Robokits RKI-1547 User manual
http://www.robokits.co.in
http://www.robokitsworld.com Page 1
2.4Ghz RF Multi Channel Remote for 4 DC Motors [RKI-1547
2.4Ghz RF Multi Channel Remote
for 4 DC Motors [RKI-1547
Users Manual
Robokits India
http://www.robokits.co.in
info@robokits.co.in
http://www.robokits.co.in
http://www.robokitsworld.com Page 2
2.4Ghz RF Multi Channel Remote for 4 DC Motors [RKI-1547
Make your robot wireless with RF 2.4GHz coded Remote control. Ideal for making any DC
motor controlled robot. Just connect battery and motors to respective terminals to make your
robot wireless. It can control up to 1Amp of current on each channel.
It can Drive 2 robot driving motors (Connect two motors in parallel for 4 wheeled robot) in
skid steer control with analog speed control and 2 motors without speed control.
This Package Includes
• RF 2.4GHz Receiver and motor control Circuit
• RF 2.4GHz Play Station 2 remote Control with receiver
Features
• Control 2 DC motors with Skid Steer Control with 1Amp capacity each (See Remote
Functions below)
• Analog speed control for 2 DC driving DC motors
• Extra 2 DC Motor control without speed control
• Auto selects four different frequencies so that four remotes can operate simultaneously.
http://www.robokits.co.in
http://www.robokitsworld.com Page 3
2.4Ghz RF Multi Channel Remote for 4 DC Motors [RKI-1547
Functions on Remote Control
Action Effect
Press Forward
Both Motors Forward
Robot Moves Forward
Press Left
Right Motor Forward
Left Motor Reverse
Robot turns Left
Press Right
Right Motor Reverse
Left Motor Forward
Robot turns Right
Press Reverse
Both Motors Reverse
Robot Moves Backward
Left Joystick
Speed control MOde
Press A or X
Motor3 Forward or Backwa
rd
Press D or O
Motor4 Forward or Backward
http://www.robokits.co.in
http://www.robokitsworld.com Page 4
2.4Ghz RF Multi Channel Remote for 4 DC Motors [RKI-1547
Usage Steps
1. Connect 4X AAA cells to the transmitter and keep transmitter in power off state.
2. Make sure the control board and receiver (Black coloured small box) are properly
connected as per the photo.
3. Connect power supply to the control board with proper polarity. Check GND(-) and
VDD(+) terminals. (Do not connect the power supply in reverse or else the circuit will be
damaged.)
4. Check LED status on receiver. Power LED should be on and rx LED should start blinking.
5. Turn on power on the transmitter and check status on the receiver RX LED. Once the
transmitter and receivers are linked the RX LED will stop blinking and stay in ON state
continuously.
6. In any case the receiver is not connected retry using power switch on the transmitter.
Also the same procedure can be used to link delinked receiver and transmitter when the
receiver goes out of range.
7. If there are multiple transmitters and receivers on at the same time please make sure
you power them in correct sequence. Once a pair is linked it will work at the same
frequency and frequency will only change if there is only one delinked receiver which is
powered and on another frequency.
http://www.robokits.co.in
http://www.robokitsworld.com Page 5
2.4Ghz RF Multi Channel Remote for 4 DC Motors [RKI-1547
Service and Support
Service and support for this product are available from Robokits India. The Robokits Web site
(
http://www.robokits.co.in
) maintains current contact information for all Robokits products.
Limitations and Warrantees
The
2.4Ghz RF Multi Channel Remote for 4 DC Motors [RKI-1547
is intended for personal experimental
and amusement use and in no case should be used where the health or safety of persons may depend on its proper
operation. Robokits provides no warrantee of suitability or performance for any purpose for the product. se of the
product software and or hardware is with the understanding that any outcome whatsoever is at the users own risk.
Robokits sole guarantee is that the software and hardware perform in compliance with this document at the time it was
shipped to the best of our ability given reasonable care in manufacture and testing. All products are tested for their best
performance before shipping, and no warranty or guarantee is provided on any of them. Of course the support is available
on all of them for no cost.
Disclaimer
Copyright © Robokits India, 2011
Neither the whole nor any part of the information contained in, or the product described in this manual, may be adapted or
reproduced in any material or electronic form without the prior written consent of the copyright holder.
This product and its documentation are supplied on an as-is basis and no warranty as to their suitability for any particular
purpose is either made or implied.
This document provides preliminary information that may be subject to change without notice.
