Randall RG100SC User manual
Master Controls:
The RG100SC is equipped with Clean and Lead master controls. Each channel can be
set to your desired volume.
Preamp Controls:
This amp features two preamp channels, Gain 1 and Gain 2 for the Lead channel and
Level 1 for the Clean channel. Each can be adjusted for desired gain.
EQ Controls:
The RG100SC has a three-band EQ with shape control for the lead channel and a separate
three-band EQ for the clean channel.
Effects:
The RG100SC is equipped with a footswitchable Stereo Chorus with Depth and Rate controls.
The amp also offers spring reverb.
Output Power:
The amp offers Constant Current, solid-state technology at 100-watts of RMS power.
Speakers
: This RG100SC pushes its 100-watts of power through two 12” Celestion Seventy 80 speakers
specially voiced for this amplifier.
Additional Features:
This amp offers several additional features including line out with independant level
control, external speaker jack, effects loop, headphone jack and channel-switching footswitch.
Power Output: 100-Watts RMS @ 4ohms.
Tone Controls
(All Controls Set At 5):
Bass: +/- 15db @ 50Hz
Mid: +/- 10db @ 600Hz
Treble: +/- 18db @ 3Hz
Shape: +18db @ 15Hz
Effects Loop:
Send 200mV
Return 50k ohms
Signal Output:
0 db @ 600ohms
Dimensions:
664W x 558H x 264D mm
