Queen Bee Power QB1300 User manual
Generator Model QB1300 QB2800 QB3300 QB5500E QB7700E
Frequency(Hz) 60Hz 60Hz 60Hz 60Hz 60Hz
Rated AC voltage (volts) 120 120 120 120/240 120/240
AC Circuit breaker 10A(1pcs) 22A (1pcs) 27A (1pcs) 22A(2 pcs)
Rated AC Output (watts) 1100 2500 3000 5000 7200
Peak AC (watts) 1300 2800 3300 5500 7700
DC Output (volts) 12v 12v 12v 12v 12v
Engine Model WG90 WG160 WG200 WG340 WG405
Engine(HP) 2.6 5.5 6.7 11.0 14.0
Low level oil alert No With With With With
Gas tank capacity 1.3 Gallon 3 Gallon 3 Gallon 6 Gallon 6 Gallon
Starting system Recoil Recoil Recoil Recoil&Electric Recoil&Electric
Noise level db(A)@7m 65-68 70-72 72-74 68-74 68-74
Gas level gauge Std Std Std Std Std
Voltmeter Std Std Std Std Std
AC receptacles 15A AC120V 1pc 20A AC120v 2PCS 20A AC120v 2PCS 20A AC120V 4PCS 20A AC120V 4PCS
AC twist lock receptacle N/A N/A N/A 30A AC240V 1PC 30A AC240V 1PC
Two wheel kit&tow handle N/A N/A Std Std Std
Dimensions L*W*H 18"x14"x15.5" 22"x17.5"x19.5" 22"x17.5"x19.5" 25"x21"x25" 25"x21"x25"
Gross weight 65 lbs 108 lbs 117 lbs 187 lbs 209 lbs
