Rowlett Rutland ESPRIT User manual
Never move a toaster whilst it is operating. Wipe down with a damp cloth
and proprietary multi-surface cleaner to remove any grease. Never use a
scouring agent as this will scratch the finish. Always empty your crumb
tray at frequent intervals as this aids toasting performance and reduces
the risk of smell, smoke and burning. On the multi and Sandwich models
after each use ensure any spilt filling is removed from carrier and crumb
tray.
Bread containing fruit or nuts can be toasted but natural sugars present
may cause them to stick to the guard rails on your toaster. Such debris
should not be left on the guard rails as it will char and possibly smoke
and can swell so as to damage the element.
Once the timer has started an element gives out heat from both sides, so
the first “unpowered” slot will always give out heat on one side.
SERVICING & REPAIRS
Elements wear out with use and it is impossible to predict their life as this
is affected by the amount and type of use and the quality of electrical
supply. They can easily be damaged by careless handling. Your toaster
has been designed that should anything go wrong all major components
such as elements and switches can easily be replaced.
Repairs or replacement of components should be undertaken only by a
competent electrician. All components and fitting instructions can be
obtained from your supplier or directly from the manufacturer.
Rowlett Rutland Ltd
32 Bookham Industrial Park,Church Road,
Bookham,Surrey, UK. KT23 3EU
Tel: +44 (0)1372 453633/450855 Fax: +44 (0)1372 453536/453671
Issue 2 for 220-240V a.c. FEB 2002
ESPRIT SANDWICH
TOASTER
INSTRUCTION BOOK
All toasters are supplied fitted with a suitable plug. Please
ensure that all packaging materials have been removed
before you use your toaster.
SAFETY – PLEASE READ!
The temperature of accessible surfaces may be high
when the appliance is operating.
Bread may burn. Therefore toasters must not be used near
or below curtains and other combustible materials. They
must be watched.
Do not leave toasters plugged into a live socket when not in
use. Always switch off at the plug.
Always allow a toaster to cool before putting away - allow
15 minutes. Never move a toaster whilst in use.
Before doing any maintenance ensure that the toaster is
unplugged from the electrical supply.
Never use a knife or other sharp instrument to clear
jammed slots or burnt crumbs (not only can this be
dangerous but it can damage the elements).
If the power supply cable is damaged then the whole
toaster must be returned to the supplier or other qualified
person for replacement.
NEVER IMMERSE A TOASTER IN WATER
Ensure your Rowlett Rutland toaster is plugged in before turning
it on. There is no separate on/off switch on the toaster as it
forms part of the timer mechanism. Your toaster is "off" when
the number "O" is on the top of the dial. All toasters have a
Rotary switch (C) that enables you to control which slots are in
use, saving on element wear and electricity. Choose how many
slots you need and adjust the control switch (C) accordingly.
Open the carrier and place the sandwich inside it. Close the
carrier –squeezing the bread will help seal the filling, but the
sandwich should be not so thick that the carrier has to be forced
into the slot. Place the carrier in the slot you wish to use and set
the timer (B) to around position 4. The neon indicator (A) will
light and the timer will start. Power will be automatically turned
off shortly before the timer completes its task. The sandwich
can be removed immediately or left in the machine to keep
warm for several minutes.
Model illustrated is a Esprit 4 Slot Sandwich
FE
C
A
B
D
Now fitted with a Ringer timer as
standard
APower indicator
B Ringer timer
On/off
C Rotary switch
D Crumb tray
E
F
Carrier
Slots L/R
1/2/3/4
2 Slot Sandwich
The 2 Slot Sandwich operates on one Rotary switch (C) that
selects either one or two sandwich/bread mode (both faces
toasted) or (1B)position for bun/bagel mode (one face only
toasted).
4 Slot Sandwich
The 4 Slot Sandwich operates on one Rotary switch (C) that
selects one,two,three or four sandwich/bread mode (both faces
toasted) or 2 position (1B) for one bun/bagel or (2B) for 2 bun/
bagel. Use a timer setting of between 2 and 3 (bun/bagel), around
3 for toast and between 3 and 4 for sandwiches. You must use
the carriers provided to hold the buns, bagels, bread or
sandwiches.
Making toasted sandwiches
Sandwiches should be made in the normal way (ie buttered on
the inside). A wide variety of fillings can be used but all
ingredients should be chopped or shredded to assist the cooking
process. Hard cheese should always be grated. Meat, fish, eggs
etc should always be pre-cooked.
We recommend that the intended toaster slot is warmed up
first by turning the timer on for one or two minutes before
cooking the sandwich.
Leaving the sandwich in the toaster for a few seconds after
toasting is completed will also help the cooking process.
CARE & MAINTENANCE
