Riccar RC-705D User manual

VACUUM CLEANER

RC-7O5D

READ AND KEEP THIS

•Thank you for purchasing this vacuum cleaner.

•For proper operation, please read this manual before using.

OWNER'S

MANUAL

DESCRIPTION AND USING

DUST METER

How to check the DU T METER!

Operate the cleaner with MAX power keep the wide suction brush apart from the

floor.

• If the red indicator of the DU T METER appears,

– Empty the dust bag.

– In case the hose is blocked with a large object, remove it.

• When cleaning with the crevice tool or the dusting brush, the red indicator may

appear. In this case, continue cleaning.

CORD REVIND B

POWER CONTROL

MAX

HIGH

MID

MIN

STOP

HOSE HANDLE

POWER CONTROL

BUTTON

HOSE ADAPTER

• When separating the hose from the body, pull

the hose adapter while pressing the button.

PIPE HOLDER HOSE

REVIND BUTTON POWER CORD

• Connect to the same voltage as

shown on the rating label.

• To plug or unplug, grasp the plug

body. Do not hold or pull by the

cord.

GROOVE

KEEPING

• Insert the pipe holder into the

groove.

BEND

•DUSTING BRUSH •CREVICE TOOL

LOGEMENT D'USTENSILES

HANDLE

DUST

COVER

BLOWER CLEANING

REAR SIDE

OF THE CLEANER

HOLE

GRILLE HOSE

ADAPTER

• Open the grille.

• eparate the hose adapter from the front side of the cleaner, then insert it into the hole and

rotate it clockwise. (As inserting the hose adapter into the hole, the blower cleaning is started.)

• In order to get strong blowing, attach the crevice tool to hose handle.

• When separating the hose adapter from the hole, rotate it counterclockwise and pull it out.

• No danger in touching the pins under blower cleaning.

• When the dust bag is getting full with dust, the blowing is getting is getting weak.

In this case, operate with the dust cover open.

HOOK FILTER

DUST COVER

DUST BAG HOLDER

GUIDE

BOTTOM HOOK BOARD

• Open the dust cover and push the dust bag holder in

the direction of the arrow mark, and then take out the

dust bag.

• When inserting the dust bag, place the board of the

dust bag between the two guides and insert the lower

part of it into the bottom hooks and fix the upper part of

it with the dust bag holder.

• The dust cover can not be closed completely when the

dust bag is set wrong.

• Open the grille

• Take the filter and replace it.

EMPTYING THE DUST BAG REPLACING THE FILTER

Please check each item below if you have trouble with your cleaner.

Before checking, ensure that the cleaner is unplugged from the power supply.

BEFORE ASKING FOR SERVICE

PROBLEM

• uction power is weak. • Dust bag

• Hose

• If it is full with dust, empty it.

• If clogged or blocked,

remove the object.

• The cleaner does not work. • Is the hose adapter inserted

into the suction opening of

the cleaner completely?

• When the dust bag is full or

blocked or any of the

accessories are blocked, the

over-heating protection for

the motor is activated.

• Insert it completly.

• witch off and unplug the

cleaner and check the dust

bag and accessories and

remove any blockages.

The cleaner can be switched

on again after about 20

minutes.

• Power cord does not

rewind.

• Power cord won't pull out of

the cleaner.

• Power cord

• Pull the power cord out a

little and press the cord

rewind button.

• Do not pull it by force Rewind

it a little by pressing the cord

rewind button and pull it out.

CHECK POINT MEASURE

This vacuum cleaner should only be used for normal dry houshold dust and dirt.

The manufacturer cannot be held responsible for any damage caused by use or operation of the

cleaner contrary to these instructions.

If the cleaner is wrongly operated for a purpose other than that for which it is intended, no liability

can be accepted for any possible damage.

PRECAUTIONS FOR SAFE USE

RED MARK

• Do not vacuum areas which contain

moisture or water and inflammable matter,

needles, pins, razor blades, matches,

cigarette-ends, etc., since they may damage

the cleaner or dust bag.

• When rewinding the power cord, hold the

plug body before pressing the cord rewind

button to prevent whipping.

• Do not pull the power cord out beyond the

red mark.

• Make sure a dust bag and a motor

protection fillter are always inserted.

• Do not operate the cleaner if ;

– the Power cord is damaged.

– the hose shows visible signs of damage.

It must be replaced by the manufacturer or

its service agent or a similarly qualified

person in order to avoid a hazzard.

SPECIFICATIONS

Model RC-705D

Rating 120V/60Hz

Input Watt Max 1300 W

MAX. Air Watt 370 W

Weight (Body) 6.1 kg

Dimension (Body) 432 x 251 x 284 mm

Cord Length 5 m
