Rohnson R-2148 User manual

INSTRUCTION MANUAL

Model No.: R-2148/R-2148B

Please read the manual carefully before

HOUSEHOLD AND INDOOR USE ONLY

IMPORTANT SAFEGUARDS

When using electric appliances, basic safety precautions should always be followed including the

following:

1. Read all instructions.

2. Do not touch hot surfaces. Use handle or knobs.

3. Close supervision is necessary when any appliance is used by or near children.

4. To protect against electric shock, do not immerse cord, plug, or any parts of the oven in water or other

liquids.

5. Do not let cord hang over edge of table or counter, or touch hot surfaces.

6. Do not operate appliance with damaged cord or plug or after the appliance malfunctions, or has been

damaged in any manner, return the appliance to the nearest Authorized Service Center for

examination, repair, or adjustment.

7. The use of accessory attachments not recommended by the appliance manufacturer may cause

hazard or injury.

8. Do not place on or near a hot gas or electric burner, or in a heated oven, or in a microwave oven.

9. When operating the oven, keep at least 12 cm of space on all sides of the oven to allow for adequate

air circulation.

10. Unplug from outlet when not in use, or before cleaning. Let it to cool down before putting on or taking

off parts, or before cleaning.

11. Do not cover any part of the oven with metal foil. This may cause overheating of the oven.

12. Extreme caution should be exercised when removing tray or disposing of hot grease or other hot

liquids.

13. Do not clean the oven with metal scouring pads. Metal chippings would touch electrical parts, and

endanger a risk of electric shock.

14. A fire may occur if the oven is covered by or placed near the flammable material, including curtains,

draperies, walls, and the like, when in operation. Do not store any item on the oven during operation.

15. Extreme caution should be exercised when using containers constructed if anything other than metal

or glass.

16. Do not place any of the following materials in the oven: cardboard, plastic, paper, or anything similar.

17. Do not store any materials, other than manufacturer’s recommended accessories, in this oven when

not in use.

18. To disconnect, turn any control to “off”, then remove plug from wall outlet. Always hold the plug, but

never pull the cord.

19. Always wear protective, insulated oven mitts when inserting or removing items from the hot oven.

20. This appliance has a tempered, safety glass door. The glass is stronger than ordinary glass and more

resistant to breakage. Avoid scratching door surface or nicking edges. If the door glass has a scratch

or nick, contact the nearestAuthorized Service Center for examination and repair.

21. Do not use outdoors.

22. Do not use appliance for other than intended use.

23. This appliance is for HOUSEHOLD USE ONLY.

24. The accessible surfaces are liable to get hot when the appliance is operating.

25. Glass Door cannot support goods in the fully open position.

26. The appliance is not intended to be controlled by an external timer or separate remote-control system.

27. If the surface of the hotplate is cracked, switch off the appliance to avoid the possibility of electric

shock. Return appliance the nearestAuthorized Service Center for repair.

28. Caution, hot surface! The temperature of accessible surface may be high when the appliance

is operation. Do not touch hot surfaces. Use handle or knobs.

29. This appliance is not intended for use by persons (including children) with reduced physical, sensory

or mental capabilities or lack of experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person responsible for their safety.

30. Children should be supervised to ensure that they do not play with the appliance.

31. For appliance with type Y attachment, if the supply cord is damaged, it must be replaced by the

manufacturer, its services agent or similarly qualified persons in order to avoid a hazard.

SAVE THESE INSTRUCTIONS

Before using your cooker for the first time, be sure to：

1. Read all instructions included in this manual.

2. Make sure oven is unplugged.

3. Remove all racks and pans. Wash the racks and pans in hot sudsy water or in dishwasher.

4. Thoroughly dry all accessories and re-assemble in oven. Plug oven into outlet and you are ready to

use your new cooker with Grill.

5. For the first time use, set the temperature knob to230 °C and set the function knob to the positi

on.Leave the oven operating for about 15 minutes with no food inside.

NOTE: The oven may smoke during cooking.This is normal for a new oven and will last no more

Than 10 to 15 minutes.

When begin to use:

1. Confirm the marked power consumption is in conformity with your household electric power.

2. Do not let cord hang over edge of table or counter to avoid that children may stumble over.

3. If the supply cord is damaged, the oven should not be used before it is repaired.

4. Oven should be sent to the manufacturer, authorized service agent or a similarly qualified person to

repair in order to avoid a hazard.

COMPONENTS:

Large Hotplate (Φ180mm): Use for cooking various casserole dishes and other desired use.

