Renesas R0E5562GAPFK10 User manual

User's Manual

R20UT2114EJ0100 Rev.1.00 Page 1 of 8

Sep 05, 2012

R0E5562GAPFK10

Debugging MCU Board for 64-pin 0.5mm-pitch LQFP

of the RX62T and RX62G Groups

1. Overview

The debugging MCU board R0E5562GAPFK10 (hereafter referred to as “this product”) is for MCUs of the RX62T and

RX62G groups in the PLQP0064KB-A package.

With the E20 emulator, the emulator occupies some user port pins for controlling the emulator and output of trace

information. These user port pins must be connected with a 38-pin connector installed on the user system.

With this product, however, all user port pins are available for the user system. In addition, you do not need to install a

38-pin connector on the user system.

Figure 1 shows the configuration of a system that includes this product and an E20.

Be sure to read section 7, Notes on Usage, before using this product.

Figure 1 System Configuration

2. Components of this Product

Table 1 lists the components of this product. Check that you have all of the components when you unpack the box.

Table 1 Components of this Product

Component Quantity Remarks

Debugging MCU board

(R0E5562GAPFK10) 1 For the dimensions of the board, refer to section 6,

Dimensions of this product.

YQPACK064SD

(from Tokyo Eletech Corporation) 1 Connector to be placed between this product and the

NQPACK.

NQPACK064SD-ND

(from Tokyo Eletech Corporation) 1 IC socket for mounting on the user system

YQ-GUIDE-S1

(from Tokyo Eletech Corporation) 4 Screws for fastening the YQPACK to the NQPACK.

Cautions in handling 1 Cautions when handling the products of Tokyo Eletech

Corporation

User’s Manual (English and Japanese) 1 for each This manual (English)

Note: NQPACK, YQPACK, YQSOCKET, YQ-GUIDE, HQPACK, TQPACK, TQSOCKET, CSSOCKET,

CSPLUG/W, and LSPACK are trademarks of Tokyo Eletech Corporation.

R20UT2114EJ0100

Rev.1.00

Sep 05, 2012

R0E5562GAPFK10 User's Manual

R20UT2114EJ0100 Rev.1.00 Page 2 of 8

Sep 05, 2012

Important

Caution to Be Taken for Disposal:

Penalties may be applicable for incorrect disposal of this waste, in accordance with your national

legislation.

European Union regulatory notices:

The WEEE (Waste Electrical and Electronic Equipment) regulations put responsibilities on producers for

the collection and recycling or disposal of electrical and electronic waste. Return of WEEE under these

regulations is applicable in the European Union only. This equipment (including all accessories) is not

intended for household use. After use the equipment cannot be disposed of as household waste, and the

WEEE must be treated, recycled and disposed of in an environmentally sound manner. Renesas

Electronics Europe GmbH can take back end of life equipment, register for this service at

“http://www.renesas.eu/weee”.

Caution to Handling this product:

•Take full care not to touch any parts or cause short circuits on this product.

•Protect this product from excessive physical shock.

•Do not alter this product. If any alteration is attempted, this product will no longer be

supported.

•The MCU installed on this product is only for use in debugging. Do not remove the MCU from

the board to use it for other purposes.

For purchasing the NQPACK064SD-ND, YQPACK064SD and HQPACK064SD, contact the

following:

Tokyo Eletech Corporation http://www.tetc.co.jp/e_index.

Caution to Notes on Turning the Power On:

•Do not apply a power voltage that is beyond the range guaranteed for the MCU.

•Only supply power to this product and connected parts after having connecting all cables.

Cautions for Use Temperature:

This product is to be used in an environment with a maximum ambient temperature of 35°C.

Care should be taken that this temperature is not exceeded.

European Union regulatory notices

This product complies with the following EU Directives.

Environmental Compliance and Certifications:

•Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive

2002/95/EC

•Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

CAUTION

R0E5562GAPFK10 User's Manual

R20UT2114EJ0100 Rev.1.00 Page 3 of 8

Sep 05, 2012

3. Specifications

Table 2 shows the functional specifications of this product.

