RCA 42PA30RQ User manual
Made for Today.
Plasma HDTV
User s Manual
Model Number.
42PA30RQ
Made for Today.
Part No.: RN0342H1913
Please register your product at www.rca.com
Please keep your sales receipt and keep the record of
the serial number and the date of purchase in order to
receive warranty parts and service.
The serial number is located at the back of the TV.
1
Child Safety Guide
2
Use una montura que se ha recomendado por el fabricante de monitor
y/o listado por un laboratorio independiente (como UL, CSA, ETL).
Siga todas las instrucciones ofrecidas por el fabricante de monitor
y montaje de pared.
Child Safety Guide
3
Feature of PDP TV
• Do not use the TV where the temperature is below 41°F (5°C)
• Do not display still image for a long time
Leaving still image on for a long time can cause screen image retention on the plasma display. In other word, the image
retention is called “screen burn”. To minimize the possibility of screen burn, please use “Display Shift” and/or “White Panel”
functions. These functions are found under “Picture” - “Advanced Picture Settings” in OSD menu.
• Heat on the upper part of the product
After long period of use, the top side of the product will be hot. It’s natural as heat dissipates from the panel through the
vent hole on top of the TV. Please do not let children touch the upper part of the TV.
• Cell Defects
The Panel of PDP requires a highly sophisticated technique. However, the screen may have a few dark or bright pixels.
It won’t disturb the work of the product.
• Warranty
Image retention will not be covered by warranty.
1
3
4
Child Safety Guide ........................................................................................................................................
Table of Contents
Feature of PDP TV ........................................................................................................................................
Caution and Warning ...................................................................................................................................
.....................................................................................................................................................
......................................................................................................................................
..................................................................................................................................
.......................................................................................................................................
......................................................................................................................
6
FCC Notice 6
Preparation for Your New TV
Check Accessories 9
9
Setup TV Table Stand 9
Safety Precautions 7
..................................................................................................................................
......................................................................................................................................
Select TV Location 9
Connection and Using 9
..................................................................................................................................
...................................................................................................................................
Ferrite Core Installation 9
TV Stand Installation 10
.................................................................................................................................................
...................................................................................................................................................
......................................................................................................................................................
..............................................................................................................................
......................................................................................................................................
...............................................................................................................................
.................................................................................................................................
..................................................................................................................................
............................................................................................................................
...........................................................................................................................
...............................................................................................................
......................................................................................................................
........................................................................
..........................................................................
...............................................................................................
..............................................................................................
.................................................................................................................
.................................................................................................................
TV Signal Connection 11
Cable Connections 12
Back Panel Connections
TV Jacks Explanation
Keypad and Front Panel
13
13
14
15
16
16
17
18
Connecting AV Composite Video device (Good Video Quality)
Connecting YPbPr Component device (Better Video Quality)
Initial Setup 21
Connecting HDMI device (Best Video Quality)
Connecting a Computer
How to Obtain Various Kinds of Input Sources
.......................................................................................................................................
...............................................................................................................................................
..................................................................................................................................
.................................................................................................................................
.............................................................................................................................
.................................................................................................................
......................................................................................................................................
.........................................................................................................................................
Basic Operations 22
22
22
22
22
23
Turning On and Off
Choosing TV Channel
Selecting Input Source
Adjusting TV Stand Angle
Channel Bar
23
23
Adjusting Volume
EPG (Electronic Program Guide)
18
18
Keypad
Front Panel
Remote Control Instructions 19
19
19
Inserting Batteries in the Remote
Learning about Remote Control 20
20Remote Control Buttons
Remote Control Reception Angle
5
Table of Contents
OSD Menu Operations ..............................................................................................................................
..............................................................................................................................
..........................................................................................................................................
...........................................................................................................................
.................................................................................................................
.................................................................................................................
.....................................................................................................................
.............................................................................................................................................
.............................................................................................................................................
.............................................................................................................................................
......................................................................................................
...........................................................................................................................................
...........................................................................................................................................
.................................................................................................................................................
24
24
24
26
27
28
32
34
35
36
38
Adjust the OSD Screen
Picture Menu
Sound Menu
Channel Menu
Parental Menu
Frequently Asked Questions (FAQs)
Troubleshooting
V-Chip Rating Explanations
38
38
39
US V-Chip Rating System
Canadian English Rating System
Canadian French Rating System
Setup Menu
Others Menu
.............................................................................................................
Wall Mounting Unit Specification 40
...........................................................................................................................................
USB Media Play 41
..................................................................................................................................
Product Specification 42
...............................................................................................................................................
Warranty Card 43
6
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR
COMPLIANCE WITH THE FCC RULES COULD AVOID THE USERS AUTHORITY TO OPERATE THIS
EQUIPMENT.
Caution: To reduce the risk of electric shock, do not remove cover or back. No user-serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Caution and Warning
FCC Notice
The lightning flash with arrowhead
symbol, within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product enclosure
that may be of sufficient magnitude to
consitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the TV.
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio Communications. However, there is no Guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
7
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water. For example, do not use near a laundry tub, in a wet basement, or near a swimming
pool, and the like.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Slots and openings in
the cabinet back or bottom are provided for ventilation, to ensure reliable operation of the TV and to protect it from
overheating. These openings must not be blocked or covered. The openings should never be blocked by placing the TV
on a bed, sofa, rug, or other similar surface.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong is
provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to
avoid injury from tip-over. A TV and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the TV and cart combination to overturn.