Small Hotplate (Φ145mm): Use for cooking various casserole dishes and other desired use.

Mini Hotplate (Φ90mm): Use for cooking coffee or milk.

Knob: Temperature Knob,Hotplate Function Knob

Wire Rack: For toasting, baking, and general cooking in casserole dishes and loading food tray.

Food Tray: For use in broiling and roasting various foods that contain water or will release water or oil

during cooking.

Door handle: Cool handle to avoid any scald.

Glass Door: Transparent tempered glass allows you to view the cooking process conveniently.

Food Tray Handle:Allows you to pick up Food Tray and Grill Rack to avoid any scald

CONTROL PANEL

TEMPERATURE SETTINGS

For small hot plate

For large hot plate

For oven

Temperature Knob: the temperature choice is

from 100 to 230℃. You could select desired

temperature according.

You can turn the temperature knobs clockwise to the desired

heat settings from 1 to MAX.

OVEN FUNCTION SETTING

You can turn the function knob to select the OFF, grill, lower

heating, convection or mini hotplate setting, .

Grill:

Only the top heating element will heat up.

Lower heating:

Only the bottom heating element will heat up.

Convectional:

The top and bottom heating elements will

heat up.

Mini Hotplate in function

NOTE: The oven and big and small hotplate can work at the same time.

OPERATION

Place the oven on a stable flat surface. Be sure that no other appliances are plugged

into the same circuit with the oven. Plug the oven into the mains socket. The oven

indicator light, hotplate indicator light will illuminate, when they are working.

OPERATION INSTRUCTION：

Using Your Oven:

1. Place the food on grill rack or Food tray and close the oven door.

a. Do not use any paper or plastic container.

b. Use Food tray for any food that is small in size or likely to drip while cooking.

c. Place the food evenly on the grill rack.

2. Insert the power plug into the socket.

3. When the cooking finished, please turn the function knob to “OFF” and use

accessory handle or oven mitts to remove hot food to avoid any scald.

4. Remove the power plug from the socket after cooking.

Oven cooking guide：

Grill

This setting is ideal for use when toasting bread and grilling chicken, sausage, pork chops and

bacon.

Lower heating

This setting can be used for most food cooked in the conventional function, but will take longer.

Convectional

This setting is ideal for use when cooking baked potatoes, roasting meat and vegetables, ready

meals, casseroles, stews, bread, cakes and desserts.

Using Your Hotplate

Hotplate could be used to cook various casserole dishes.

Cooking Utensils

1. Cooking gears that can be placed on top of the heater to heat food includes all utensils made of ferrite

element such as enamel, cast or stainless steel with a smooth base which diameter in 85--180mm,

have a flat bottom and are covered with lid.

2. Utensils that should not be used to heat food include that is made of aluminum or copper; and

containers with a base diameter no more than hotplate set value.

Operation Instructions

．Plug in the power socket

．Turn Function to (Large hotplate in function), (small hotplate in function) or (Large hotplate and

small hotplate in function), (mini hotplate in function).

CARE & CLEANING

ALWAYS UNPLUG OVEN AND ALLOW TO COOL BEFORE CLEANING

Your oven features a quick-clean coating. If desired, wipe walls with damp cloth. Do not use steel wool

scouring pads, abrasive cleaners or scrape walls with metal utensils as this may damage the quick-clean

interior. Wash all accessories in hot sudsy water or in a dishwasher. Wipe the door clean with a damp

cloth and wipe dry with a paper or cloth towel.

SPECIFICATION

Power Consumption: 220V-240V~ 50Hz

Note: The weight of the food which is put on the Food Tray/wire Rack can not be over 3.5kg. （just

for reference）（The food can not concentrate on one side of the Food Tray/Grill Rack, you would

better try you best to make the food put on the Food Tray/Wire Rack evenly）.

The maximum Output Power: 3100W

Big Hotplate(Φ180) Output: 1000W

Small Hotplate(Φ145) Output: 600W

Mini Hotplate(Φ90) Output: 450W

Oven Output: 1500W

Oven Capacity: 48Litres

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC

DIRECTIVE 2002/96/EC.

At the end of its working life, the product must not be disposed of as urban waste.

It must be taken to a special local authority differentiated waste collection centre or to a dealer providing this

service.

Disposing of a household appliance separately avoids possible negative consequences for the environment

and health, deriving form inappropriate disposal and enables the constituent materials to be recovered to obtain

significant savings in energy and resources. As a reminder of the need to dispose of household appliances

separately, the product is marked with a crossed-out wheeled dustbin.
