Ricoh THETA X User manual
youtube.com/c/RICOHTHETA
facebook.com/ricoh.theta
@theta360official
*L8581971AR*
*L8581971A*
Kurzanleitung
Quick Start Guide
Guide de démarrage rapide
Receptor4.0_QSG_cover14.indd 1 2021/09/06 9:28:57
English 1
Deutsch 17
Français 33
日本語 49
Model: R04010
Receptor4.0_QSG_cover23.indd 2 2021/09/06 14:12:47
1
English
A New Way to Enjoy
Photography
Easy Operation Introduction
Video
You can watch a video of how to use this
product.
https://www.thetalab.ricoh/en/howto/tips/
thetax/
Product Website
You can see the latest product information and useful hints
and tips on using this product.
https://theta360.com/en/
Brand Website
You can see the tips on how to enjoy this product, various
events, and other information.
https://www.thetalab.ricoh/en/
User Guide
You can access the user guide for details on how to use
this product.
https://support.theta360.com/en/manual/
Support Information
You can see the support information and entire warranty
provisions.
https://support.theta360.com/en/
Receptor4.0_QSG.indb 1 2021/09/06 14:13:32
2
Names of Parts
1
2
8
9
0
3
4
5
6
3
a
b
7
Receptor4.0_QSG.indb 2 2021/09/06 14:13:32
3
1Speaker
2Battery/card cover
3Lens
4LCD panel
Displays the menu, shooting information, and captured
images. Touch operation is possible on this panel.
5Shutter button
Shoots a still image or video when pressed.
6Tripod mount hole
7Power lamp
Lights blue when the power is on.
8Power button
Turns the power on and off when pressed and held.
Turns the sleep mode on and off when pressed briefly.
9Mode button
Switches the shooting mode.
Runs and terminates the installed plug-ins when pressed
and held.
0USB terminal (USB Type-C)
Connects with other devices via the provided USB cable.
aMicrophone
bCamera status lamp
Lights when shooting can be performed.
Be careful when handling the lens section. Always store the camera in
the provided soft case when the camera is not used.
Receptor4.0_QSG.indb 3 2021/09/06 14:13:32
4
Before Use
1 Check that the power of the camera is off.
2 Slide the battery/card cover in the direction of
the arrow to open it.
3 Check that the orientation of the battery is cor‑
rect, and insert it all the way while pushing the
latch sideways.
To remove the battery, slide the latch.
4 Check that the orientation of the memory card is
correct, and insert it.
Use a commercially available microSDXC card (64 GB
or higher, UHS-I).
Receptor4.0_QSG.indb 4 2021/09/06 14:13:32
5
5 Close the battery/card cover.
6 Connect the camera to a computer with the pro‑
vided USB cable to charge the battery.
The battery level can be checked on the LCD panel.
The power lamp lights green during charging, and the
lamp turns off when charging is complete.
Update the camera firmware to the latest version before using the cam-
era. For details on the operation, refer to the user guide.
https://support.theta360.com/en/manual/
Receptor4.0_QSG.indb 5 2021/09/06 14:13:32
6
Basic Operation
Turning the Camera On
Press and hold the power button for approx. 1 second. The
power lamp starts to flash.
In the sleep mode, briefly press the power button to recover
from the sleep mode.
Touch on the LCD panel for subsequent operations.
Making Initial Settings
When the camera is started for the first time, set the lan-
guage, position information, and date and time according to
the on-screen instructions.
Then the LCD panel shows how to operate on the shoot-
ing, setting, and playback screens and how to connect the
camera to a smartphone.
If [Auto] is set in the date and time setting, the date and
time of the camera is synchronized with those of the smart-
phone when the camera is connected to the basic app for
smartphone.
When the initial settings are complete, the shooting screen
appears.
Receptor4.0_QSG.indb 6 2021/09/06 14:13:32
7
Switching the Screen
Swipe from the edge of the LCD panel while the shooting
screen is displayed to switch the screen.
2 4
1
3
1Swiping down: Camera setting screen
2Swiping right: Playback screen
3Swiping up: Shooting parameter setting screen
Swiping up again: Shooting setting screen
4Swiping left: Plug-in selection screen
Swipe the bar at the edge of each screen toward the center to return to
the shooting screen. The panel display returns to the shooting screen
also when the shutter button is pressed.
Receptor4.0_QSG.indb 7 2021/09/06 14:13:32
8
Shooting Screen
8
1
2
3
7
6
5
4
90
1Wireless LAN communication status
2Bluetooth®
3Position information
4Remote control
5Plug-in
6Memory card
7Battery level
8Self-timer
9Shooting mode
0Exposure program
For 8, 9, and 0, you can make settings by tapping them.