13. Unplug this apparatus during lightning storms or when unused for long periods of time. For added protection for this TV
receiver during a lightning storm, or when it is left unused for long periods of time, unplug it from the wall outlet and
disconnect antenna or cable system. This will prevent damage to the TV due to lightning and power line surges.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the
appratus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15. This TV should be operated only from the type of power supply indicated on the rating label. If customer is not sure the
type of power supply in your home, consult your appliance dealer or local power company. For TV remote control battery
power, refer to the operating instructions.
16. The TV set shall not be exposed to dripping or splashing. No objects filled with liquids, such as vases, shall be placed on
the TV set.
17. Never push objects of any kind into this TV through openings as they may touch dangerous voltage or other electrical
parts that could result in fire or electric shock. Never spill liquid of any kind into the TV.
18. Unplug the TV from the wall outlet before cleaning. Do not use liquid or aero cleaners. Use a damp cloth for cleaning.
19. This TV should never be placed near or over a radiator or heat resource. This TV should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been
adhered to.
20. Do not place this TV on an unstable cart, stand, tripod, bracket, or table. The TV may fall, causing serious injury to
someone, and serious damage to the appliance.
21. Do not attempt to service this TV by yourself because opening or removing covers may expose you to dangerous high
voltage or other hazards. Refer all servicing to qualified service personnel.
22. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Safety Precautions
M6 Screws
Wall
8
25. If an outside antenna or cable system is connected to the TV, be sure the antenna or cable system is grounded to provide
some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code,
ANSI/NFPA NO.70, provides information with respect to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge
unit, connection to grounding electrodes, and requirements for the grounding electrodes. (See figure A)
24. To reduce the risk of electric shock, the grounding of center pin of plug must be maintained.
Safety Strap
Caution: Pushing, pulling or climbing on the TV may cause the TV falling. Do not let chlidren climb or hang on the TV.
Always place the TV on a sturdy, level, stable surface that can hold the weight of TV. And if possible, secure the TV
according to the instruction below (Note: The fastening components such as screws are not supplied with TV).
Step one: Insert the M6 mounting screws into the upper two wall mounting screw holes and fasten them (Figure B).
Step two: Insert anchors to wall and connect the bolts and anchors with ropes or chains (Figure C).
Safety Precautions
ANTENNA
LEAD IN
WIRE
GROUND CLAMP
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PARTH)
ELECTRIC SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
Figure A
Figure B Figure C
23. WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the
installation instructions.
AAA BATTERIES
AC POWER CORD
TV STAND SCREWS
MACHINE
SCREW
M4 x 12mm, 6pcs
Part# RS01TM412H
COVER
TV STAND FERRITE CORE
9
Note: Above accessories are subject to change without notice.
Before Turning On TV
Check Accessories
Check the accessories that are packed with your TV.
Select TV Location
Select a flat, stable table to place your TV set. Please follow the Safety Instructions when placing the TV.
Setup TV Table Stand
Please refer to TV Stand Installation guide in next page to carry out stand installing.
Connection and Using
After placing your TV properly, you can connect the TV with power supply and cable components. For further information, see page
13 to page 16.
Ferrite Core Installation
In order to reduce the influence to the screen caused by
the noise induced from the cable, please install the ferrite core.
How to install ferrite core: Open the ferrite core, slide the
power supply cable into the slot, then get the core buckled.
Preparation for Your New TV
REMOTE CONTROL
PART NO.: RE20QP80
CH LI ST
.
SOUND
DOCUMENTS
USER’S
GUIDE
REMOTE CONTROL
GUIDE
QUICK START
GUIDE
Quick Start Guide
Remote Control Guide
Program Your Universal Cable
or Satellite Remote Control to
Operate Your New RCA TV!
If you would like to program your other
household remote controls to your new RCA
television, please consult the User’s Manual
supplied by your Cable or Satellite provider.
The Cable or Satellite providers’ User’s Manuals
should include instructions on how to program
their remote to your television.
Below is a list of RCA codes for the most
common Cable and Satellite providers.
Use the RCA code that is associated with your
Cable or Satellite provider (if applicable).
DIRECTV.........................0178,10178
Time Warner Cable...........0178,0178
Comcast.................................. 10178
Cox Communications.................0178
Dish Network.............................627
Fios Verizon.....0205,0057,0493,0775
If the RCA code associated with your Cable or
Satellite provider is not listed above, if the code
above does not work, or if you can not locate the
instructions for programming your household
remote to your television, call your local Cable or
Satellite provider’s customer service center.
Part No.: RN0342H1911
Please register your product at www.rca.com
Serial Number / Número de serie de TV
Date of Purchase / Fecha de la compra
Eng li sh
Please keep your sales receipt and keep the record of
the serial number and the date of purchase in order to
receive warranty parts and service.
The serial number is located at the back of the TV.
This is for U.S. customers
CH LIST
.
SOUND
Plasma HDTV
User s Manual
Model Number.
42PA30RQ
Install the ferrite core on the
power cord close to the plug
(Picture may differ from actual product appearance.)
Other manuals for 42PA30RQ
4
Table of contents
Other RCA Plasma TV manuals
