RFID 8075E User manual

Product Manual

Model 8075E PROFINET Series Interface

for LF 125 kHz and 148 kHz Smart Antennas

This document is made available to product owners and users for integration purposes. Proprietary and confidential

information is contained herein, therefore this document is protected by all applicable international intellectual property

laws. The information contained in this document is constantly subject to revision (see Rev. number at top of each page).

Revision 2/2021

14190 E. Jewell Avenue, Suite 4, Aurora CO 80012 - TEL: 303-366-1234 –Proudly Made in the USA

www.rfidinc.com

Model 8075E Operations Manual v7.21

Table of Contents

How to Contact Us .................................................................................................................................... 3

Part Numbers............................................................................................................................................. 3

Hardware Description.............................................................................................................................. 4

Specifications........................................................................................................................................... 4

Drawing.................................................................................................................................................... 5

Pigtail Wire Specifications ...................................................................................................................... 6

Power Requirements................................................................................................................................ 6

Cabling the Reader –Power .................................................................................................................... 6

Wiring Color Codes................................................................................................................................. 6

M12 Pinouts............................................................................................................................................. 6

CAN Smart Antenna Readers and LF Passive RFID Tags ....................................................................... 7

Integer Data.............................................................................................................................................. 7

SW1 & SW2 Dipswitches......................................................................................................................... 7

RW/RO (read write or read only) ............................................................................................................ 8

Summary Default Settings....................................................................................................................... 8

Serial Port Settings................................................................................................................................... 9

Serial Port Commands to the Interface.................................................................................................... 10

Serial Port Commands to the Smart Antenna RFID Readers.................................................................. 12

Configuring PROFINET - LED Status Lights ........................................................................................ 13

Setting up PRFINET Interface ................................................................................................................ 14

Issuing Commands via PROFINET ........................................................................................................ 15

“I/O Command Bits 1 Byte”.................................................................................................................... 15

Example Module setups Integer Mode Smart Antenna Readers ........................................................... 17

Example Module setups ASCII Mode Smart Antenna Readers.............................................................. 21

Example Module setups Integer Mode Serial Smart Antenna Reader.................................................... 29

Example Module setups ASCII Mode Serial Readers ............................................................................ 33

Smart Antenna Reader Addressing ......................................................................................................... 41

Warranty.................................................................................................................................................. 42

Revision 2/2021

14190 E. Jewell Avenue, Suite 4, Aurora CO 80012 - TEL: 303-366-1234 –Proudly Made in the USA

www.rfidinc.com

Model 8075E Operations Manual v7.21

How to Contact Us

Customer Service: [email protected] or [email protected]

303-366-1234 x101

Tech Support: 303-910-5447 cell 9am to 6pm PST

[email protected]

Sales: 719-330-2349 cell 7am to 5pm CST

[email protected]

Not Happy? Contact our President:303-378-9500 cell or [email protected]

Part Numbers

Model

Number

Part Number

Description

8075E-

04SA08

801-8075-

04SA08

Model 8075E-04SA08 PROFINET Interface, CAN Smart Antennas, M12

connector, 24vdc, 8 characters

8075E-

14SA08

801-8075-

14SA08

Model 8075E-14SA08 PROFINET Interface, CAN Smart Antennas, pigtail

wiring, 24vdc, 8 characters

8075E-

24SA08

801-8075-

24SA08

Model 8075E-24SA08 PROFINET Interface, CAN Smart Antennas, dual

pigtail wiring, 24vdc, 8 characters

8075E-

04SA16

801-8075-

04SA16

Model 8075E-04SA16 PROFINET Interface, CAN Smart Antennas, M12

connector, 24vdc, 16 characters

8075E-

14SA16

801-8075-

14SA16

Model 8075E-14SA16 PROFINET Interface, CAN Smart Antennas, pigtail

wiring, 24vdc, 16 characters

8075E-

24SA16

801-8075-

24SA16

Model 8075E-24SA16 PROFINET Interface, CAN Smart Antennas, dual

pigtail wiring, 24vdc, 16 characters

Revision 2/2021

14190 E. Jewell Avenue, Suite 4, Aurora CO 80012 - TEL: 303-366-1234 –Proudly Made in the USA

www.rfidinc.com

Model 8075E Operations Manual v7.21

Hardware Description

This Interface is the master in managing a network of up to 32 networkable CAN based RFID Readers

termed Smart Antennas (or as an PROFINET bridge from our series of serial Reader Models 4000E,

5000E, and 7000E), and ultimately presents RFID Tag data from the networked Smart Antennas in

PROFINET format. Any sections of this manual pertaining to settings or functions with serial RFID

Readers have the word serial highlighted in yellow to alert users of the CAN based Smart Antennas those

sections can be skipped or ignored. Dual pigtail wiring would be used if the Interface is to be located in

the center of the trunk network line of Smart Antenna RFID Readers thus providing a connection in either

direction or an M12 T-Connector can be used to split the single on board M12 connector into two

directions.

