REH4MAT AKVOSEGO User manual
AKVOSEGO™
User manual
BATH CHAIR
5°C
70%
45%
Manufacturer takes responsibility for proper usage of the device only when
the product was purchased from qualified REH4MAT employee or at
specialized medical store!
REH4MAT reserve the right to introduce technical and trading changes in the
content of the instruction without warning.
35°C
Product marked with the CE sign is Class I medical device, of
rule 1, consistent with the requirements of Regulation (EU)
2017/745 of the European Parliament and of the Council of 5
April 2017 on medical devices.
REH4MAT introduced quality management system ISO 13485
regarding production, sales and service. The system is certified
by Det Norske Veritas.
AKVOSEGO
10. Safety rules........................................................................................................................19
4. Size table ...............................................................................................................................7
CONTENTS
3.2. Additional equipment............................................................................................6
7 . Additional equipment........................................................................................................14
1. The purpose of user manual...............................................................................................5
5. Detailed description of how to apply the lounger upholstery............................................8
6. The adjustment of bath chair.............................................................................................11
3. General characteristics of bath chair..................................................................................6
3.1. Standard equipment..................................................................................6
8. How to fix bodymap cushion on chair..............................................................................16
2. Indications for use................................................................................................................5
9. Using of chair......................................................................................................................18
11. Maintenance and cleaning...............................................................................................21
11. Labelling.............................................................................................................................23
Its upholstery and frame are available in different colours – it depends on its size.
AKVOSEGO™ bath chair is simple and innovative solution that is helpful while
taking care of disabled people. The bath chair consists of solid frame that is
made of aluminium and, moreover, it protects from adverse effects of water.
Furthermore, frame is equipped with foam covers that protect bathtub or kids
bath tub from scratching. Unique construction of frame makes it possible to
adjust the tilt angle of footrest and backrest.
Furthermore, it is also possible to change distance as well as seat’s tilt angle
towards floor. It is highly beneficial due to the fact that product is correctly
adjusted to user’s needs which is very helpful while e.g. washing little user’s hair.
Concerning upholstery, it is made of impermeable net. AKVOSEGO™ bath chair
can be used together with BodyMap® cushion either in a room or during bath
because all BodyMap® cushions are totally waterproof! The use of BodyMap®
cushion makes the stabilization of patient more efficient during bath.
INTRODUCTION
AKVOSEGO
Before using the product, user is obliged to familiarize himself/herself
with user manual. Remember that complying with guideline is highly
important. It assures safety and extends durability as well as
aesthetics of the device.
AKVOSEGO
5
This manual contains information necessary for correct use of
AKVOSEGO™ bath chair for children, preparation of the device before the use,
maintenance and cleaning as well as the guarantee conditions. Manual should
be kept in an easy accessible place.
The manual is addressed to the parents, doctors and physicaltherapistis
who take direct care of handicap children.
Please, remember that following the rules of the manual enables safe use of the
product, its extended life and esthetics.
THE PURPOSE OF USER MANUAL
Before using the product, user is obliged to familiarize himself/herself with
user manual.
źcerebral palsy (CP)
źMuscular dystrophy
źSpina bifida
źOther neurological diseases with movement deficits in the form of paralysis and
paresis of the limbs and / or trunk
Indications for use:
INDICATIONS AND CONTRINDICATIONS FOR USE
źMax. user's weight: size 0 - 25 kg, size 1 - 30 kg, size 2 - 50 kg, size 3 - 75 kg
Contrindications for use:
źIncorrect positioning of the person with the use of bathing products may lead to
deformation of the joints, and long-term keeping of the person in one position
significantly increases the risk of pressure ulcers.
Intended purpose of the product with a defined target group: Disabled people
(children / adolescents) with cerebral palsy, muscular dystrophy, spina bifida, spinal cord
injuries and neurological deficits.
3.1 Standard equipment
AKVOSEGO
6
GENERAL CHARACTERISTICS OF BATH CHAIR
Adaptation set used for
assembling BodyMap cushion BodyMap cushion
3.2. Additional equipment
AKVO - Active waterproof
platform for bath devices for
disabled children
Pelivic support
2
3
1
5
4
Pelvic-thigh belt
5. Leg support
4. Upholstery not absorbing the water
2. Head support
3. Trunk support
1. Frame
Symbol Measurement Unit Size 1 Size 2
A Seat width [cm]
B Seat depth [cm]
C Head rest height [cm]
C1 Back rest height [cm]
C2 Lower leg length [cm]
C3 Floor to seat distance [cm]
User weight (max) [kg]
Weight and dimensions of the device
Product width [cm]
After folding width [cm]
Product length [cm]
After folding length [cm]
Product height [cm]
After folding height [cm]
Product weight [kg]
Note: Dimensional tolerance in the table is +/-1 cm.
7
AKVOSEGO
Size 3
Size 3
SIZE TABLE
[kg]
4
42 45
28-33 32-40
16 19
40 44
31 36
11-44 13-49
30 50
50
37-50
23
50
41
15-54
75
37
23-28
16
31
26
11-44
25
Size 0
Size 1 Size 2
Size 0
42 45
42 45
75 91
67 76
85 96
28 29
50
50
97
88
113
31
4 4,5 8
42
42
70
64
80
28
4
AKVOSEGO
1
2
3
4 Joints
Frame of bath deckchair x 1
Footrest frame
Upholstery x 1
5 Head support x 1
6
Backrest Frame
8
DETAILED DESCRIPTION OF HOW TO APPLY THE LOUNGER
5
6
1
4
5
5
UP
DOWN
2 3
5.1. Components :
AKVOSEGO
first you must :
adjust the angle between the backrest
-Push the bottom part of the upholstery onto the footrest frame (fig. 4),
on the frame of the back support (fig. 2, 3),
- Press joints (G and F) at the same time
To put on the upholstery on the frame
and the footrest (according to fig. 1),
-Insert the upper part of upholstery
Fasten all straps with velcro closures from the underside of the lounger (fig. 5, 6).
Please keep in mind that the straps should cover the seat frame.
9
fig.6
fig.5
fig.2 fig.3 fig.4
GF
fig.1
AKVOSEGO
10
-lounger with upholstery set to the
usable position (fig.9).
- choose the appropriate height of the stabilizer on the backrest of the
lounger,
To mount the head stabilizer you must:
- next using straps with velcro closures fasten the stabilizer on the back of the
lounger (fig. 7, 8).
fig.7 fig.8
fig.9
