Ross Vision 4800DR-319-03 User manual
Ross Video Limited
Touchscreen Display
Installation Guide
V I S I O N
2
Vision • Touchscreen Display Installation Guide
• Ross Part Number: 4800DR-319-03
• Release Date: January 13, 2012. Printed in Canada.
The information contained in this guide is subject to change without notice or
obligation.
Copyright
© 2012 Ross Video Limited. All rights reserved.
Contents of this publication may not be reproduced in any form without the
written permission of Ross Video Limited. Reproduction or reverse engineering
of copyrighted software is prohibited.
Patents
This product is protected by the following US Patents: 4,205,346; 5,115,314;
5,280,346; 5,561,404; 7,034,886; 7,508,455; 7,602,446; 7,834,886. This
product is protected by the following Canadian Patents: 2039277; 1237518;
1127289. Other patents pending.
Notice
The material in this guide is furnished for informational use only. It is subject to
change without notice and should not be construed as commitment by Ross
Video Limited. Ross Video Limited assumes no responsibility or liability for
errors or inaccuracies that may appear in this guide.
Trademarks
•is a trademark of Ross Video Limited.
• Ross, ROSS, ROSS®, and MLE are registered trademarks of Ross
Video Limited.
•All other product names and any registered and unregistered
trademarks mentioned in this guide are used for identification
purposes only and remain the exclusive property of their
respective owners.
3
Important Regulatory and Safety Notices to Service
Personnel
Before using this product and associated equipment, refer to the “Important
Safety Instructions” listed here and in the front of the Vision Engineering
Manual, to avoid personnel injury and to prevent product damage.
Products may require specific equipment, and/or installation procedures to be
carried out to satisfy certain regulatory compliance requirements. Notices have
been included in these publications to call attention to these specific
requirements.
Important Safety Instructions
Use only manufacturer approved Power Supplies and Power Cords supplied
with this product.
The power supply adapter(s) included with this product use a protective earth
connection to reduce the risk of electrical shock to the operator and or service
personnel. A grounding conductor in the equipment's supply cord provides this
protective earth connection and must be reliably connected to a facilities
protective earth.
Do not defeat safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The third prong is provided for
your safety. If the provided plug does not fit in to your outlet, consult an
electrician for replacement of the obsolete outlet.
Protect the product’s power cord(s) and replace any cord(s) which shows signs
of physical damage or ware.
The product's power supply cord(s) is (are) used as a means to disconnect the
power supply from the AC Mains. Ensure either the appliance inlet or the mains
plug of the power supply cord, remains readily operable.
This product is designed for Indoor Use:
“WARNING - TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPERATUS TO RAIN OR MOISTURE”.
General Handling Guidelines
• Careful handling, using proper ESD precautions, must be observed.
• Power down the system before PCB removal.
4
ESD Susceptibility — Avoid handling the switcher circuit
boards in high static environments such as carpeted areas, and
when synthetic fiber clothing is worn. Touch the frame to
dissipate static charge before removing boards from the frame,
and exercise proper grounding precautions when working on
circuit boards.
Environmental Information
The equipment that you purchased required the extraction and use
of natural resources for its production. It may contain hazardous
substances that could impact health and the environment.
To avoid the potential release of those substances into the environment and to
diminish the need for the extraction of natural resources, Ross Video encourages
you to use the appropriate take-back systems. These systems will reuse or
recycle most of the materials from your end-of-life equipment in an
environmentally friendly and health conscious manner.
The crossed-out wheeled bin symbol invites you to use these systems.
If you need more information on the collection, reuse, and recycling systems,
please contact your local or regional waste administration.
You can also contact Ross Video for more information on the environmental
performances of our products.
Package Contents • 5
Package Contents
The contents of the Touchscreen Display upgrade kit are listed below. If any
items are missing, or damaged, contact Ross Video Technical Support.
Qty Part# Item
1 V-100A or V-100B Touchscreen Display
1a
a. Will be quantity 2 if Redundant Power Option is ordered.
103-011R Power Supply
1b
b. Will be quantity 2 if Redundant Power Option is ordered.
330-002R Power Cable
1726-170R DVI Cable (Black DVI-D cable)
1 727-016R USB Cable (Black USB 2.0 A/B cable)
1727-021R Control Cable (Black CAT5 cable)
6 • Touchscreen Display Control Connection
Touchscreen Display Control
Connection
Ross Video does not provide a mounting arm with the Vision control panel.
