PUIG 3493 User manual
ID.PART DESCRIPTION QTY. REF.:
1 Left guide 1 SOPOR-8P-6-3493
2 Right guide 1 SOPOR-8P-6-3493
3 Upper support 2 SOPOR-8P-6-3493
4 Lower support 2 SOPOR-8P-6-3493
5 M6X16 ISO 4753 Knob 2 MANECILLA------
6 Ø15,87 x Ø8,76 x 2,66mm bush with flange 8 ARAND------3493
7 Ø9,53 x Ø14,27 x 12,7mm nylon spacer 4 DISTANCIADOR---
8 M5x11 Ø11 ISO 7380 allen screw 6 TORNI-AI----520
9 M5x1 nylon washer 4 ARNV0000000245
10 M5 ISO 7380 screw cap 4 TAPON--------85
11 Ø4,5 x Ø11 x 2mm rubber washer 4 ARAND-EPDM--722
HONDA
CRF1000L AFRICA TWIN / ADVENTURE SPORTS
MO U N T I N G I N STRUCTI O N S
REF 3493 MA N U A L R E G U L A T I O N S Y S T E M F O R W I N D SHI E L D S
1 Person
20 min
EASY Nº 5
ALLEN
Nº 3
12 M5x20 Ø11 ISO 7380 allen screw 4TORNI-I7380-730
UP
DOWN
LOOSEN ID8 SCREW AND CHECK THE
CORRECT OPERATION
Original components
A
HONDA
CRF1000L AFRICA TWIN / ADVENTURE SPORTS
M OUNTI N G I N STRU CTIO N S
1
DISASSEMBLY
2
3 4
ASSEMBLY
ASSEMBLY
ASSEMBLY
A
AA12
11
89
9810
21
88
A
12
12
12
DOWN
EXPLOTING FOR MANUAL
REGULATIO N SYSTEM
POSITION SCREEN ON LOWEST POSITION
AND TIGHTEN ID8 SCREWS
HONDA
CRF1000L AFRICA TWIN / ADVENTURE SPORTS
M OUNTING I N STRUCTION S
5
ASSEMBLY
8
8
5
1
3
4
8
6
7
6
5
2
3
4
8
6
7
6
ID. PART DESCRIPTION QTY. REF.:
1 Touring Screen 1 8905A/F/H/N/R/WM3
2 Left guide 1 SOPOR-8P-6-3493
3 Right guide 1 SOPOR-8P-6-3493
4 Upper support 2 SOPOR-8P-6-3493
5 Lower support 2 SOPOR-8P-6-3493
6 M6x16 ISO 4753 Knob 2 MANECILLA------
7 Ø15,87 x Ø8,76 x 2,66mm bush with flange 8 ARAND------3493
8 Ø9,53 x Ø14,27 x 12,7mm nylon spacer 4 DISTANCIADOR---
9 M5x11 Ø11 ISO 7380 allen screw 6 TORNI-AI----520
10 M5x1 nylon washer 4 ARNV0000000245
11 M5 ISO 7380 screw cap 4 TAPON--------85
12 Ø4,5 x Ø11 x 2mm rubber washer 4 ARAND-EPDM--722
HONDA
CRF1000L AFRICA TWIN / ADVENTURE SPORTS
M O U N T I N G I N STRUCTI O N S
REF 3714 TOURING SCREEN +MANUAL ELEVATION MECHANISM (MEM)
1 Person
20 min
EASY Nº 5
ALLEN
Nº 3
UP
DOWN
LOOSEN ID8 SCREW AND CHECK THE
CORRECT OPERATION
Original components
A
Original screws
A
HONDA
CRF1000L AFRICA TWIN / ADVENTURE SPORTS
- M OUNTI N G I N STRUCTIO N S -
1
DISASSEMBLY
2
3 4
ASSEMBLY
ASSEMBLY
ASSEMBLY
A
AAA
12
910
10 911
32
9
9
1
ID9
DOWN
EXPLOTING FOR MANUAL
REGULATIO N SYSTEM
POSITION SCREEN ON LOWEST POSITION
AND TIGHTEN ID8 SCREWS
HONDA
CRF1000L AFRICA TWIN / ADVENTURE SPORTS
M OUNTI N G I N STRUCTIO N S
5
ASSEMBLY
9
9
ID9
6
2
4
5
9
7
8
7
6
3
4
5
9
7
8
7
D
D
D
iffi
fi
fi
c
cu
u
u
l
lt
ID. QTY
.
Right Elevator suplement support 11
Left Elevator suplement support 12
84 ØINT.4 ØEXT.14 x 4 rubber washers
43 M5x16 ISO 7380 Allen screw
5 min
1 person
Nº 5
ALLEN
Ref.: 9154
HONDA AFRICA TWIN ‘16- / AFRICA TWIN ADV. SPORT ’18-
Puig Racing Screen Puig Touring Screen
Original screen
PART
- ELEVATOR SUPPORT FOR -
DESCRIPTION
Easy
Intermediate
Support
HONDA AFRICA TWIN ‘16- / AFRICA TWIN ADV. SPORT ’18-
3A
4A
4
2
1
Original screws
A
Original screws / Original Screen
A
NOT NECESSARY IN AFRICA TWIN ADVENTURE
SPORT ’18
4
4
A
3
2
1
A
- MOUNTING INSTRUCTIONS -
- ELEVATOR SUPPORT FOR -
HONDA AFRICA TWIN ‘16- / AFRICA TWIN ADV. SPORT ’18-
Puig Racing Screen ref.:
8904 NOT included
Puig Touring Screen
ref.: 8905 NOT included
3B
A
4
3C
Original screws
A
Original screws
A
A
4
A
4
A
4
- ELEVATOR SUPPORT FOR -
- MOUNTING INSTRUCTIONS -
