Quoizel GLS8406EK User manual

-of-12

INSTALLATION GUIDE FOR GLS840 EK6

CARE AND MAINTENANCE

SAFETY INFORMATION Released Date: 202 -2 09-05

Please read and understand this entire manual before attempting to assemble, install or operate the product.

WARNING

• RISK OF ELECTRIC SHOCK - Before beginning installation, turn oﬀ electricity at the circuit breaker box or the main fuse box.

• RISK OF FIRE - Use bulbs speciﬁed by the markings and/or labels on the ﬁxture.

CAUTION

• For your safety, read instructions completely before beginning installation.

• If in doubt about electrical installation, consult a licensed electrician.

• Turn oﬀ electricity to ﬁxture before replacing the bulb(s).

TOOLS REQUIRED

AFixture Body

x 1

PACKAGE CONTENTS

MOUNTING HARDWARE

B

• Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean ﬁxture as they may damage

the ﬁnish.

If you need further assistance call Quoizel Customer Care at 1-800-645-3184 (9:00am - 5:00pm EST), or visit us on-line at

www.quoizel.com.

Crossbar

x 1

AA

Wire Connector

x3

CC Outlet Box Screw

x2

DD

Mounting Screw

x2

BB

Glass Shade

x 1

-of-22

INSTALLATION

1

Install Crossbar

Install Fixture Body

White wire from supply White from ﬁxture

Black (or red) wire from supply Black from ﬁxture

Ground wire from supply

Ground wire

from ﬁxture

Green ground screw

Wiring

3

2

4

5

Install Bulb and Glass Shade

Apply Caulking

ECxterior aulk

ECxterior aulk

* Note: Do NOT caulk the bottom of the backplate to

allow moisture to escape.

Your installation is now complete! Restore electricity and save this sheet for future reference.

OUTLET BOX

Install t correct bulb referring tohe

ﬁxture markings and/or labels for

maximum wattage.

Recommended Bulb Type (not

included):

BULB BASE TYPE

Candelabra (E12)

BULB SHAPE

TYPE B

60W

ECxterior aulk

ECxterior aulk
