PC7501 Setup Guide

For details, refer to...

1 Check the contents. >> PC7501 Packing List (Back)

2 Register your PC7501. >> PC7501 User Registration Tool (Start up the REG7501E.EXE in the \REGISTER\ENGLISH folder on the Renesas Debugger

Package CD-ROM) or send a hardware tool user registration FAX sheet

3 Install an emulator debugger. >> README.HTM on the Renesas Debugger Package CD-ROM

Download the latest emulator debugger from http://www.renesas.com/en/tools

4 Setup hardware. >> PC7501 User’s Manual “Chapter 4 Setup (P.23)” and the user’s manual of the emulation probe

For Troubleshooting... PC7501 User’s Manual “5.2 Interface Connection Error (P.37)”

5 Turn on the PC7501 in maintenance mode. >> PC7501 User’s Manual “4.4 Downloading Firmware (P.34)”

6 Start up the emulator debugger. >> Emulator Debugger User’s Manual (Online Help)

7 Make settings for the emulator debugger. >> Emulator Debugger User’s Manual (Online Help)

8 Download firmware. >> PC7501 User’s Manual “4.4 Downloading Firmware (P.34)” and Emulator Debugger User’s Manual (Online Help)

For Troubleshooting... PC7501 User’s Manual “5.3 Firmware Download Error (P.39)”

9 Exit the emulator debugger, and turn off the PC7501.

10 Execute the self-check. >> User’s Manual of each emulation probe

11 Start up the emulator debugger. >> Emulator Debugger User’s Manual (Online Help)

For Troubleshooting... PC7501 >> PC7501 User’s Manual “Chapter 5 Troubleshooting (P.37)”

Emulator debugger >> Emulator Debugger User’s Manual (Online Help)

Renesas Tool Homepage PC7501 Emulators Site >> http://www.renesas.com/eng/products/mpumcu/toolhp/pc7501/



© 2005. Renesas Technology Corp. and Renesas Solutions Corp.,All rights reserved. Printed in Japan. Rev.1.00

05.03.01

REJ10J0902-0100T

PC7501 Packing List

- PC7501 emulator main unit 1

- AC adaptor (100-240 V, 50/60 Hz) 1

- AC power cable (3m) 1

- USB interface cable (1.9m) 1

- LPT parallel interface cable (1.9m, IEEE1284-A male to IEEE1284-C male cable) 1

- External trigger input/event output cable (50 cm) 1

- 160-pin flexible cable for connecting emulation probe (Preinstalled to PC7501) 1

- Converter board for connecting emulation probe M3T-FLX160-EPB (Preinstalled to PC7501) 1

- Oscillator board OSC-3 for 30 MHz (Preinstalled to PC7501) 1

- Renesas Debugger Package CD-ROM 1

- PC7501 User’s Manual (English) 1

- PC7501 User’s Manual (Japanese) 1

- Hardware tool user registration FAX sheet 1

This product package does not contain a LAN cable. Get a commercially available 10BASE-T cable.

If any of these items are missing or found faulty, please contact your local distributor.
