RedLeaf HD-SP102N User manual

Dearcustomer

Thankyouforpurchasingthisproduct.Foroptimumperformanceandsafety,please

readtheseinstructionscarefullybeforeconnecting,operatingoradjustingthis

product.Pleasekeepthismanualforfuturereference.

OurseriesofHDMIConverters,switchers,extenders,matrixesandsplittersare

designedtomakeyou`rea/Vdeviceusemoreconvenient,morecomfortable,more

productiveandmorecost-eﬃcient.

The1x2HDMISplitterthatsupportsFullHD3D&4k*2kusesasingleHDMIsource,

accessingtomultipleHDMIsinks.TheSplitterallowsoneHDMIdevicestobesplit

easilytoeightHDMIcompatiblemonitorsorprojectors.TheSplittercanalsobeplaced

attheendofalongHDMIcabletoregeneratetheHDMIsignal.

Ourdevicesoﬀersolutionsfornoise,spaceandsecurityconcerns,datacentercontrol,

informationdistribution,conferenceroompresentation,schoolandcorporate

trainingenvironments.

USER

MANUAL

INTRODUCTION

HDMISplitter1x2

FEATURES

OneHDM1.4ainputsignalsplittotwoHDMI1.4asinkdevices.

Support3D.

Support4k*2kresolution.

SupportCEC.

Supportdeepcolor30bit,36bit,48bit.

SupportBlue-Ray24/50/60fs/HD-DVD/xvYCC.

Digitalaudioformat,asDTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD/HD(HBR)

Supportsignalretiming.

Supportinputupto15metresAWG26HDMIstandardcablelength,outputupto20metres

AWG26cablelength.

Nolossofquality.

Installsinminutes.

NeedDC5V/2Apowersupply.

Theaccessorieswiththemachineslistsaspicture:

5VPowerAdaptor.

OnepcofManual

Poweradaptor

ModelNo:HD-SP102N

Redleaf

PhysicalConnectionShowingPicture:

POWER

Output2Output1Input

+DC5V

Figure1.0PanelShowingPicture

Figure1.1rearpanelshowingpicture

+DC5V:5VDC-DCPowerinterface

Input:HDMIInputInterface

Output1-Output4:HDMIoutput

Output1-Output2:SignalOutputLedLight

Input:SignalInputLEDLight

POWER:PowerLED

HDMiversion

HDMIresolution

Supportvideocolorformat

Supportaudioformat

Maxbandwidth

Maxbaudrate

Input/OutputTMDSsignal

Input/OutputDDCsignal

Inputcabledistance

Outputcabledistance

Maxworkingcurrent

PoweradapterformatInput

OperatingTemperaturerange

OperatingHumidityrange

Dimension(LxWxH)

Weight

HDMI1.4a

24/50/60fs/1080i/720p/576p/576i/480p/480i

24bit/deepcolor30bit,36bit,48bit

DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSDHD(HBR)

340MHz

10.2Gbps

0.5-1.5Voltsp-p(TTL)

5Voltsp-p(TTL)

<15mAWG26HDMIstandardcable

<20mAWG26HDMIstandardcable

1000mA

AC(50HZ,60HZ):100V-240V;Output:DC5V/3A

(-15to+55°C)

5to90%RH(NoCondensation)

110X52X20(mm)

141g

OperatingandConnecting:

ConnectonecablefromHDMIsourcedevicesintoHDMISplitterinput.

Connectonecablefromeachdisplay(monitororprojector)intotheHDMISplitteroutputs.

Connect5VpowersupplytotheHDMI1x4Splitter.

SPECIFICATIONS: HD-SP102N

Output2 Output1 Input

HDMISplitter1x2

Notes:

Plsusethemachineastheinstructionlistedtokeepthelonguselifetimeofthemachine.

ThemachineshouldbeplacedatthespotfarfromtheDamp,High-Temperature,Dusty,Erosive,andoxidativeenvironment.

Allpartswillbefreefromthestrongshake,hit,fall.

Touchingthepoweradaptorwiththewethandsisprohibited.

Plsholdthepoweradaptorheadanddonotpullthepowercordwhencutoﬀfromthesocket.

Plsturnthepoweroﬀwhenthemachineisnotusedforlongtime.

Plsdonotopenthecoveranddonottouchtheinsideparts.

Plsusetheoriginalfactorypoweradaptor.

Beforepoweron,plschecktheconnectionlinecarefully.Andmakesurethatallinterfacesarenormallyconnected.Thecommontroubleshootingway

showsbellow:

Checkifthepoweradaptorheadistrulyandcorrectlyinsertedthepowersocket.

Checkthepowerswitchitisinonstatus.

PlstomakesurethattheTVisonandhasbeenconnectedwiththemachine.

Tocheckifthesignalsourceisonandwellconnected.

Checkthesystemconnectionquality.

Checkifthelineisallgoodquality

Checkthecablequality

ToTryagaintoconnectthecabletobefreefromtheunsuccessfulconnection.

HDMICableQuality.

Non-Power-

Connected

NoPicture

ObscurePicture

SerialNO TroubleDescription CauseandWaystodealwith

HDMISplitter1x2