Table 2 Specifications of this product

Item Specification

MCU for use •RX62T and RX62G groups MCUs in PLQP0064KB-A packages

The MCU type name

installed on this product

•R5F562GABDFH (exclusive for debugging)

(ROM: 256 Kbytes, RAM: 16 Kbytes, Data flash: 32 Kbytes )

Power supply •Power(VCC) at 2.7*1 to 3.6 V, or 4.0 to 5.5 V is supplied from the user system.

•Power(AVCC0 = AVCC) at 3.0 to 3.6 V, or 4.0 to 5.5 V is supplied from the user

system.

•The state of power supply can be monitored through the test pins (TP1 for VCC

and TP2 for GND).

•The state of analog power supply can be monitored through the test pins (TP3 for

AVCC0, TP4 for VREFH0, TP5 for AVCC, and TP6 for VREF).

System clock (EXTAL) •This clock signal at 8 to 12.5 MHz is supplied from the user system.

Notes*:1. Please use it by voltage (VCC > VPOR) that doesn't enter the state of power on reset.

4. Reset Circuit

Figure 2 shows the reset circuit, with the level on the RES# pin pulled up by a 510-kresistor.

38-pin connector (CN1)

Pin 9

(RES#)*1

MCU（IC1）

RES#

YQSOCEKT064SDF (CN2)

Pin 6

(RES#)*2

R14 0 Ω

UVCC

R17

510 kΩ

Notes* : 1. Indicated pin numbers are for pins of the 38-pin connector (CN1).

2. Indicated pin numbers are for pins of the YQSOCKET064SDF (CN2).

Figure 2 Reset Circuit

R0E5562GAPFK10 User's Manual

R20UT2114EJ0100 Rev.1.00 Page 4 of 8

Sep 05, 2012

5. Connection

To connect this product and user system, follow the

procedure below.

This Product(R0E5562GAPFK10) can be used for

debugging and on-board evaluation in common by

mounting the NQPACK064SD-ND on the user system.

(1) For debugging

1. Mount the NQPACK064SD-ND on the user system.

Be sure to check that the location of pin 1 is correct.

2. Install the YQPACK064SD after checking for a match

with the position of pin 1 for the NQPACK064SD-ND.

Then use the YQ-GUIDE-S1 to affix the

YQPACK064SD to the NQPACK064SD-ND.

Do NOT use the screws included with the

YQPACK064SD for fixing the YQPACK064SD.

Do NOT use the screwdriver included with the

NQPACK064SD-ND for fixing the

YQ-GUIDE-S1. That is used only for the

HQPACK064SD. Note that you need to provide

your own screwdriver.

3. Connect this product after checking for a match with the

position of pin 1 for the YQPACK064SD.

4. Install the connector of the flexible cable from the

emulator to the 38-pin connector on this product.

Hold this product while connecting the cable to avoid

imposing heavy pressure on the 38-pin connector of this

product.

(2) For on-board evaluation

5. Mount an MCU with on-chip flash memory and the

HQPACK064SD (not included) in order on the

NQPACK064SD-ND on the user system.

Before using this product, be sure to read section 7, Notes on Usage.

Warning to Connection:

•Always switch OFF the emulator, this product, and user system before connecting or disconnecting the

emulator. Failure to do so will create a FIRE HAZARD and will damage the emulator, this product, and

user system.

•Make sure that the connectors on both ends of the user-system interface cable are facing the right way

relative to the user-side connector on the emulator and the 38-pin connector on this product,

respectively. Incorrect connection will create a FIRE HAZARD and will damage the emulator, this

product, and user system.

Caution to Mount the NQPACK:

•Check the locations of pin 1 before mounting the NQPACK.

•The tightening torque must be no greater than 0.054 N•m. If the applied torque is not accurately

measurable, stop tightening when the force required to turn the screw (YQ-GUIDE-S1) becomes

significantly greater than that required at the start of tightening. Tightening a screw too much may break

the screw hole of the NQPACK or lead to a faulty connection by cracking solder on the NQPACK side.