Specifications

Physical:

Dimensions (w/o

connectors):

4.8" square x 2.175"

122mm square x 55mm

Weight (w/o cable):

11 oz.

312 grams

Connector Options:

CAN Port(s): M12 or

pigtails

Power: M12, Quick Connect

power jack or pigtails

RS232 Port: 9pin D-sub or

pigtails

PROFINET: RJ45

Electrical:

Input:

+9VDC –+28VDC

Draw:

125mA min –200mA max

150mA typical

Materials:

Housing, Base:

Polycarbonate, opaque

NEMA 4X

Lid:

Polycarbonate, clear

LED:

On = power

Blink = read achieved

Environment:

Storage

Temperature:

-40°F to 185°F

-40°C to +85°C

Operating

Temperature:

-40°F to +131°F

-40°C to +55°C

Certs:

IP-50

RoHS & CE & REACH

Revision 2/2021

14190 E. Jewell Avenue, Suite 4, Aurora CO 80012 - TEL: 303-366-1234 –Proudly Made in the USA

www.rfidinc.com

Model 8075E Operations Manual v7.21

Drawing PROFINET Interface w/M12 Connectors Drawing Shown

Revision 2/2021

14190 E. Jewell Avenue, Suite 4, Aurora CO 80012 - TEL: 303-366-1234 –Proudly Made in the USA

www.rfidinc.com

Model 8075E Operations Manual v7.21

Pigtail Wire Specifications

Shielded (22 AWG for cable length up to 25’ and 16 AWG for communication lengths beyond 25’)

insulated, stranded wire is recommended. All wires should be stripped approximately 3/8 inches and

tinned.

Power Requirements

The Interface can be powered from regulated, linear, or switching power sources having the

characteristics defined in the Specifications section of this document (9 to 28 volts). The Interface

should be operated from a grounded supply that has the same ground reference as the host computer or

logic device.

Cabling the Reader –Power

The Interface is delivered with two power connection options, an M12 connection or connection to bare

pigtail wiring.

Wiring Color Codes

CAN WIRE COLOR

SIGNAL NAME

RED

+9 to +28VDC Input Unfused

BLACK

DC Ground (-)

WHITE

CAN-HI

BLUE

CAN-LO

BARE/DRAIN

EARTH GROUND, DRAIN, SHIELD

RS232 WIRE COLOR

SIGNAL NAME

BLACK

RED

WHITE

Ground

M12 Pinouts

Revision 2/2021

14190 E. Jewell Avenue, Suite 4, Aurora CO 80012 - TEL: 303-366-1234 –Proudly Made in the USA

www.rfidinc.com

Model 8075E Operations Manual v7.21

CAN Smart Antenna Readers and LF Passive RFID Tags

Smart Antenna RFID Readers are addressable and simply provide a means of emitting the RF signal to

energize a Tag, receive data back from a Tag and pass Tag data back to the Interface. Smart Antennas

can also program RFID Tags. RFID Tags store 8 or 16 ASCII characters (limited to capital letters,

numbers and some symbols). Smart Antenna Readers operate at +9VDC to +28VDC consuming 160mA

max.

Integer Data

Although the Smart Antenna RFID Readers and Tags use 8 or 16 character formats, the Model 8075E

Interface can convert DINT data from the PROFINET scanner to 8/16 character numerical strings and

convert the string from the Tag into a DINT before sending to the PROFINET bus.

SW1 & SW2 Dipswitches

The SW1 switch block is inactive. SW2 is located at right center shown below used to configure ASCII

or Integer data, serial type, and serial baud rate.

Revision 2/2021

14190 E. Jewell Avenue, Suite 4, Aurora CO 80012 - TEL: 303-366-1234 –Proudly Made in the USA

www.rfidinc.com

Model 8075E Operations Manual v7.21

RW/RO (read write or read only)

All Smart Antenna Readers are RW. When the Interface is configured for RO however, you are simply

removing Tag data from the scanner output. Use the SW2 dipswitch settings of the first 4 rows below

for networkable CAN Smart Antenna Readers and the second 4 rows for serial Readers like the Models

4000E, 5000E, 7000E:

Summary Default Settings

RS232 - Full Duplex, 9600, 8, N, 1, Single Read Mode

PROFINET –CAN RW Integer, Dynamic IP Address, Single Tag Report Read Mode

*Defaults are noted with an asterisk in tables below*

Switch 1 (LSB)

Switch 2

Switch 3

Smart Antenna Data Type

OFF

CAN ASCII RW

OFF

CAN INTEGER RW*

OFF

CAN ASCII RO

CAN INTEGER RO

OFF

SERIAL ASCII RW

OFF

SERIAL INTEGER RW

OFF

SERIAL ASCII RO

OFF

SERIAL INTEGER RO

Table 1 - SW2 CAN Smart Antenna Interface Modes

The PROFINET Interface can only use even values. The extra byte of data must be ignored

