RCA 46LA55R120Q User manual
RCA Full HDTV 120Hz MODEL –46LA55R120Q
Product Specifications
Solution
RENESA
Built-in Tuner
YES
Color System
ATSC/NTSC
Stereo System
MONO-STEREO-SAP
Closed Captions
YES
V-CHIP
YES
HDTV Ready
720P 1080i 1080P
PC Resolution
DOS/ VGA/SVGA/SXGA
Black/Blue stretch
YES
CCD
CC1~CC4 T1~T4
Digital Comb filter
3D
OSD Menu Language
English/French/Spanish/Optional
Noice reduction
3D
Sleep timer
YES
Power consumption
TBA
Voltage/Frequency
AC100-240v, 120Hz
Standby Power
consumption
TBA
Wall Mounting
YES
Wall Bracket Size
VESA STANDARD
AV Features
Pixel Pitch
0.53025*0.53025
Aspect ratio
16:9
Max. Resolution
1920 x1080 FHD
Brightness
450 cd/m2
Contrast
5000:1
View Angle
H:178°, V:178°
Response Time
6 ms
Display Colours
16.7M
Audio Amplifier
2*10W
Sound Mode
User/Dynamic/Standard/Soft
Picture Mode
User/Dynamic/Standard/Movie
Aspect
Full/Normal/WaterGlass/Cinema
Connections
Antenna Input
1 REAR
HDMI
4 REAR
VGA input
1 REAR
AV Input
1 X 3REAR
YPbPr or YCbCr
(COMPONENT)
1 X 3REAR
Audio Input
(PC Stereo)
1 REAR
USB Port
( For Service purpose )
1 REAR
Audio L/R output
1 X 2 REAR
Headphone
1 REAR
COAX output
1 REAR
Compliance
Unit Safety Regulation
UL/FCC
AC Cord
UL
Unit Color
PIANO BLACK
GTIN-14 Code
008 83393 00344 1
Unit Dimension
(W/o Stand)
1114x108x694mm
Unit Dimension
(With Stand)
1114x273x748mm
Packing Dimension
1280x320x860mm
Unit Weight
25 kgs
Gross Weight
22.1 kgs
Loading Q’ty
100pcs/20’, 200pcs/40’
243pcs/40’HQ
RCA Full HDTV 120Hz
MODEL –46LA55R120Q
■46 Inch LCD Full HDTV
■120Hz Refresh Rate
■Tuner Mode : ATSC
■4 HDMI & 1080P
■Resolution: 1920 x1080
■Contrast: 5000:1
■Brightness: 450cd/㎡
■Response Time : 6ms
■Digital 3D Comb Filter
■Component, VGA, AV input
Key feature
Specifications
Packing details
