RESU RESU10H User manual
The information included in this manual is accurate at the time of publication.
However, this manual is subject to change without prior notice. In addition, the
concepts and installation instructions.
Please note the image shown is for illustration purposes only.
May.2017
......................................................................................
3
Contents
1 Safety 5
1.1 Symbols....................................................................................................................5
1.2 Safety instructions ................................................................................................. 6
1.2.1 General safety precautions........................................................................6
1.2.2 Battery handling guide..............................................................................6
1.2.3 Response to emergency situations ...........................................................8
1.3 Warning label
Qualied personnel
.........................................................................................................9
1.4
.............................................................................................
10
2 Product Introduction 11
2.1 Technical data....................................................................................................... 11
2.1.1 Dimensions and weight........................................................................... 11
2.1.2 Performance............................................................................................... 12
2.2 Feature ................................................................................................................... 13
2.3 Packaging specication 13
3 Installation 14
3.1 Mechanical requirements ................................................................................... 14
3.1.1 Unboxing the package.............................................................................. 15
3.1.2 Items in the package................................................................................. 16
3.1.3 Installation locations ................................................................................ 16
3.1.4 Clearance.................................................................................................... 17
3.1.5 Tools & safety gears required ................................................................. 17
3.1.6 Mounting bracket...................................................................................... 19
3.1.7 Appearance and dimension.................................................................... 20
3.1.8 System clearance....................................................................................... 20
3.1.9 Installing the battery pack....................................................................... 21
3.2 Cable connection..................................................................................................24
3.2.1 Auxiliary power switch and spring terminal blocks .......................... 26
4
4 Commissioning 27
4.1 LED indicators ..................................................................................................... 27
4.2 Powering up the battery pack ............................................................................ 28
4.3
Shutting o the
battery pack ............................................................................ 28
6 Uninstallation & Return 32
6.1 Return/replacement instructions ........................................................................... 32
5 Troubleshooting 29
5.1 Troubleshooting ................................................................................................... 29
6.1.1 Uninstallation from the wall .................................................................... 32
6.1.2 Contact information ..................................................................................34
5.1.1 Post-Installation Check List ....................................................................30
5.1.2 Troubleshooting Guideline ....................................................................30
Contents
5
1 Safety
1.1 Symbols
Caution, risk of electric shock
Install the product out of reach of children.
Read the instruction manual before starting installation and
operation.
Heavy weight may cause serious injury to the back.
Do not dispose of the product with household wastes.
Recyclable
Disconnect the equipment before carrying out maintenance or repair.
Observe precautions for handling electrostatic discharge sensitive
devices.
Avoid installing the battery pack where ammable materials are stored. Do not
install in places where explosive gas or chemicals are present.
Over-voltages or wrong wiring can damage the battery pack and cause deagration,
which can be extremely dangerous.
6
1.2 Safety instructions
For safety reasons, installers are responsible for familiarizing themselves with the
contents of this document and all warnings before performing installation.
1.2.1 General safety precautions
All types of breakdown of the product may lead to a leakage of electrolyte or
ammable gas.
During installation of the battery, the utility grid, solar input must be disconnected
from the Battery Pack wiring. Wiring must be carried out by a qualied personnel.
Battery Pack is not user serviceable. High voltage is present in the device.
The electronics inside the Battery Pack are vulnerable to electrostatic discharge.
Be sure to be grounded before handling the battery pack.
Read the label with Warning Symbols and Precautions, which is visibly under to the
Battery Cover (see Section 1.3)
1.2.2 Battery handling guide
• Do not expose battery to open ame.
• Do not place the product nearby highly ammable materials. It may lead to re
or explosion in case of accident.
• Do not expose or place near water sources like downspouts or sprinklers.
• Store at cool and dry place. (Do not store in greenhouses and storage areas for hay,
straw, cha, animal feed, fertilizers, vegetables or fruit products.)
• Store the product on a at surface.
