. See grounding instructions
in the installation section.
3) Never unplug your refrigerator by pulling on the power cord. Always grasp the plug firmly and pull straight out from the outlet.
4) Repair or replace immediately, all electric service cords that have become frayed or otherwise damaged. Do not use a cord that shows
cracks or abrasion damage along its length, the plug or the connector end.
5) Unplug your refrigerator before cleaning or before making any repairs.
NOTE: If for any reason this product requires service, we strongly recommend that a certified technician performs the service.
6) Do not use any electrical device or any sharp instrument in defrosting your refrigerator.
7) If your old refrigerator is not being used, we recommend that you remove the doors and leave the shelves in place. This will reduce the
possibility of danger to children.
8)
After your refrigerator is in operation, do not touch the cold surfaces in the freezer compartment, particularly when hands are damp or wet.
Skin may adhere to these extremely cold surfaces.
9) Do not refreeze foods that have been thawed completely. The United States Department of Agriculture in Home and Garden Bulletin No.
69 reads: “…You may safely refreeze frozen foods that have thawed if they still contain ice crystals or if they are still cold-below 40°F.
“…Thawed ground meats, poultry, or fish that have any off-odour or off-colour should not be refrozen and should not be eaten. Thawed
ice cream should be discarded. If the odour or colour of any food is poor or questionable, discard it. The food may be dangerous to eat.
“…Even partial thawing and re-freezing reduce the eating quality of foods, particularly fruits, vegetables, and prepared foods. The eating
quality of red meats is affected less than that of many other foods. Use refrozen foods as soon as possible, to save as much of its eating
quality as you can.”
10) This refrigerator should not be recessed or built-in in an enclosed cabinet. It is designed for freestanding installation only.
11) Do not operate your refrigerator in the presence of explosive fumes.
4
CONTENTS
SAFETY PRECAUTIONS 3
PARTS 5
INSTALLING YOUR REFRIGERATOR 6
REFRIGERATOR FEATURES AND USE 8
PROPER REFRIGERATOR CARE AND CLEANING 10
TROUBLESHOOTING 12
SPECIFICATIONS 13
WARRANTY 14
CONTACT INFORMATION 14
PAGE EN FRANÇAIS 15
RMF-113SS / RMF-113B
5
PARTS
1. 3/4-Width Freezer Compartment
2. Adjustable Temperature Control
3. Fixed Door Shelves
4. "Dispense-A-Can"TM Storage
5. Accomodates 2 liter and tall bottles
6. Adjustable Front Leveling Legs
7. Removable Glass Shelves
8. Drip Tray
9. Ice Cube Tray
1
2
3
4
5
6
7
8
9
6
INSTALLING YOUR REFRIGERATOR
Unpacking Your Refrigerator
1. Remove all packaging material. This includes the foam base and all adhesive tape holding the refrigerator accessories inside and outside.
2. Inspect and remove any remains of packing, tape or printed materials before powering on the refrigerator.
Leveling Your Refrigerator
• Your refrigerator has two leveling legs which are located in the front bottom corners of your refrigerator. After properly placing your
refrigerator in its final position, you can level your refrigerator.
• Leveling legs can be adjusted by turning them counterclockwise to raise your refrigerator or by turning them clockwise to lower your
refrigerator. The refrigerator door will close easier when the leveling legs are extended.
Proper Air Circulation
•To ensure your refrigerator works at the maximum efficiency it was designed for, you should install it in a location where there is proper air
circulation, plumbing and electrical connections.
• The following are recommended clearances around the refrigerator:
Sides 3/4" (19mm)
Top 2" (50mm)
Back 2" (50mm)
Electrical Requirement
• Make sure there is a suitable power outlet (115 volts, 15 amps outlet) with proper grounding to power the refrigerator.
• Avoid the use of three prong adapters or cutting off the third grounding prong in order to accommodate a two prong outlet. This is a
dangerous practice since it provides no effective grounding for the refrigerator and may result in shock hazard.
Use of Extension Cords
• Avoid the use of an extension cord because of potential safety hazards under certain conditions. If it is necessary to use an extension
cord, use only a 3-wire extension cord that has a 3-blade grounding plug and a 3-slot outlet that will accept the plug. The marked rating of
the extension cord must be equal to or greater than the electrical rating of the appliance.
Installation Limitations
• Do not install your refrigerator in any location not properly insulated or heated, e.g. garage, etc. Your refrigerator was not designed to
operate in temperature settings below 55˚ Fahrenheit.
• Select a suitable location for the refrigerator on a hard even surface away from direct sunlight or heat source, e.g. radiators, baseboard
RMF-113SS / RMF-113B
7
heaters, cooking appliances, etc. Any floor unevenness should be corrected with the leveling legs located on the front bottom corners of the
refrigerator.
Reversing the Door Hinge
1. Remove the top hinge cover.
2. Using Phillips Head Screwdriver, loosen and remove the screws holding the top hinge in place.
3. Remove top hinge and carefully lift off the door.
4. Remove the screw hole plugs from the opposite side and insert the plugs in the screw hole openings of the just removed screws.