Type

CMD

ADD

DATA

Total

Actual

CAN ASCII RW

CAN INTEGER RW*

CAN ASCII RO

CAN INTEGER RO

Table 2 - CAN Smart Antenna PROFINET data sizes

Revision 2/2021

14190 E. Jewell Avenue, Suite 4, Aurora CO 80012 - TEL: 303-366-1234 –Proudly Made in the USA

www.rfidinc.com

Model 8075E Operations Manual v7.21

Serial Port Settings

Switch 4

Switch 5

Switch 6

Serial Baud Rate

OFF

1200

OFF

2400

OFF

4800

OFF

9600*

OFF

19200

OFF

38400

OFF

Do not use

Table 3 - SW2 & Baud Rate Selection

*9600, 8, 1, N

RS232 full duplex, RS422 full duplex (5 wire), RS422 half-duplex (3 wire)

Switch 7

Switch 8

Serial hardware type

OFF

RS232 full duplex*

OFF

RS422 half-duplex

OFF

RS422 full duplex

Table 4 - SW2 Serial Port Hardware Select

The PROFINET Interface can only use even values. The extra byte of data must be ignored.

TYPE

CMD

DATA

Total

Actual

SERIAL ASCII RW

SERIAL INTEGER RW

SERIAL ASCII RO

SERIAL INTEGER RW

Table 5 –Serial Port PROFINET Data Sizes

Start & End Characters for Serial to PROFINET Bridge Mode

This section pertains only to use of the Interface when linked with serial Readers, NOT the networkable

CAN Smart Antenna Readers. The serial port software frames Tag data from the Smart Antenna RFID

Readers based on its End and Start character settings. Start may be set to zero in which case any character

is accepted as a start character. End must be set to a value other than zero to delimit incoming tag data.

The default settings are:

Start = 0x00

End = 0x0D (Carriage return)

Revision 2/2021

14190 E. Jewell Avenue, Suite 4, Aurora CO 80012 - TEL: 303-366-1234 –Proudly Made in the USA

www.rfidinc.com

Model 8075E Operations Manual v7.21

Serial Port Commands to the Interface

The characters of open square bracket and closed square bracket are used to frame an incoming command

message. When the serial port software receives the open square bracket [ character it expects the rest of

the message to be a command and the last character to be a closed square bracket ].

[1CXX]

Format: 1 = Start and End Char setting, C = Start or End character, XX = hex value

Valid values: C = ‘S’ or ‘E’, XX = a hex value. Values outside of ASCII letters and numbers are

recommended

Response: OK

Example 1: [1S0A] sets the start character as a Line Feed

Example 2: [1E0D] sets the end character as a Carriage Return

Example 3: [1S00] sets the start character to none

[2NNOO] –Change Reader Address

Format: 2 = Set Reader CAN address, NN = New CAN address, OO = Current (old) CAN address

Valid Addresses: 01 to 32

Response: OK, FAILED1, or FAILED2

Example: [23001] change Reader from address #01 to address #30

Example response 1: OK = #01 existed on the CAN bus and has been reset to #30

Example response 2: FAILED1 = #01 does not exist on the bus

Example response 3: FAILED2 = #30 is already in use

[3]

Format: 3 = Scan for present Readers

Response: RDR1, RDR2, RDRn…

Example: [3] Request a scan of present Readers

Example response 01 07 19 31

[4=IP address]

There are options for either a static IP address or a dynamic IP address. Interfaces are shipped with

dynamic IP address as the default. The following command is for a static IP address:

Format: 4=NNN.NNN.NNN.NNN

Response: OK

Example: [4=10.0.1.42] Set new IP address

To return to a dynamic IP address, issue the command [4=0.0.0.0]

[5=Mask]

Format: 5=NNN.NNN.NNN.NNN

Table of contents

Other RFID Antenna manuals

RFID

RFID 4000 Series User manual

Popular Antenna manuals by other brands

Alfa Network

Alfa Network APA-L01 Specifications

Naval

Naval PR-422CA Operation manual

Feig Electronic

Feig Electronic ID ISC.ANTH200/200 Series manual

TERK Technologies

TERK Technologies TV44 owner's manual

Directive Systems & Engineering

Directive Systems & Engineering DSE2324LYRMK quick start guide

HP J8999A instructions

MobilSat

MobilSat MSP-S Mounting instructions

Steren

Steren ANT-UHF 13 instruction manual

Novatel

Novatel 600-G User information

Radio Shack

Radio Shack Amplified VHF/UHF/FM Indoor Antenna owner's manual

TRENDnet

TRENDnet TEW-AO12O Specifications

Radio Shack

Radio Shack 15-1837 owner's manual

CommScope

CommScope CMAX-OMFX-43M-I53 Installation instruction

Ramsey Electronics

Ramsey Electronics DAP25 Kit assembly and instruction manual

COBHAM

COBHAM SAILOR 800 VSAT Replacement procedure

Trango Systems

Trango Systems AD900-9 Specification sheet

Steren

Steren ANT-100 user manual

Proxim

Proxim 5054-PA-23 quick start guide
