Razer RZ01-0373 User manual
FO R G A M E R S . B Y GA M E RS.™
1
WHAT’S INSIDE / WHAT’S NEEDED
WHAT’S INSIDE
Wireless Mouse [Model #: RZ01-0373]
A. Left mouse button
B. Right mouse button
C. Scroll wheel
D. DPI cycle button
E. Status indicator
F. Mouse button 5
G. Mouse button 4
H. Ultraslick mouse feet
I. Optical sensor
J. Slider switch
Bluetooth mode
Power off mode
Razer™ HyperSpeed Wireless
(2.4 Ghz) mode
1 x AA battery
Important Product Information Guide
The DPI stages are as follows: 400, 800, 1600 (default), 3200 and 6400. The DPI stages can be
customized using Razer Synapse.
FO R G A M E R S . B Y GA M E RS.™
2
WHAT’S NEEDED
PRODUCT REQUIREMENTS
Windows® OS
USB-A port
1 x 1.5V AA battery*
Bluetooth 5.1 connectivity
RAZER SYNAPSE REQUIREMENTS
Windows® 7 64-bit (or higher)
Internet connection for software installation
*Also compatible with a AAA battery (not included).
FO R G A M E R S . B Y GA M E RS.™
3
LET’S GET YOU COVERED
You’ve got a great device in your hands, complete with a 2-year limited warranty coverage. Now
maximize its potential and score exclusive Razer benefits by registering at razerid.razer.com
Got a question? Ask the Razer Support Team at support.razer.com
Your product’s serial
number can be found
here.
FO R G A M E R S . B Y GA M E RS.™
4
GETTING STARTED
INSERTING THE BATTERY
1. Remove the top cover of the mouse and insert the AA battery as indicated in the battery
compartment.
Caution: The included AA battery is non-rechargeable. You may also use a AAA battery (not
included) if preferred. Dispose batteries in accordance with your local environmental laws.
For your safety, use only alkaline batteries and do not mix old batteries with new ones.
2. Reattach the top cover onto the mouse and make sure that it is tightly secured.
FO R G A M E R S . B Y GA M E RS.™
5
CONNECTING YOUR MOUSE
A. VIA RAZER™ HYPERSPEED WIRELESS (2.4 GHZ) MODE
1. Remove the top cover of the mouse and take out the wireless USB dongle.
2. Close the top cover and insert the wireless USB dongle into the USB port of your PC.
3. Push the slider switch to Razer™ HyperSpeed Wireless (2.4 GHz) mode. When connected, the
status indicator will briefly turn static green.
FO R G A M E R S . B Y GA M E RS.™
6
Your RZ01-0373 is now ready for use in wireless mode.
B. VIA BLUETOOTH MODE
1. Push the slider switch to Bluetooth mode ( ).
2. Press and hold the two side buttons and the DPI cycle button simultaneously for three seconds
to activate pairing mode. The status indicator will blink twice in repeated intervals to show
that the device is in pairing mode.
3. Activate Bluetooth on your device and select “RZ01-0373” from the list of devices found.
Pairing
FO R G A M E R S . B Y GA M E RS.™
7
4. Wait until the mouse pairs with your device. When paired, the status indicator will briefly turn
static blue.
Once paired, your RZ01-0373 will automatically reconnect to your device whenever in
Bluetooth mode and within range. Keep the pairing devices within close proximity of
each other for faster and more stable connection.
Congratulations, your RZ01-0373 is now ready to use in Bluetooth mode.
Pairing Paired
FO R G A M E R S . B Y GA M E RS.™
8
LOW BATTERY NOTIFICATION
The status indicator will blink red twice in repeated intervals to indicate that the battery level of the
inserted battery is less than 5%*. This lighting sequence will repeat until the battery is fully drained.
Once you receive this notification, it’s time to replace the battery.
The indicator percentage can be customized through Razer Synapse.
PERSONALIZING YOUR MOUSE WITH RAZER SYNAPSE
Change your mouse’s DPI to match your playstyle with a press of the DPI cycle button or fine-tune
your own sensitivity setting using the Razer Synapse app.
Install Razer Synapse when prompted or download the installer from razer.com/synapse
FO R G A M E R S . B Y GA M E RS.™
9
SAFETY AND MAINTENANCE
SAFETY GUIDELINES
In order to achieve maximum safety while using your RZ01-0373, we suggest that you adopt the
following guidelines:
Should you have trouble operating the device properly and troubleshooting does not work, unplug
the device and contact the Razer hotline or go to support.razer.com for support.
Do not take apart the device (doing so will void your warranty) and do not attempt to operate it
under abnormal current loads.
Keep the device away from liquid, humidity or moisture. Operate the device only within the specific
temperature range of 0°C (32°F) to 40°C (104°F). Should the temperature exceed this range, unplug
and/or switch off the device in order to let the temperature stabilize to an optimal level.
COMFORT
Research has shown that long periods of repetitive motion, improper positioning of your computer
peripherals, incorrect body position, and poor habits may be associated with physical discomfort and
injury to nerves, tendons, and muscles. Below are some guidelines to avoid injury and ensure
optimum comfort while using your RZ01-0373.
Position your keyboard and monitor directly in front of you with your mouse next to it. Place
your elbows next to your side, not too far away and your keyboard within easy reach.
Adjust the height of your chair and table so that the keyboard and mouse are at or below
elbow-height.