5. Remove any loose items in the refrigerator and carefully turn refrigerator on its back and place in a secure area.
6. Loosen the screws holding the lower hinge bracket to the refrigerator and remove screws and bracket.
7. Remove (2) screws from the other side and insert in the previously removed screw holes.
8. Remove door pin by turning counter clockwise and reinsert to the underside of the bracket and tighten.
9. Align bracket and insert (2) remaining screws into the holes provided .
10. Align hole in the door with the door pin and washer and gently push down until firm.
11. Align upper hinge bracket with screw holes insert screws and partially secure, check that door and cabinet are properly aligned and then
secure tightly.
12. Replace hinge cap.
NOTE: As the door gets pressed in during shipping, after reversing the door, the gasket may have to be reset. This is done to prevent the
cool refrigerated air from escaping. If there is a gap between the door gasket and the cabinet, set the gasket by gently pulling it out to
seal the gap.
8
Door Alignment
1. Remove the top hinge cover.
2. Loosen the top hinge screws using a phillips head screwdriver.
3. Adjust the door or put a spacer in between and then tighten the screws.
4. Replace the top hinge cover.
REFRIGERATOR FEATURES AND USE
General Features
Adjustable temperature dial:
Your refrigerator will automatically maintain the temperature level you select.
The temperature control dial has 7 settings plus "0". 1 is the warmest. 7 is the coldest. At first, set the dial to 4 and allow 24 hours to pass
before adjusting the temperature to your needs.
Note:
If the refrigerator has been placed in a horizontal or tilted position for any period of time wait 24 hours before plugging the unit in.
Freezer Compartment / Use of the Ice Cube Tray
This compartment is designed for making ice cubes and for short-term food storage (a few days at most).
WARNING: This compartment is not cold enough to freeze foods safely for more than 5 days.
• If ice cube tray freezes to the bottom of the compartment, pour a little warm water around it to loosen it. Do not use boiling water, which can
damage plastic parts, or sharp metal objects such as a knife or screwdriver, which can damage the cooling system tubing. Wash the ice
cube tray in lukewarm water only. Do not wash in the dishwasher.
Refrigerator Interior Shelves
To remove or replace a full-width slide-out shelf:
(see fig. # 1)
1. Gently tilt the shelf up and slide forward until the shelf has been completely
removed.
2. To replace the shelf, gently slide the shelf back.
fig. 1
RMF-113SS / RMF-113B
9
Using the Dispense-A-Can™
• Your refrigerator is equipped with the convenient “Dispense-A-Can™” compartment. The compartment
will hold up to five cans. Simply load the cans from the top. To dispense a can, simply draw one out from
the bottom. It is that easy.
Food Storage Information
Fresh Food
• When storing fresh food that is not prepackaged, be sure to wrap or store food in airtight and moisture
proof material unless otherwise noted. This will ensure proper shelf life and prevent the transfer of odors
and tastes.
• Wipe containers before storing to avoid needless spills.
• Eggs should be stored in an upright position in their original carton to maximize shelf life.
• Fruit should be washed and dried, then stored in sealed plastic bags before storing in the refrigerator.
• Vegetables with skins should be stored in plastic bags or containers.
• Leafy vegetables should be washed and drained and then stored in plastic bags or containers.
• Hot food should be allowed to cool before storing in the refrigeration. This will prevent unnecessary
energy use.
• Fresh seafood should be used the same day as purchased.
• When storing meats in the fresh food section, keep in the original packaging or rewrap as necessary. Follow the suggestions below for safe
storage:
• Chicken 1-2 Days
• Ground Beef 1-2 Days
• Cold Cuts 3-5 Days
• Steaks/Roasts 3-5 Days
• Smoked/Cured Meats 7-10 Days
• All others 1-2 Days
Normal Operating Sounds You May Hear
• Boiling water, gurgling sounds or slight vibrations that are the result of the refrigerant circulating through the cooling coils.
• The thermostat control will click when it cycles on and off.
fig. 2
10
PROPER REFRIGERATOR CARE AND CLEANING
Cleaning and Maintenance
Warning: To avoid electric shock, always unplug your refrigerator before cleaning. Ignoring this warning may result in death or injury.
Caution: Before using cleaning products, always read and follow manufacturer’s instructions and warnings to avoid personal injury or product
damage.
General: Prepare a cleaning solution of 3-4 tablespoons of baking soda mixed with warm water. Use sponge or soft cloth, dampened with the
cleaning solution, to wipe down your refrigerator.
• Rinse with clean warm water and dry with a soft cloth.
• Do not use harsh chemicals, abrasives, ammonia, chlorine bleach, concentrated detergents, solvents or metal scouring pads.
Some of these chemicals may dissolve, damage and/ or discolor your refrigerator.
Door Gaskets: Clean door gaskets every three months according to general instructions. Gaskets must be kept clean and pliable to assure a
proper seal.
• Petroleum jelly applied lightly on the hinge side of gaskets will keep the gasket pliable and ensure a good seal.
Defrosting
Defrost whenever frost on the wall of the freezer compartment becomes 1/8" thick. Never us a sharp or metallic instrument to remove frost as
it may damage the cooling coils. (A punctured cooling coil will cause serious damage to the product and will void the warranty). We
recommend using a plastic scraper. To defrost,
remove foods and ice cube tray from the freezer
compartment. Make sure the drip tray is in place and
unplug the unit. Defrosting usually takes a few hours.
To defrost faster, keep the door open and place a
bowl of warm water in the refrigerator. After
defrosting, empty water from the drip tray and wash
the drip tray in warm water.