A ventilated area is strongly recommended for handling the product.•
Do not store this product in a place exposed to direct sunlight.•
Store the product out of reach of children and animals.•
Store the product where it should be minimal dust and dirt in the area.•
Safety
7
•
• Do not touch if liquid is spilled on the product. There is a risk of electric shock.
Handle the battery wearing the insulated gloves.
• Do not step on the product or the product package. The product may be damaged.
• Only use the product with a LGC-authorized inverter. For a list of compatible
inverters, go to :
http://www.lgesspartner.com
• Do not connect any AC conductors or Photo-voltaic conductors directly to the
battery pack and should be only connected to the Inverter.
• Notify your LG Chem regional contact if the product cannot be installed within
5 months after the manufacturing date. The product may require recharge.
• Do not place any foreign objects on the top of the Battery Pack and on the cooling
fin.
• Do not connect the power cables at terminal block opposite direction.
• Do not charge or discharge damaged battery.
• If the battery pack is installed in the garage then ensure the product is above the
height of the vehicle bumper and/or door.
•
well as outdoors. However, if installed outdoors, do not allow the battery pack to
be exposed to direct sunlight and water source as it may cause :
-Power limitation phenomena in the battery
(with a resulting decreased energy production by the system)
-Premature wear of the electrical/electromechanical components and
mechanical components.
-Reduction in performance, service life and possible damage of the battery
Safety
• Do not disconnect, disassemble or repair by unqualified personnel.
Services must be made by qualified personnel only.
The RESU battery pack has been cerified IP55 and can be installed indoors as
Do not damage the unit in such ways as dropping, deforming, impacting, cutting
or penetrating with a sharp object. It may cause a leakage of electrolyte or fire.
• Do not put the battery pack upside down on the ground.
8
1.2.3 Response to emergency situations
• If a user happens to be exposed to internal materials of the battery cell due to
damage on the outer casing, the following actions are recommended.
Inhalation : Leave the contaminated area immediately and seek medical attention.
Eye contact : Rinse eyes with running water for 15 minutes and seek medical
attention.
Contact with skin : Wash the contacted area with soap thoroughly and seek
medical attention.
Ingestion: Induce vomiting and seek medical attention.
Safety
Eective ways to deal with accidents
On land : Place damaged battery into a segregated place and call local fire
department or service engineer.
In water : Stay out of the water and don’t touch anything if any part of the
battery, inverter, or wiring is submerged.
Do not use submerged battery again and contact the service engineer.
•
Fire ghting instructions•
Fire extinguishing media•
WARNING
There may be a possible explosion when batteries are heated above 150℃.
When the battery pack is burning, it leaks poisonous gases. Do not approach.
The RESU10H battery pack comprises multiple batteries that are designed to prevent
hazards resulting from failures. However, LG Chem cannot guarantee their absolute
safety.
If a fire breaks out in the place where the battery pack is installed, perform the
following countermeasures:
Respirator is not required during normal operations.
Use FM-200 or CO2 extinguisher for battery fire.
Use an ABC fire extinguisher, if the fire is not from battery and not spread to it yet.
1. If fire occurs when charging batteries, if it is safe to do so, disconnect the
battery pack circuit breaker to shut off the power to charge.
2. If the battery pack is not on fire yet, extinguish the fire before the battery pack
catches fire.
3. If the battery pack is on fire, do not try to extinguish but evacuate people
immediately.
9
Safety
1.3 Warning label
Warning labels and other relevant labels are
attached to the inside of the battery pack.
1
2
3
1. Warning label
2. Product label 3. Traceability label
10
Safety
1.4 Qualied personnel
This guide and the tasks and procedures described herein are intended for use
by skilled workers only. A skilled worker is dened as a trained and qualied
electrician or installer who has all of the following skills and experience:
• Knowledge of the functional principles and operation of on-grid and o-grid
(backup) systems.
• Knowledge of the dangers and risks associated with installing and using electrical
devices and acceptable mitigation methods.
• Knowledge of the installation of electrical devices
• Knowledge of and adherence to this guide and all safety precautions and best
practices.