•Failure of conduction during operation may be due to a crack in the solder for the NQPACK. Check

conduction with a tester and re-solder the NQPACK as required.

Figure 3 Connection of the User System and the MCU

Board

WARINIG

CAUTION

R0E5562GAPFK10 User's Manual

R20UT2114EJ0100 Rev.1.00 Page 5 of 8

Sep 05, 2012

6. Dimensions of this Product

Figures 4 shows the dimensions and reference pad pattern of this product (R0E5562GAPFK10).

22.25

Unit [mm]

10.00

14.00

10.00

14.00

0.50

0.25

0.50x15=7.50

18.30

28.00

18.50 7.50

TP2

45.00

IC1

128

112

Ø2.2

3.00

CN1 137

238

TP3 POWER

AVCC0

TP1

VCC

TP4

VREFH0

GND

R0E5562GAPFK10 REV.A

13.00 13.00

Figure 4 Reference Pad Pattern and Dimensions of this product (R0E5562GAPFK10)

R0E5562GAPFK10 User's Manual

R20UT2114EJ0100 Rev.1.00 Page 6 of 8

Sep 05, 2012

7. Notes on Usage

READ the following warnings before using this product. Incorrect operation will damage this product and user system.

The USER PROGRAM will be LOST.

Notes on Connecting this product:

•Cables must not be connected or removed while the power is on.

•Before connecting this product and user system, check that the pin 1 locations on both sides are correctly

aligned with each other.

Notes on Rewriting the Flash Memory:

•The number of times that the flash memory in the MCU installed on this product can be programmed is

limited. If an error in erasure occurs during debugging, replace this product.

Notes on Debugging:

•This product is only usable for debugging when it is connected to the user system.

•Debugging by this product alone is not supported.

Notes on Starting the Debugger and Selecting the MCU Type:

•Select the MCU type for use in the device name section of the [Initial Settings] dialog box on initiation of

the debugger.

Note on Differences between the MCU to be debugged and this Product:

•The sizes of the ROM, RAM, and data flash of the MCU installed in this product are 256 KB, 16 KB and

32 KB, respectively. Note that if the MCU to be debugged has the ROM, RAM, or data flash which is

smaller in size than that of this product, access can be made to the differential area.

Notes on Designing the User System:

•Pull the levels on the EMLE pin down to 4.7 kto 10 k.

•Pull the levels on the MD0 and MD1 pins up to 4.7 kto 10 k, and select the single-chip mode.

•Pull up or down the level on the MDE pin according to the endian used.

•The output of the reset circuit of the user system must be open collector.

Notes on the Flash Development Toolkit (FDT):

•Do not use the FDT when using the debugging MCU board.

Notes on the Writing the On-chip Flash Memory Mode:

•If the debugger has an exclusive mode for flash writing (e.g. “writing the on-chip flash memory mode” of

High-performance Embedded Workshop), do not use the mode.

Notes on the A/D Converter:

•The characteristics of the A/D converter differ from those of actual MCU because there are a converter

board and other devices between the MCU and the user system.

Notes on the Hot Plug-in function:

•Do not use the hot plug-in function when using this product.

R0E5562GAPFK10 User's Manual

R20UT2114EJ0100 Rev.1.00 Page 7 of 8

Sep 05, 2012

Precautions

This product is only intended for use in a laboratory environment under ambient temperature and humidity

conditions. A safe separation distance should be used between this and any sensitive equipment. Its use outside the

laboratory, classroom, study area or similar such area invalidates conformity with the protection requirements of

the Electromagnetic Compatibility Directive and could lead to prosecution.

The product generates, uses, and can radiate radio frequency energy and may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation. If this

equipment causes harmful interference to radio or television reception, which can be determined by turning the

equipment off or on, you are encouraged to try to correct the interference by one or more of the following

measures;

• ensure attached cables do not lie across the equipment

• reorient the receiving antenna

• increase the distance between the equipment and the receiver

• connect the equipment into an outlet on a circuit different from that which the receiver is connected

• power down the equipment when not in use

• consult the dealer or an experienced radio/TV technician for help

NOTE: It is recommended that wherever possible shielded interface cables are used.

