Pyle PLVWR1752 User manual
HTTP://WWW.PYLEAUDIO.COM
Instruction Manual
1 x instruction manual1 x remote control
2 x connection wire
1. When connect the electric power wires, you should make clear about the
positive and negative electrode ( the red one is positive and the black
is negative). If you wrongly connected the fuse in the filter box will be
broken protectively. Please replace the fuse in same parameter.
2. Because the LCD screen is the main component It should be paid
attention to be damp-proof.
3. The device must be installed firmly to prevent falling of device that will
possibly cause injury and device-broken.
4. The connecting-point of direct current (12V) should connect on the Main
line of storage battery as possible as it can , for keeping this device in
normal operation and be away from the large voltage drop influence.
5. There is high voltage cluster in this machine, if you are the professional
person, should never to take part the machine if malfunction and
contact the dealer in time.
Attentions:
Accessories
PLVWR1752
17" High Resolution Widescreen TFT-LCD Flip-Down
Roof Mount Monitor w/IR Transmitter
V1V2MENU
Thank you for purchasing the TFT LCD color monitor. To enjoy the features
of this device and to ensure years of trouble-free operation, please read
this manual carefully and follow the instructions.
Front Panel
Remote control
Analog variable increase
Menu button
V1/V2 conversion
Analog variable decrease
Switch for mode
Specification
Installation Diagram
Power ON/OFF
1. IR transmitter
2. Power ON/OFF
3. V1/V2 switch
4. Negative adjustment
5. Activation of menu indicator
6. Positive adjustment
7. Remote control
8. Light switch
9. open/close
V1V2MENU
* 17'' TFT Active Matrix System
* Super Slim Design
* On Screen Display Menu
* 16:9 Widescreen Aspect
* High Resolution 1280 x 1024
* NTSC/PAL
* 2 AV Inputs
* Built-In IR Transmitter for Wireless IR Headphones
* English OSD Menu
* Full Function Wireless Remote Control
* Dual Dome Light
* Universal Roof Mount Console
* Power Input DC 12V
* Dimensions: 17"W x 13.8"H x 1.2"D