When selecting a mounting arm, you should consider the environment that the
control panel will be operating in. For example, in a mobile or truck
environment, a more rigid mounting arm is needed to secure the Touchscreen
Display.
Operating Tip — Ross Video recommends the Humanscale
M7 Desk Mount Flat Panel Monitor Arm by Media Control Co.,
Inc. (mcergo.com).
Use the following procedure to connect the Touchscreen Display to the Vision
control panel (Figure 1):
1. Secure the Touchscreen Display (Figure 1) to the VESA FDMI
MIS-D 75 or 50, C Mounting Arm using the screws provided with
the mounting arm and position the display as desired.
Figure 1 Control Panel to Touchscreen Display Cable Connections
2. Connect and secure one end of the DVI Cable to the DVI port on the
back of the Vision control panel (Figure 2).
3. Connect and secure the other end of the DVI Cable to the DVI port on
the Touchscreen Display.
VGA DVI PS1 USB
PREV NEXT
PS2
VESA FDMI
Mounting Holes
Touchscreen Display Control Connection • 7
Figure 2 Touchscreen Display Connections to the Vision Control Panel
4. Connect and secure one end of the Control Cable to the External
Panel Link 1 port on the back of the Vision control panel.
5. Connect and secure the other end of the Control Cable to the PREV
port on the Touchscreen Display.
6. Connect one end of the USB Cable to a USB port on the back of the
Vision control panel. It does not matter which port you use.
7. Connect the other end of the USB Cable to the USB port on the
Touchscreen Display.
Caution — Always connect the External Power Supply to the
Touchscreen before connecting it to the AC mains power.
Connecting the power supply to the AC mains power before
connecting to the Touchscreen could damage the Touchscreen.
8. Connect and secure the Power Supply to the PS1 port on the back of
the Touchscreen Display.
9. If purchased, connect and secure the second Power Supply to the
PS2 port on the back of the Touchscreen Display.
10. Connect the power cables to the appropriate AC mains power outlets.
This completes the procedure for connecting the Touchscreen Display to the
Vision control panel.
VGA DVI PS1 USB
PREV NEXT
PS2
Vision Control Panel
To Power
Supplies
Touchscreen Display
8 • Touchscreen Controls
Touchscreen Controls
There are a number of control buttons provided on the Touchscreen that allow
you to navigate the on-screen menus, or select the video input signal.
The function of these control buttons depends on the Touchscreen that you are
using. Refer to the table for your device for information on the control buttons.
Table 1.1 V-100A Controls
Button Description
SYSTEM
POWER Navigate to the System Shutdown Menu on the switcher. Is lit
when the switcher is powered.
FRAME
FAIL Lights red when there is an error detected in the frame. Press
to navigate to the status menu on the switcher.
MENU Access the on-screen display menu.
- Navigate the on-screen display menu.
+ Navigate the on-screen display menu.
SELECT Manually select DVI-D or VGA input.
PANEL
FAIL Lights red when there is an error detected in the control panel.
Press to navigate to the status menu on the switcher.
DISPLAY Turns green when there is valid video input signal, and is unlit
when there is not a valid video input signal. Press to turn off the
button LEDs and Display.
Touchscreen Controls • 9
Table 1.2 V-100B Controls
Button Description
SYSTEM
POWER Navigate to the System Shutdown Menu on the switcher. Is lit
when the switcher is powered.
FRAME
FAIL Lights red when there is an error detected in the frame. Press
to navigate to the status menu on the switcher.
MENU Access the on-screen display menu.
LEFT Navigate the on-screen display menu.
UP Navigate the on-screen display menu.
DOWN Navigate the on-screen display menu.
RIGHT Navigate the on-screen display menu.
EXIT Auto adjust the display in VGA mode, or exit the on-screen
display menu.
PANEL
FAIL Lights red when there is an error detected in the control panel.
Press to navigate to the status menu on the switcher.
DISPLAY Turns green when there is valid video input signal, and flashes
green when there is not a valid video input signal, eventually
changing to yellow. Press to turn off the button LEDs and
Display.
10 • Touchscreen Controls
Notes