The product is potentially susceptible to certain EMC phenomena. To mitigate against them it is recommended that

the following measures be undertaken;

• The user is advised that mobile phones should not be used within 10m of the product when in use.

• The user is advised to take ESD precautions when handling the equipment.

This product does not represent an ideal reference design for an end product and does not fulfill the regulatory

standards for an end product.

8. Warranty

1. The warranty of your product is valid for one year after purchase.

If your product becomes faulty or damaged while being used under good conditions by observing this user's manual,

we will repair or replace your faulty or damaged product free of charge.

2. Note, however, that if your product's fault or damage is raised by any one of the following causes, the warranty is

void.

a) Misuse, abuse, or use under extraordinary conditions

b) Improper handling such as dropping your product during transportation or carriage

c) Other connected equipments

d) Fires, earthquakes, lightning, flood and other unexpected disasters, damages and abnormal voltage.

e) Unauthorized remodeling, repair, adjustment, and so on

In the above cases, contact your local distributor.

If your product is being leased, consult the leasing company or the owner.

Colophon 2.2

Renesas Tools Website http://www.renesas.com/tools

ll trademarks and registered trademarks are the property

of their respective owners.

If the requirements shown in the "WARNING"

sentences are ignored, the equipment may

cause death or heavy wound.

Renesas Tools Website http://www.renesas.com/tools

ll trademarks and registered trademarks are the property

of their respective owners.

If the requirements shown in the "CAUTION"

sentences are ignored, the equipment may cause

personal injury or damage to the products.

WARINIG

Table of contents

Other Renesas Computer Hardware manuals

Renesas

Renesas 32176 User manual

Renesas

Renesas H8/36024 User manual

Renesas

Renesas Converter Board for M32171FxxFP M32171T-PTC User manual

Renesas

Renesas Emulation Pod M306H2T-RPD-E User manual

Renesas

Renesas M3T-FLX-80NRA User manual

Renesas

Renesas RL78 Series Installation and operating instructions

Renesas

Renesas E200F User manual

Renesas

Renesas QB-R5F1026A-TB User manual

Renesas

Renesas RZ/Five User guide

Renesas

Renesas Converter Board M3T-F160-64NSD User manual

Renesas

Renesas H8S series User manual

Renesas

Renesas M3A-HS85 User manual

Renesas

Renesas M65881AFP User manual

Renesas

Renesas H8/330 User manual

Renesas

Renesas MCU Board for PC4504 Emulator System... User manual

Renesas

Renesas DA9318 User manual

Renesas

Renesas SH7705 User manual

Renesas

Renesas R8C/11 Series Installation and operating instructions

Renesas

Renesas R9A02G011 Installation and operating instructions

Renesas

Renesas Direct Dummy IC M3T-DIRECT100S User manual

Renesas

Renesas H8SX/1520 Series User manual

Renesas

Renesas SH7763 User manual

Renesas

Renesas E6000 User manual

Renesas

Renesas RZ/A1H Series Installation and operating instructions

Popular Computer Hardware manuals by other brands

EMC2

EMC2 VNX Series Hardware Information Guide

Panasonic

Panasonic DV0PM20105 Operation manual

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 user manual

Gigabyte

Gigabyte B660M DS3H AX DDR4 user manual

Raidon

Raidon iT2300 Quick installation guide

National Instruments

National Instruments PXI-8186 user manual

Hauppauge

Hauppauge WinTV-HVR-2250 Quick installation guide

Kontron

Kontron CP6002 user guide

Manhattan

Manhattan 702843 user manual

Aphex

Aphex 230 instruction manual

AMD

AMD Phenom II Product data sheet

Intel

Intel NUC 12 Pro user guide

dbx

dbx Zone Pro 1260 user manual

Galaxy

Galaxy GHDX2-2430S-24F4D Installation and hardware reference manual

Intel

Intel AXXRMFBU4 Quick installation user's guide

Kontron

Kontron DIMM-PC/MD product manual

ST X-NUCLEO-SAFEA1B How to use

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 installation manual
